Sena SPIDER ST1 User Manual

Motorcycle mesh communication system
Hide thumbs Also See for SPIDER ST1:
Table of Contents

Advertisement

Quick Links

SENA
MOTORCYCLE MESH COMMUNICATION SYSTEM
USER'S GUIDE
Version 2.1.0
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPIDER ST1 and is the answer not in the manual?

Questions and answers

Павел
April 7, 2025

Возможно соединение с гарнитурами не поддерживающими Mesh ?

0
1 comments:
Mr. Anderson
April 9, 2025

No, the Sena SPIDER ST1 cannot connect with headsets that do not support Mesh. It is a mesh-only unit and does not support Bluetooth intercom.

This answer is automatically generated

0

Related Manuals for Sena SPIDER ST1

Summary of Contents for Sena SPIDER ST1

  • Page 1 SENA MOTORCYCLE MESH COMMUNICATION SYSTEM USER’S GUIDE Version 2.1.0 ENGLISH...

  • Page 2: Table Of Contents

    3.5 Volume Adjustment 3.6 Checking the Battery Level PAIRING THE HEADSET WITH OTHER BLUETOOTH DEVICES 4.1 Phone Pairing 4.1.1 Initially Pairing the SPIDER ST1 4.1.2 Pairing When the SPIDER ST1 is Turned Off 4.1.3 Pairing When the SPIDER ST1 is Turned On...
  • Page 3 TABLE OF CONTENTS CONTINUED 4.2 Second Mobile Phone Pairing - Second Mobile Phone and GPS 4.3 GPS Pairing MOBILE PHONE USAGE 5.1 Making and Answering Calls 5.2 Speed Dialing 5.2.1 Assigning Speed Dial Presets 5.2.2 Using Speed Dial Presets 5.3 HD Voice (Always On) STEREO MUSIC 6.1 Playing Music with Bluetooth Devices MESH INTERCOM...
  • Page 4 TABLE OF CONTENTS CONTINUED FUNCTION PRIORITY 10. CONFIGURATION SETTING 10.1 Headset Configuration Menu 10.2 Software Configuration Setting 10.2.1 Headset Language 10.2.2 Audio Equalizer (Default: Off) 10.2.3 VOX Phone (Default: Enable) 10.2.4 VOX Sensitivity (Default: 3) 10.2.5 Intercom-Audio Overlay Sensitivity (Default: 3) 10.2.6 Audio Overlay Volume Management (Default: Disable)

  • Page 5: About The Spider St1

    1. ABOUT THE SPIDER ST1 1.1 Product Features Bluetooth ® Mesh Intercom up to 2 km (1.2 mi)* Audio Multitasking™ Fast Charging * in open terrain SPIDER ST1 Motorcycle Mesh Communication System | 5...

  • Page 6: Product Details

    1 ABOUT THE SPIDER ST1 1.2 Product Details Mesh Intercom Antenna Jog Dial Mesh Intercom Button Phone Button Status LED Charging LED DC Power Charging & Firmware Upgrade Port Speaker and Microphone Port SPIDER ST1 Motorcycle Mesh Communication System | 6...

  • Page 7: Package Contents

    Hook and Loop Fastener Microphone Sponges for Boom Microphone Boom Hook and Loop Wired Microphone Microphone Holder Fastener for Holder Hook and Loop Fastener USB Power & for Wired Microphone Data Cable (USB-C) SPIDER ST1 Motorcycle Mesh Communication System | 7...

  • Page 8: Installing The Headset On Your Helmet

    1. Clean the area on the left side of the helmet where you will attach the glued surface mounting plate with a moistened towel and dry thoroughly. SPIDER ST1 Motorcycle Mesh Communication System | 8...

  • Page 9: Installing The Speakers

    2.2 Installing the Speakers 1. Peel off each cover of the hook and loop fasteners for speakers to expose the adhesive surface. Then, attach the fasteners to the ear pockets inside the helmet. SPIDER ST1 Motorcycle Mesh Communication System | 9...

  • Page 10: Installing The Microphone

    Then, attach the hook and loop fastener on the inside surface of the left external shell. 2. Attach the wired boom microphone’s mounting plate to the hook and loop fastener. SPIDER ST1 Motorcycle Mesh Communication System | 10...
  • Page 11 4. Align the arrows on the microphone and speaker cables and insert the microphone cable into the microphone connector. SPIDER ST1 Motorcycle Mesh Communication System | 11...

  • Page 12: Installing The Wired Microphone

    1. Peel off the cover of the hook and loop fastener for wired microphone to expose the adhesive tape. Then, attach the hook and loop fastener on the inside of the helmet’s chin guard. SPIDER ST1 Motorcycle Mesh Communication System | 12...
  • Page 13 4. Insert the speaker cable into the speaker and microphone port to connect it to the main unit. 5. Close the cover of the speaker cable to lock the cable to the port. SPIDER ST1 Motorcycle Mesh Communication System | 13...

  • Page 14: Getting Started

    3. GETTING STARTED 3.1 Downloadable Sena Software 3.1.1 SENA MOTORCYCLES App By simply pairing your phone with your headset, you can use the SENA MOTORCYCLES App for quicker, easier set up and management. SENA MOTORCYCLES • Download the SENA MOTORCYCLES App on Google Play Store Store.

  • Page 15: Charging

    2.0 hours of Mesh communication after charging the headset for 20 minutes. • Any 3rd party USB charger can be used with Sena products if the charger is approved by either the FCC, CE, IC, or other locally approved agencies.

  • Page 16: Powering On And Off

    3.6 Checking the Battery Level Instructions are for when powering the headset on. Powering On HOLD Note: When the battery is low while in use, you will hear a voice prompt saying “Low battery”. SPIDER ST1 Motorcycle Mesh Communication System | 16...

  • Page 17: Pairing The Headset With Other Bluetooth Devices

    1. Press and hold the Phone Button and the Jog Dial for 1 second. Blinking HOLD “Phone pairing” Note: • The phone pairing mode lasts for 3 minutes. • To cancel phone pairing, tap the Phone Button or Jog Dial. SPIDER ST1 Motorcycle Mesh Communication System | 17...

  • Page 18: Pairing When The Spider St1 Is Turned Off

    0000. Device B 4.1.2 Pairing When the SPIDER ST1 is Turned Off 1. While the headset is off, press and hold the Phone Button and the Jog Dial until the LED flashes red and blue alternately and you hear a voice prompt, “Phone pairing”.

  • Page 19: Second Mobile Phone Pairing - Second Mobile Phone And Gps

    2. Rotate the Jog Dial clockwise until you hear a voice prompt, “Second mobile phone pairing”. Blinking ROTATE “ Second mobile phone pairing” 3. Select SPIDER ST1 in the list of Bluetooth devices detected. If your Bluetooth Bluetooth device asks for a PIN, SPIDER ST1 enter 0000.

  • Page 20: Mobile Phone Usage

    5.2 Speed Dialing 5.2.1 Assigning Speed Dial Presets Speed Dial Presets could be assigned through the Sena Device Manager or the SENA MOTORCYCLES App. 5.2.2 Using Speed Dial Presets 1. Enter into the Speed Dial menu.

  • Page 21: Hd Voice (Always On)

    This feature increases the quality so that the audio will be crisp and clear during phone call conversations. Note: Refer to the manufacturer of your Bluetooth device that will be connected to the headset to see if it supports HD Voice. SPIDER ST1 Motorcycle Mesh Communication System | 21...

  • Page 22: Stereo Music

    6. STEREO MUSIC 6.1 Playing Music with Bluetooth Devices Play/Pause Music HOLD Track Forward/Backward ROTATE ROTATE SPIDER ST1 Motorcycle Mesh Communication System | 22...

  • Page 23: Mesh Intercom

    The working distance between each SPIDER ST1 in Mesh Intercom can be up to 2 km (1.2 miles) in open terrain. In open terrain, the Mesh can be extended up to 8 km (5 miles) between a minimum of six users.

  • Page 24: Open Mesh

    Mesh needs to be created by the users. When users create a private group in Group Mesh by Mesh Grouping, the headset automatically switches from Open Mesh to Group Mesh. Up to 24 users can all be connected in each private group. Group Mesh SPIDER ST1 Motorcycle Mesh Communication System | 24...

  • Page 25: Starting Mesh Intercom

    7 MESH INTERCOM 7.2 Starting Mesh Intercom When Mesh Intercom is enabled, the SPIDER ST1 will automatically connect to nearby SPIDER ST1 users and allow them to talk to each other by pressing the Mesh Intercom Button. Mesh Intercom On Blinking “...

  • Page 26: Using Mesh In Group Mesh

    • The channel will be remembered even if you turn off the SPIDER ST1. • You can use the SENA MOTORCYCLES App to change the channel. 7.4 Using Mesh in Group Mesh 7.4.1 Creating a Group Mesh...

  • Page 27: Joining An Existing Group Mesh

    Note: If the Mesh Grouping is not completed within 30 seconds, the current user (You) will hear a low tone double beep and the new users (D and F) will hear a voice prompt, “Grouping failed”. SPIDER ST1 Motorcycle Mesh Communication System | 27...

  • Page 28: Enable/Disable Mic (Default: Enable)

    Open Mesh and Group Mesh. You will hear a voice prompt, “No Group Available”. 7.7 Reset Mesh If a headset in an Open Mesh or Group Mesh resets the Mesh, it will automatically return to Open Mesh (default: channel 1). HOLD SPIDER ST1 Motorcycle Mesh Communication System | 28...

  • Page 29: Mesh Audio Multitasking (Always On)

    Management settings. The Intercom-Audio Overlay Sensitivity and the Audio Overlay Volume Management settings can be found in the Software Configuration Setting, accessible through the Sena Device Manager or the SENA MOTORCYCLES App. SPIDER ST1 Motorcycle Mesh Communication System | 29...

  • Page 30: Function Priority

    The headset prioritizes connected devices in the following order: (highest) Mobile phone Mesh Intercom (lowest) Bluetooth stereo music A lower-priority function gets interrupted by a higher-priority function. For example, stereo music will be interrupted by an incoming mobile phone call. SPIDER ST1 Motorcycle Mesh Communication System | 30...

  • Page 31: Configuration Setting

    GPS Pairing None Exit Execute 10.2 Software Configuration Setting You can change the settings of the headset through the Sena Device Manager or the SENA MOTORCYCLES App. SENA MOTORCYCLES Sena Device Manager SPIDER ST1 Motorcycle Mesh Communication System | 31...
  • Page 32 Level 1 has the lowest sensitivity and level 5 has the highest sensitivity. Note: If your voice is not louder than the sensitivity of the selected level, the overlaid audio will not be lowered. SPIDER ST1 Motorcycle Mesh Communication System | 32...
  • Page 33 10.2.7 Voice Prompt (Default: Enable) You can disable Voice Prompts by software configuration settings, but the following voice prompts are always on. - Headset configuration settings menu, battery level indicator, speed dial SPIDER ST1 Motorcycle Mesh Communication System | 33...

  • Page 34: Troubleshooting

    11.2 Factory Reset To erase all of your settings and start fresh, the headset can be restored to factory default settings using the Factory Reset feature. HOLD “Factory reset” “ Headset reset, good-bye” SPIDER ST1 Motorcycle Mesh Communication System | 34...
  • Page 35 Hero4 allowing for Bluetooth capabilities. The Bluetooth word mark and logos are owned by the ® Bluetooth SIG, Inc. and any use of such marks by Sena is under license. iPhone and iPod touch are registered trademarks of ®...
