- Page 1 PRT-IPIC-POE-C Protege Vandal Resistant VoIP Intercom with Camera Installation Manual...
- Page 2 Protege® Logo are registered trademarks of Integrated Control Technology Limited. All other brand or product names are trademarks or registered trademarks of their respective holders. Copyright © Integrated Control Technology Limited 2003-2022. All rights reserved. Last Published: 16-Jun-22 9:15 AM PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 3: Table Of Contents
Programming the Intercom Intercom Web Interface Initial setup of the Intercom System System | Information System | Account System | Configurations System | Upgrade System | Auto Provision System | FDMS PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 4 Configuring the Onboard Input as a Protege Input Adding the Intercom Setup in Protege GX Adding the Intercom Setup in Protege WX Trigger a Protege Input with Your Phone PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
- Page 5 Schematic Diagram Wall Mounting Template Technical Specifications New Zealand and Australia European Standards UK Conformity Assessment Mark FCC Compliance Statements Industry Canada Statement Disclaimer and Warranty PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 6: Introduction
All installations are required to meet local wiring regulations and standards. ⦁ There are no user serviceable parts. If the intercom requires servicing or repair, return the unit to ICT. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 7: Power Requirements
WAN port on the intercom PCB board. For more information, see Connections (page 9). Internet Mobile Phone (ip SIP Server audio/video calls) Intercom Intercom IP Desk with camera Optional Entry Station (Optional Phone (Optional Controller Poe) Poe) PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 8: Supported Protocols
⦁ Audio Encodings: ⦁ G.711U (PCMU) G.711A (PCMA) G.722 G.723.1 G.726-32 G.729AB SIP Servers The intercom supports SIP servers that comply with SIP protocol standards including Asterisk and 3CX. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 9: Connections
The relay output can switch to a maximum capacity of 24V DC 1A. Exceeding this will damage the output. Ports WAN Port An RJ45 network port for ethernet (including PoE - Power over Ethernet connection). PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 10: Connection Terminals
By default, only one of the jumper shunts is connected, to ports 2 and 3. To change to active mode relocate the jumper shunts so that ports 1, 2, 3 and 4 are all connected. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 11: Mounting And Installation
Check the contents of the accessory parts supplied: 1x L-shaped hex tool ⦁ 5x 35mm screw anchors (1 spare) ⦁ 5x TA5*40mm screws (1 spare) ⦁ 1x spare M4*16mm screw ⦁ 1x spare PM3*16mm screw ⦁ PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 12 Drill 4 holes over the marks provided on the template. A drill hole depth of 50mm is recommended. Remove the template and insert the screw anchors into the holes. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
- Page 13 Push the front panel carefully into the plastic frame and replace the 6 screws, ensuring the screws have been tightened correctly and the panels are secure to ensure waterproofing. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 14: Flush Mounting Installation
Check the contents of the accessory parts supplied: ⦁ 1x L-shaped hex tool ⦁ 5x 35mm screw anchors (1 spare) ⦁ 5x TA5*40mm screws (1 spare) ⦁ 1x spare M4*16mm screw ⦁ 1x spare PM3*16mm screw PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 15 Place the back panel in the cavity where the intercom will be located and mark the 4 screw holes Drill 4 screw anchor holes as marked. A drill hole depth of 60mm is recommended Insert the screw anchors into the holes PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
- Page 16 Push the front panel carefully into the plastic frame, ensuring the security screws have been tightened correctly and the panels are secure to ensure waterproofing. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 17: Flush Mounting Installation With Kit
Check the contents of the accessory parts supplied: 1x L-shaped hex tool ⦁ 5x 35mm screw anchors (1 spare) ⦁ 5x TA5*40mm screws (1 spare) ⦁ 1x spare M4*16mm screw ⦁ 1x spare PM3*16mm screw ⦁ PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 18 Fill the gaps between the brick box and the wall with cement. Note: this step can be skipped. However it will decrease the anti-punch strength Do not proceed until the cement has set. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
- Page 19 Pull the cable through the cable hole in the back panel, leaving 15-20cm excess cable length. Note: the intercom is equipped with a secondary cable hole at the bottom of the back panel. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
- Page 20 Using 4 M4*35mm screws, attach the intercom into the brick box and seal the gap between the frame panel and wall surface. Push the front panel carefully into the plastic frame, ensuring the security screws have been tightened correctly and the panels are secure to ensure waterproofing. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 21: Hardware Configuration
IP address. Connect to the web interface by entering the IP address into the address bar of your web browser. Log in when prompted: User: admin, Password: admin PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 22: Defaulting The Intercom
Remember to revert the PC back to its original IP address if changed at Step 2. Defaulting the intercom will reset all settings and set the IP address to the default (192.168.1.128) PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 23: Programming The Intercom
Protege system or to be set up for standalone operation. Note: The web interface contains a number of intercom features and configuration settings that are not supported by ICT or the integration, and as such those options are not documented here. Accessing the Web Interface Open a web browser and enter the default IP address of the intercom: 192.168.1.128... -
Page 24: Initial Setup Of The Intercom
In the Number 1 field enter the first number for the intercom to call when the call button is pressed. Select the SIP Line for connection. Set the Subtype to Speed Dial. Click Apply. For additional call button configurations, refer to the Function Key section (see page 40). PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 25: System
Privilege: Select the access level for the new user. Administrators have access to all settings. Users have access to all configuration except user management and SIP server addressing. Click Add to complete adding the new user. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 26: System | Configurations
Click Import to upload the configuration settings to the device. This will take some time as the new configuration is uploaded. The device will then perform a Reboot before prompting you to log in. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 27: System | Upgrade
Some configuration modifications require a system reboot to take effect. Click the Reboot button to perform an immediate reboot on the device. Save the configuration before rebooting. For more information, see System | Configurations (previous page). PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 28: Network
⦁ settings. Service Port Settings Service port settings can be customized to enhance security. These should typically be left at the default settings, unless required by your network administrator. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 29: Network | Vpn
⦁ Click Delete to remove the currently loaded HTTPS certification file. ⦁ Network | VPN This feature is not supported. Network | Web Filter This feature is not supported. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 30: Line
Blocking Anonymous Call: Blocks any incoming call without a recognized caller ID. ⦁ Use 182 Response for Call waiting: Set the 182 response for call waiting. ⦁ Anonymous Call Standard: Selectable settings for SIP privacy protocol standards. ⦁ PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 31 Keep Alive Type: Set the line to use a dummy UDP or SIP Option packet to keep the NAT pinhole open. ⦁ Keep Alive Interval: Set the transmitting interval. ⦁ Sync Clock Time: Synchronize the device time with the server. ⦁ PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 32: Line | Basic Settings
SIP Waiting Time: The waiting time for SIP. This will vary depending on the network. Line | SIP Hotspot This feature is not supported. Line | Blacklist This feature is not supported. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 33: Line | Action Plan
Line | Action Plan This feature is not supported. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 34: Intercom Settings
MIC Input Volume: Configure the microphone volume level for audio when the intercom calls a phone. ⦁ Broadcast Output Volume: The volume level for audio received in phone calls. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 35: Intercom Settings | Video
Day/Night Mode: ⦁ Automatic: Switches according to the DNC Threshold and the brightness of the camera's environment. Day Mode: The camera's video screen is always colored. IRCUT switch will be synchronized. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 36 Main Stream URL: Displays the URL for the Main Stream high definition video camera feed. ⦁ Sub Stream URL: Displays the URL for the Sub Stream lower definition video camera feed. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 37: Intercom Settings | Mcast
This feature is not supported. Intercom Settings | Trusted Certificates This feature is not supported. Intercom Settings | Device Certificates This feature is not supported. This feature is not supported. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 38: Security Settings
Call State Trigger: The output will be triggered when the call state of the intercom matches the selected state. ⦁ The following options can be selected by moving the required state(s) to the Enabled State list. Talking Ringing Calling Calling and Talking PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 39 Server Address: The IP or Domain of the server to send SIP messages to when the input or tamper alarm is triggered. ⦁ Message: The message to be sent when the input or tamper alarm is triggered. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 40: Function Key
Hot Key Dial Mode Select: set to Main-Secondary. Click Apply. Day/Night Operation The intercom can be programmed to call a day number or night number, according to the call time settings. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 41 Hot Key Dial Mode Select: set to Day-Night and click Apply. Configure the Day Start Time and Day End Time. Number 1 will be called inside these hours and Number 2 will be called outside these hours. Click Apply. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 42: Standalone Functionality
To play a tone when the door is unlocked by a code, in the Alert Trigger Setting | Ring section, set the Remote DTMF Trigger to Default. Set the Alarm Ring Duration to the desired duration. Click Apply. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 43: Unlock A Door With Rex
Set the Ring Type to Default to play a tone when a tamper is triggered. Click Apply. The alarm can be stopped via the web interface by clicking Reset Alerting Status. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 44: Protege Integration
Low Level Trigger (Close Trigger). If your input device opens the circuit when activated, set the Trigger Mode to High Level Trigger (Disconnect Trigger). Check Alert message send to server. Click Apply. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 45: Adding The Intercom Setup In Protege Gx
Intercom keypad records can also be added via the Expanders Wizard, however it will not Auto Detect intercoms so they will need to be added manually as Additional Modules. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 46: Trigger A Protege Input With Your Phone
To play a tone when the input is triggered, in the Alert Trigger Setting | Ring section, set Remote DTMF Trigger to Default. Set the Alarm Ring Duration to the desired duration. Click Apply. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 47: Schematic Diagram
Schematic Diagram * Installed with Rain Shade * Installed with optional Flush Mount Kit PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 48: Wall Mounting Template
Wall Mounting Template PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 49: Technical Specifications
223 x 130 x 74mm (8.77 x 5.11 x 2.91") In-Wall 270 x 150 x 61mm (10.6 x 5.9 x 2.4") Net Weight 1400g (49.4oz) Gross Weight 1640g (57.8oz) Environment PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 50 10% to 90% Integrated Control Technology continually strives to increase the performance of its products. As a result these specifications may change without notice. We recommend consulting our website (www.ict.co) for the latest documentation and product information. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 51: New Zealand And Australia
New Zealand and Australia General Product Statement The RCM compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 52: European Standards
Tests EMC (operational) according to EN 55032:2015 Radiated disturbance EN 55032:2015 Power frequency magnetic field immunity tests (EN 61000-4-8) EN50131 In order to comply with EN 50131-1 the following points should be noted: PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... - Page 53 To comply with EN 50131-1 the Bell Cut-Off Time should be programmed between 02 and 15 minutes. EN 50131-1 requires that detector activation LEDs shall only be enabled during Walk Test. This is most conveniently achieved by using detectors with a Remote LED Disable input. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual...
-
Page 54: Uk Conformity Assessment Mark
UK Conformity Assessment Mark General Product Statement The UKCA Compliance Label indicates that the supplier of the device asserts that it complies with all applicable standards. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 55: Fcc Compliance Statements
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 56: Industry Canada Statement
Industry Canada Statement ICES-003 This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. CAN ICES-3 (A)/NMB-3(A) PRT-IPIC-POE-C | Vandal Resistant VoIP Intercom with Camera | Installation Manual... -
Page 57: Disclaimer And Warranty
Integrated Control Technology Ltd nor its employees shall be liable under any circumstances to any party in respect of decisions or actions they may make as a result of using this information. In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice. - Page 58 In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
