  • Page 1 IES618 series Managed Industrial Ethernet Switch CLI user manual Version 1.0.0, Sep. 2017 www.3onedata.com...
  • Page 2 Trademarks Notice is registered trademarks of 3onedata Co.,Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Agreement As the product version upgrades or other reasons, this document is subject to change without notice.

  • Page 3: Table Of Contents

    CLI user manual Content Chapter 1 Login Ethernet Switch ................................1 1.1 Configuration through console port ............................1 1.2 Configuration through Telnet ..............................4 1.3 Agreement ....................................5 1.4 Command line port ..................................6 1.4.1 View of Command Lines ..............................6 1.4.2 Command lines Online help ...............................
  • Page 4 CLI user manual 6.3 Vlan information view ................................21 6.4 Enter the port configuration view based on Vlan ........................22 6.5 Enter configuration view based on 802.1QVlan ........................23 Chapter 7 Static Multicast filtering view ............................. 24 7.1 Enter the multicast filtering view .............................. 24 7.2 Add /Delete static multicast address ............................
  • Page 5 CLI user manual 14.1 Enter the port mirroring view ..............................39 14.2 Port mirroring configuration / delete ............................39 14.3 Display port mirroring information ............................39 Chapter 15 System management ............................... 40 15.1 Enter the System management configuration view ......................40 15.2 System timeout ..................................

  • Page 6: Chapter 1 Login Ethernet Switch

    CLI user manual Chapter 1 Login Ethernet Switch 1.1 Configuration through console port 1. Connection switches to configure terminal As shown in Figure 1.1.1, the establishment of the local configuration environment, only the computer serial cable and connected to the Console port of the Ethernet switch. (Figure 1.1.1) This cable is used for connecting the switch Console port and the external monitoring terminal equipment.
  • Page 7 CLI user manual (Figure 1.1.3) 2) Choose connecting serial port. Choose connecting serial port under “Connect using”（pay attention to the chosen serial port is consistent with the port connected with the configuration cable）, Click “OK”. As shown in Figure 1.1.4. (Figure 1.1.4) 3) Set serial port parameters.
  • Page 8 CLI user manual (Figure 1.1.5) 4) Hyper terminal attribute. In the Hyper Terminal window select [document / property / setting] into the attributes settings window. Select the terminal simulation of type VT100 or automatic detection, click < OK > button to return to the hyper terminal window. (Figure 1.1.6)

  • Page 9: Configuration Through Telnet

    CLI user manual 5) For the switch power, power after the hyper terminal display Ethernet switch self-test information, after the prompt the user to type the carriage return, until the emergence of <user name> command prompt, this time to enter the correct username and password, enter the switch system mode can be configured, the specific configuration commands refer to the later chapters of the contents of the book in.

  • Page 10: Agreement

    CLI user manual 3） Hit “Enter”, checkout successful and till PC show“Please input hostname and password”, ask user to input user name and password, default is admin, figure 1.2.3 as follows: (Figure 1.2.3) 4） Use command to configure the switch and check the running statues, if need help, please input“?”...

  • Page 11: Command Line Port

    CLI user manual 1.4 Command line port The switch provide command lines port and its configuration for user’s easy configuration and management. Command lines port includes the following features: 1. Local configuration through Console port; 2. Supports history command saving which means it can save 10 pieces. History commands can be selected by up and down key.
  • Page 12 CLI user manual Table 1.4.1 system view command list View Function DOS Prompt Enter Quit Quit and return to System View Switch# user login Show or modify device LLDP information, like LLDP Switch(LLDP)# LLDP parameter, neighbor etc. Show or modify device Switch Information information, like software...

  • Page 13: Command Lines Online Help

    CLI user manual View or modify the alarm information, such Switch (Alarm)# Alarm Relay Warning power alarm, and port alarm. Port to receive the frame Switch(Statistic and the total amount of Statistics Port Statistics data statistics View or modify the mirror Switch (mirror)# Mirror Diagnosis...

  • Page 14: Frequent Incorrect Information Of Command Lines

    CLI user manual Trunk <dir> --Enter Trunking setting menu Snmp <dir> --Enter snmp setting menu Alarm <dir> --Enter alarm setting menu Statistics <dir> --Enter statistics menu Mirror <dir> --Enter port mirror menu Manage <dir> --Enter system manage menu Multicast <dir> --Enter static multicast filters menu Information <dir>...

  • Page 15: History Command

    CLI user manual English incorrect information Reason Command cannot be found. Key word cannot be found. Invalid Command The type of parameter is wrong. The parameter is beyond the border. Incomplete Command Command is not completed. Too many parameters Parameter is too much. 1.4.4 History command Command lines port can provides the function similar to Dos key.

  • Page 16: Chapter 2 Device System Based Information Configuration

    CLI user manual CHAPTER 2 Device system based information configuration Device information includes Device Type, Hardware Version, Device Name, Software Version, Device Description, Device SN and Contact Way. Among them, Hardware Version and Software Version can be only read, not modified. 2.1 Enter into the view of device information Please check the view as figure 2.1.1 Table 2.1.1...

  • Page 17: Configuration Information

    CLI user manual 2.3 Configuration information Please reference user configuration device information as table 2.3.1: Table 2.3.1 Operating Command Description Type: configurable type, the length is config –t type Configure Device Type between 1～16 characters Name: configurable name, the length is Configure Device Name config -n name between1～16 characters...
  • Page 18 CLI user manual Example: Delete Contact information, enter the bold type command as follows and enter return key: Switch(information)# clean -c [OK]...

  • Page 19: Chapter 3 Port Configuration

    CLI user manual Chapter 3 Port Configuration Port information including link state (link or LOS), the port state (full or half), rate mode (automatic negotiation, 10Mbps, 100Mbps), interface type (electric or optical), flow control, port is enabled. 3.1 Port information The Ethernet port characteristics of the switches support: 10/100Base-Tx Ethernet port can operate in half duplex, full duplex, auto negotiation mode.

  • Page 20: To Enable Or Disable The Port

    CLI user manual 3.4 To enable or disable the port The user can use the following command to open or close the port. By default, the port is enabled. Table 3.4.1 to enable or disable the port: Table 3.4.1 Operating Command Description switch...

  • Page 21: Chapter 4 Bandwidth Management

    CLI user manual Chapter 4 Bandwidth Management 4.1 Enter rate management view Bandwidth allocation including: 1. Entrance velocity distribution; 2. The outlet velocity distribution; 3. Check the entrance rate configuration information; 4. Check the export rate of configuration information; Table 4.1.1 in bandwidth management view: Operating Command Description...

  • Page 22: Ingress Bandwidth Configuration

    CLI user manual 4.3 Ingress bandwidth configuration By default, Ingress bandwidth does not limit. Table 4.3.1 Ingress bandwidth configuration: Table 4.3.1 Operating Command Description <portlist>: 1,3,5-8 or all Config inrate <portlist> Ingress <Bandwidth>: <low_bw> <normal_bw> bandwidth (128k,256k,512k,1M,2M,4M,8M) <medium_bw> <high_bw> 0: unlimited Example: set the 1 and 2 port of Ingress bandwidth is Low priority for 1M, general priority is 2M, Medium priority for 4M, higher priority for the 8M.
  • Page 23 CLI user manual port 2 port 3 unlimited unlimited unlimited unlimited...

  • Page 24: Chapter 5 Igmp

    CLI user manual Chapter 5 IGMP 5.1 The contents of IGMP configuration The IGMP configuration including: 1. Enable IGMP snooping 2. Enable the IGMP query 3. The query time setting 4. Check the MAC address table Table 5.1.1 into IGMP view command: Table 5.1.1 Operating Command...

  • Page 25: Check The Mac Address Table

    CLI user manual 5.5 Check the MAC address table Table 5.5.1 Check the MAC address table command: Table 5.5.1 Operating Command Description Check the MAC address table Show MAClist Example: Switch(Igmp)# show MAClist IGMP Snooping query time 125 seconds [ 1] MAC List: 01-00-5E-00-00-FB Port: 5 [ 2] MAC List: 01-00-5E-00-00-FC Port: 5 [ 3] MAC List: 01-00-5E-7F-FF-FA Port: 5,6 [ 4] MAC List: 01-00-5E-00-00-FD Port: 5...

  • Page 26: Chapter 6 Vlan

    CLI user manual Chapter 6 VLAN 6.1 Introduction to VLAN VLAN (Virtual Local Area Network) is a virtual local area network, is a kind of device by LAN logical rather than physical division into a network, in order to achieve the virtual group technology.

  • Page 27: Enter The Port Configuration View Based On Vlan

    CLI user manual 6.4 Enter the port configuration view based on Vlan Table 6.4.1 to enter the port configuration view based on vlan: Operating Command Description <vid>: VLAN ID:1-4095 <portlist>: 1,3,5-8 or all 0 --CPU port Add Vlan Add <vid> <portlist> <typelist> <typelist>: UnModified | UnTagged | Tagged Delete Vlan...

  • Page 28: Enter Configuration View Based On 802.1Qvlan

    CLI user manual 6.5 Enter configuration view based on 802.1QVlan Table 6.5.1 into the 802.1Q Vlan configuration based view: Operating Command Description <portlist>: 1,3,5-8 or all 0 --CPU port Pvid setting config pvid <portlist> <pvid> <pvid>: 1,3,5-8 or all 0 --CPU port config type <portlist>...

  • Page 29: Chapter 7 Static Multicast Filtering View

    CLI user manual Chapter 7 Static Multicast filtering view 7.1 Enter the multicast filtering view Static multicast configuration includes: 1. Add static multicast address; 2. Delete the multicast address; 3. Display the multicast address; Table 7.1.1 into the static multicast view command: Operating Command Description...

  • Page 30: Chapter 8 Qos

    CLI user manual Chapter 8 QoS 8.1 Enter the multicast filtering view QoS configuration includes: 1. Enable Tos, Cos 2. Qos queue mechanism settings（8:4:2:1, high priority first） 3. Cos/Tos value mapping 4. Default port priority 5. Show configuration information of QoS Table 8.1.1 to enter the Qos configuration view: Operating Command...

  • Page 31: The Value Of Dscp/Tos Mapping

    CLI user manual 8.4 The value of Dscp/Tos mapping The user can use the following command to configure the Dscp/cos value map Table 8.4.1 Dscp/cos mapping configuration command: Operating Command Description <coslist>: CoS Mapping value, 0, 1, 2-7 The value of Cos Config cos <coslist>...
  • Page 32 CLI user manual Operating Command Description To view the default port Show default <portlist>: port 1, 2, 3-8 or all priority <portlist>...

  • Page 33: Chapter 9 Ring Configuration

    CLI user manual Chapter 9 Ring configuration 9.1 Enter the ring network configuration view The ring network configuration including: 1. The Ring3 configuration; 2. Ring network information view; 3. The RSTP configuration 4. RSTP state information view Table 9.1.1 into the ring network configuration view: Operating Command Description...

  • Page 34: The Ring1 Configuration

    CLI user manual 9.4 The Ring1 configuration User can use the following command to configure SWRing 1 after enabling it. SWRing1 configuration: Operating Command Description Open Enable1 1: Open swring1 SWRing1 Configure <portlist>: Ring Port Config ring1 <portlist> SWRing1 Example: Configure Port 3 and 4 to be Ring Port of SWRing1. Switch(Ring)# Enable ? {1|2|3|4} --Enable Ring I...

  • Page 35: The Ring3 Configuration

    CLI user manual Example: Configure Port 7 and 8 to be the Ring Ports of the first group in SWRing2, Ring ID is 225, hellotime is 0, single ring. Switch(Ring)# Enable 2 [OK] Tip: This configuration will be validated after restarting Switch(Ring)# config ring2 1 255 0 7,8 0 [OK] Tip: This configuration will be validated after restarting...

  • Page 36: The Rstp Configuration

    CLI user manual {1|2|3|4} --Enable SW-Ring I --Enable SW-Ring II --Enable SW-Ring III -- Enable Rstp Switch(Ring)# Enable 3 [OK] Tip: This configuration will be validated after restarting Switch(Ring)# config ring3 1 1 1 7,8 0 [OK] Tip: This configuration will be validated after restarting Example: to modify the first groups in SWRing3 ring network ports 5, 6 Switch(Ring)# modify 1 -p 5,6 [OK]...
  • Page 37 CLI user manual Operating Command Description <pathcost> --Port pathcost Range [0-200000000] <portpriority> --Port portpriority Config rstp_port{1|2|3|4|5|6|7|8 } {0|16|32|48|64|80|96|112|128|144|160| <pathcost> <portpriority> <p2p> 176|192|208|224|240} <edge><enable> <p2p> --Port p2p {no|yes|auto} <edge> --Port edge {no|yes} <enable> --Port enable {no|yes} <options> --modify priority {0|4096|8192|12288|16384|20480| 24576|28672|32768|36864|40960|45056| 49152|53248|57344|61440} Modify rstp _state <options>...
  • Page 38 CLI user manual Switch(Ring)# Config rstp_port 1 20000 128 auto yes yes [OK] Tip: This configuration will be validated after restarting Switch(Ring)# Modify rstp _port –c 30000 [OK] Tip: This configuration will be validated after restarting...

  • Page 39: Chapter 10 Trunk Configuration

    CLI user manual Chapter 10 Trunk configuration 10.1 Enter the port Trunk view Port Trunk configuration includes: 1. Port trunk configuration; 2. Delete port information fusion; 3. Port trunk information view; Table 10.1.1 to enter the port trunk view: Operating Command Description To perform the operation in the...

  • Page 40: Chapter 11 The Snmp Configuration

    CLI user manual Chapter 11 The SNMP configuration 11.1 Configure the view into the SNMP The Snmp configuration including: 1. Close the Snmp 2. To view the Snmp configuration information 3. The Snmp configuration Table 11.1.1 to enter the Snmp configuration view: Operating Command Description...

  • Page 41: Chapter 12 Alarm Configuration

    CLI user manual Chapter 12 Alarm configuration 12.1 Enter the alarm information view Alarm configuration including: 1. Power alarm; 2. Port alarm; 3. Delete alarm information; 4. Alarm information view; Table 12.1.1 enter the alarm configuration view: Operating Command Description Enter the alarm configuration To perform the operation in the system Alarm...
  • Page 42 CLI user manual Operating Command Description {1|2|all}: Show the way power alarm Show power alarm 1: The first power supply； Show power {1|2|all} information 2: The second way power Only applicable to DC Show port alarm Show port <portlist> <portlist>: Alarm ports 1, 2, 3-8 or all information Show alarm output Show type...

  • Page 43: Chapter 13 Port Statistics

    CLI user manual Chapter 13 Port Statistics 13.1 Enter the port statistical configuration view Port statistics: 1. Statistics port number and type 2. Clean up the count the number of frames 3. Statistics port flow 4. Clean up the total flow 5.

  • Page 44: Chapter 14 Port Mirroring

    CLI user manual Chapter 14 Port mirroring 14.1 Enter the port mirroring view Port mirroring configuration includes: 1. Port mirroring configuration; 2. Delete port mirroring; 3. View port mirroring; Table 14.1.1 to enter the port mirroring configuration view: Operating Command Description Enter the port mirroring configuration To perform the operation in the...

  • Page 45: Chapter 15 System Management

    CLI user manual Chapter 15 System management 15.1 Enter the System management configuration view System management includes: 1. System timeout; 2. The default gateway, IP address configuration; 3. The user name, password configuration; 4. Device IP, subnet mask, default gateway, see; 5.

  • Page 46: User Name, Password Settings

    CLI user manual Operating Command Description device <A.B.C.D>: ip address address Ip <A.B.C.D> <A1.B1.C1.D1> <A1.B1.C1.D1>: The subnet mask configuration The default gateway <A.B.C.D>: The gateway address Gateway <A.B.C.D> configuration Example: the equipment configuration for 192.168.254 IP 255.255.255.0, subnet mask, default gateway for 192.168.1.1 Switch(Manage)# ip 192.168.1.254 255.255.255.0 [OK]...

  • Page 47: Restore Factory Settings

    CLI user manual Device DNS address : 202.96.134.133 15.6 Restore factory settings The user can restore to factory settings following command equipment Table 15.6.1 restores factory settings command: Operating Command Description Restore the device to To perform the operation in the system Restore factory settings manage...

  • Page 48: Chapter 16 Lldp Setting

    CLI user manual Chapter 16 LLDP Setting 16.1 Enter LLDP settings view Operating Command Description Enter LLDP settings view Execute in system view LLDP Switch# LLDP Switch(Lldp)# ? List --List commands of current menu Help --Help commands of current menu Quit --Quit from CLI Exit...
  • Page 49 CLI user manual Operating Command Description Print remote machine's Print neighbors infomation Print lldp statistics local print local Run in view of LLDP System counters Clear lldp statistics local clear counters Switch(Lldp)# show Lldp Configuration:Enable Lldp Configuration of sending PDU: Tx Interval: 30 seconds Tx Hold: Tx Delay:...
