KEEP FOR FUTURE REFERENCE
INSTRUCTIONS
MANUAL
INTENDED FOR USE BY SKILLED
TECHNICAL PROFESSIONALS • READ AND
UNDERSTAND BEFORE INSTALLING AND USING
MRT4 ADAPTABLE-LENGTH LIFT BAR
Stock number: 95723
Rev 3.0/7-21
1
908 W. Main • P.O. Box 368
Laurel, MT USA 59044
800-548-7341 (phone)
406-628-8231 (phone)
406-628-8354 (fax)
www.WPG.com
#35202AFT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WPG MRT4
Summary of Contents for WPG MRT4
- Page 1 908 W. Main • P.O. Box 368 Laurel, MT USA 59044 800-548-7341 (phone) 406-628-8231 (phone) 406-628-8354 (fax) INTENDED FOR USE BY SKILLED www.WPG.com TECHNICAL PROFESSIONALS • READ AND UNDERSTAND BEFORE INSTALLING AND USING MRT4 ADAPTABLE-LENGTH LIFT BAR Stock number: 95723 Rev 3.0/7-21 #35202AFT...
- Page 2 #35202AFT Rev 3.0/7-21...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS ..................2 FEATURES....................3 INSTALLATION ..................4 ..........4 NSTALL THE DAPTABLE ENGTH ASSEMBLY....................5 ..........5 ELECT THE PPROPRIATE ONFIGURATION ............6 P THE HORT ONFIGURATION ............6 P THE ONFIGURATION REPLACEMENT PARTS................7 LIMITED WARRANTY ................8 .............8 BTAIN EPAIRS OR ARRANTY ERVICE Rev 3.0/7-21 #35202AFT... -
Page 4: Specifications
SPECIFICATIONS This lift bar is designed for applications requiring increased horizontal reach at the lift point or Product applications involving minimal clearance between the lifter and the hoisting equipment, such as Description installations under eaves, gables or overhangs. Stock Number 95723 with Long with Long Reversed... -
Page 5: Features
FEATURES Features shown here are underlined on their first appearance in each section following. LIFT POINT LOWER LIFT BAR SEGMENT UPPER LIFT BAR SEGMENT 1/2-13 x 4" HEX HEAD BOLT (2x) 1/2-13 HEX NUT 1/2" LOCK WASHER 1/2" FLAT WASHER 1/2-13 x 4½"... -
Page 6: Installation
INSTALLATION NSTALL THE DAPTABLE ENGTH 1) Remove the original lift bar from the vacuum lifter: 1.1) Remove the cotter pin (A) from the end of the tilt pin (B). 1.2) Remove the hex head bolt (C) and its washer from the opposite end. This will enable you to slide the tilt pin out from the center section (D). -
Page 7: Assembly
ASSEMBLY ELECT THE PPROPRIATE ONFIGURATION Before suspending the vacuum lifter from hoisting equipment as directed in the “ASSEMBLY” section of the lifter's OPERATING INSTRUCTIONS, assemble the Adaptable-Length Lift Bar in the appropriate configuration for the intended use. Note: When the lift point is reversed and/or the Adaptable-Length Lift Bar is shortened or lengthened, make sure that the lifter still has sufficient load capacity for the intended use. -
Page 8: T O Set U P The Short Configuration
ASSEMBLY P THE HORT ONFIGURATION Remove the two 4½" hex head bolts and associated hardware (items A in fig. 1A) that secure the lift point the upper lift bar segment. 1) Remove the lift point from the segment. 2) Remove 4" hex head bolts and associated hardware (items B in fig. -
Page 9: Replacement Parts
12760 1/2" Split Lock Washer 11124 1/2-13 Hex Nut 10858 1/2-13 x 4-1/2" Hex Head Bolt 10854 1/2-13 x 4" Hex Head Bolt ERVICE ONLY WITH IDENTICAL REPLACEMENT PARTS WPG.COM AVAILABLE AT OR THROUGH AN AUTHORIZED DEALER Rev 3.0/7-21 #35202AFT... -
Page 10: Limited Warranty
Contact the WPG Technical Service Department. When factory service is required, ship the complete product – prepaid – along with your name, address and phone number to the street address listed at the bottom of this page. WPG may be reached by phone or fax numbers listed below.
