Summary of Contents for McElroy TP-300 Series
- Page 1 Operator’s Manual Test Caps TP-300 Series Manual: TP-901 Revision: E 1/14...
-
Page 2: Limited Warranty
McElroy or has become damaged McElroy reserves the right to make any changes in or due to misuse, negligence or casualty, or has not been improvements on its products without incurring any operated or maintained according to McElroy’s printed... -
Page 3: Safety Alerts
Follow all applicable federal, state, local, and industry specific regulations. McElroy Manufacturing, Inc. cannot anticipate every possible circumstance that might involve a potential hazard. The warnings in this manual and on the machine are therefore not all inclusive. -
Page 4: General Safety
Safety General Safety Safety is important. Report anything unusual that you notice during set up or operation. LISTEN for thumps, bumps, rattles, squeals, air leaks, or unusual sounds. SMELL odors like burning insulation, hot metal, burning rubber, hot oil, or natural gas. FEEL any changes in the way the equipment operates. -
Page 5: Operation
Operation Introduction Thank you for purchasing this McElroy product. The TP-300 Series Test Caps are designed for quick and easy air pressure testing testing of Polyethylene pipe. The many features include: • Quick installation and removal • Pressure rated to 165 psi •... -
Page 6: Insertion Depth
Operation Insertion Depth Measure and mark the insertion depth on the pipe before installing the test cap to ensure proper set up. The gauge line (Caption “A” of diagram) on the outside of the test cap, is used for correctly marking the pipe to its proper insertion depth To correctly mark the insertion depth, place the pipe alongside the test cap, marking the length from the gauge line (A) to the end of... - Page 7 Operation Install Test Cap Check the end of the pipe to be tested. Make sure the outside of the pipe is free of dirt and scratches that would prevent an airtight seal. Slide the pipe ring (stamped with the pipe size) on to the pipe first.
-
Page 8: Preventive Maintenance
Operation Bleed All Pressure Bleed all pressure from the test line. Verify that all pressure has been bled by reading the gauge. The gauge should read zero psi. Always relieve pressure before removing test cap. This test equipment uses high pressure air which can cause severe injury or death from flying parts. - Page 11 Other McElroy Services www.mcelroy.com McElroy strives to stay on the leading edge of technology and innovation in the industry. Providing our customers with the tools to succeed is our number one priority. McElroy's web site has raised the standard for the fusion industry. We provide...
