GLT-R003-2HDSATA Internal RAID system
Application
GLT-R003-2HDSATA is an internal RAID system.
It allows the user to use two hard disk drives at the same
time in order to mirror the data.
Content
Important Information on Product Safety ...............................................................................................................2
Item........................................................................................................................................................................3
Hardware requirements .......................................................................................................................................3
Requirements for operation and notes ................................................................................................................3
Installing the Hard Disk Drive ..............................................................................................................................4
Installing the Hardware ........................................................................................................................................5
Connecting to the Computer................................................................................................................................8
Setting Mirror Mode (RAID 1) ..............................................................................................................................9
Hard Disk Status on the LCD Display..................................................................................................................9
System Maintenance .........................................................................................................................................10
Rectifying Malfunctions......................................................................................................................................11
Kieback&Peter GmbH & Co. KG
Tempelhofer Weg 50, 12347 Berlin/Germany
Telefon: +49 30 60095-0, Telefax: +49 30 60095-164
www.kieback-peter.de, info@kieback-peter.com
R
Commissioning
GLT-R003-2HDSATA
Page
4.75-10.003-11-EN | 2019-11-12
Advertisement
Table of Contents
Summary of Contents for Kieback&Peter GLT-R003-2HDSATA
-
Page 1: Table Of Contents
Commissioning GLT-R003-2HDSATA GLT-R003-2HDSATA Internal RAID system Application GLT-R003-2HDSATA is an internal RAID system. It allows the user to use two hard disk drives at the same time in order to mirror the data. Content Page Important Information on Product Safety .......................2 Item..................................3... -
Page 2: Important Information On Product Safety
This data sheet contains information on installing and commissioning the product “GLT-R003-2HDSATA”. Each person who carries out work on this product must have read and under- stood this data sheet. If you have any questions that are not resolved by this data sheet, you can obtain further information from the supplier or manufacturer. -
Page 3: Item
Commissioning GLT-R003-2HDSATA Item GLT-R003-2HDSATA Internal RAID System Hardware requirements ■ Computer or server with SATA type 1 & 2 & 3 ■ Hard disk with SATA type 1 & 2 & 3 Requirements for operation and notes ■ The outstanding design of the SATA RAID system allows the user to use two hard disk drives at the same time. -
Page 4: Installing The Hard Disk Drive
Commissioning GLT-R003-2HDSATA Installing the Hard Disk Drive Frontal view LCD display Fail LED Buzzer On/Off HDD1 / HDD2 LED Lock with push button Hard drive carrrier LED HDD hard drive carrier Status Display for the LEDs Status Fail LED HDD1 / HDD2 LED Hard drive carrier LED Buzzer... -
Page 5: Installing The Hardware
Commissioning GLT-R003-2HDSATA Installing the Hardware CAUTION You must remove and connect the hard disks only when the computer is switched off. ► Put the key in the lock and turn it counterclockwise to open the case. Position 1: locked Position 2: unlocked ►... - Page 6 Commissioning GLT-R003-2HDSATA ► Connect the SATA cable on the removable carrier to the connections on the hard disk drive. ► Fix the hard disk drive on the removable carrier using the enclosed screws as displayed in the figure. 4.75-10.003-11-EN | 2019-11-12...
- Page 7 Commissioning GLT-R003-2HDSATA ► Insert the removable carrier into the RAID system. ► Lock the HDD hard drive carrier by turing the key clockwise. Position 1: locked Position 2: unlocked Page 7 / 12 4.75-10.003-11-EN | 2019-11-12...
-
Page 8: Connecting To The Computer
Commissioning GLT-R003-2HDSATA Connecting to the Computer CAUTION You must fit and remove the connections only when the computer is switched off. 45 cm SATA cable Network cable ► Connect the power and SATA connection to the computer. Power supply is either via the SATA power connector or via the 4-pin power connector. -
Page 9: Setting Mirror Mode (Raid 1)
Commissioning GLT-R003-2HDSATA Setting Mirror Mode (RAID 1) Installing two completely new hard disk drives ► Insert the two new hard disk drives into the RAID system at the same time. ► Switch on the computer. Installing one new hard disk drive and one hard disk drive with existing data We strongly recommend installing drives of the same manufacturer brand and the same memory capacity in your RAID system. -
Page 10: System Maintenance
Commissioning GLT-R003-2HDSATA System Maintenance Quick Switch and Automatic Restore Offline Backup If the data on the RAID system is saved, you can remove the backup drive. Within a specific time period, you can now insert the hard disk into the RAID system and perform an automatic backup. This allows you to protect the system and prevent both hard disks from failing at the same time. -
Page 11: Rectifying Malfunctions
Commissioning GLT-R003-2HDSATA Rectifying Malfunctions The system is unstable after installing and connection the RAID system Cause ■ After the installation, the computer restarts. ■ The computer does not detect the Raid system after it starts. Repair ■ Check the display on the LCD display. - Page 12 Commissioning GLT-R003-2HDSATA Automatic restore function Cause ■ What happens if the energy supply of the computer is interrupted while the SATA RAID system is automatically restoring the data? Repair ■ If you are in mirror mode (RAID 1) and the energy supply is switched off during an automatic restore process, the control automatically detects the percentage of the restore process that is complete.
