- Page 1 ITEM No.:A101010800 WE HAVE YOU IN MIND, LET US SERVE YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com 1-(866)-578-6569 Country of Origin: China Production Number: xxxxxxxxxx...
-
Page 2: Hardware Pack
2 / 7 ∙ Hardware Pack H06015C11 M6 * 15 Bolt 8PCS H06030C11 M6 * 30 Bolt 8PCS H19002C11 M6 Flat Washer 16 PCS H14001C11 M6 Nut 8 PCS P90804B07016 M6*20 8 PCS P90804B07016 M6*15 16PC P12401B01001 Stake 8PCS P90701A07001 Mosquito Netting Hook 32PCS H00002C12... - Page 3 3 / 7 ∙ Middle beam P000501135 bottom connector P000501136 Big top connector P005700645 Netting rod Big top adjustable P005700643 tube Small top P005700644 adjustable tube P005700606 Mosquito netting P001100509 Small canopy P001100508 Big top canopy Fig.4 Step1 Fig.7 Fig.8 Fig.5 Fig.1 Fig.6...
- Page 4 4 / 7 ∙ Fig.1-1 Fig.1-2 Fig.2 CC DD Fig.1-1:Insert across beam 1（C）into across beam 2（D）. Fig.1-2: Attach netting rod（I） 、middle beam bottom connector（G）to across beam 1/2（C/ D）and fix by using bolt (FF). Fig. 2：Attach base plate(B) to bottom post（A）fix by using bolt（DD）and flat washer（CC）. Fig.4 Fig.5 Fig.3...
- Page 5 5 / 7 ∙ Step2 Fig.9 Fig.10 Fig.9 Fig.1 Fig.8：Place small canopy four corner（M）to small top adjust tube（K）. Fig.9: Place big canopy four corner（N）to big top adjustable tube（J）. Country of Origin: China...
- Page 6 6 / 7 ∙ Step3 Fig.10-2 Fig.11 Fig.10-2 Fig.11 Fig.10-1 Fig.10-1: Put ring（HH）through mosquito netting loop（L），hang mosquito netting to mosquito rod（I）. Fig.10-2: Fix mosquito netting bandage（L） to post（A）. Fig.11: Put the stake（GG）through base plate（B）and fix on ground. Country of Origin: China...
-
Page 7: Care And Maintenance
Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a period of 6 months from the date of purchase, provided the item was factory‐sealed at the time of purchase and is maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within this warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of purchase; however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly of the item, remain the responsibility of the ...
