  • Page 1 Lighting LED, T5, Hybrid LED+T5 User Manual cloud ver. 2.0 PS Cloud Interface www.Pacific-Sun.eu...

  • Page 2: Table Of Contents

    4.1. Althea T5 Hybrid LED + T5 lamp ................12 4.2. Pandora Hyperion R2+ ....................14 4.3. Pandora Hyperion S ....................16 5. Lamp Wi-Fi Pacific Sun Cloud setup ..........19 5.1. Connecting Lamp to your home Wi-Fi network ............19 5.2. Adding Lamp to Pacific Sun Cloud ................21 5.3.

  • Page 3: Introduction

    1. Introduction Dear Customer, Thank you for purchasing the Pacific Sun Lighting. With the purchase of this unit, you have selected a top quality product. It has been specifically designed for aquaristic purposes and has been tested by experts. With this unit, you are able to adjust light source in your saltwater tank simply and efficiently in order to achieve optimum light levels and coal health.

  • Page 4: Led Lighting

    Lighting - LED, T5, Hybrid LED+T5 2. LED lighting 2.1. Alpha LED lamp 215W With 11 years of experience in LED lamps research, development and production, we have designed and created Alpha – the best available LED light source for your marine aquarium.
  • Page 5 Lighting - LED, T5, Hybrid LED+T5 LED Configuration Details Violet Prolight 405nm 22.5W Cool White Cree XB-D Royal Blue 450nm XB-D Cree Blue Cree 465nm XB-D Royal Blue Cree 450nm XB-D Cyan/Green – Prolight/Cree X-PE Amber/Red/Photo Red Cree XP-E 585/625/650nm Prolight UV 435nm 22.5W Specification...
  • Page 6 Completely silent passive cooling – no more fans maintenance or replacement. Specially designed glass to reduce light emission limitations and spectrum changes. Easy to use Cloud-based application on every available Pacific Sun device through any web browser – no need to install any additional separate applications.

  • Page 7: Metis Hyperion R2

    LED channels and an extraordinary visual experience – very strong shimmer on the bottom of the aquarium comparable to metal halide. The Pacific Sun lamp has been designed as a pendant lamp for open aquariums. It must not be used in enclosed aquariums below the canopy.
  • Page 8 850 x 130 x 50 1250 x 130 x 50 1650 x 130 x 50 LED panels specification • UV (400 and 420nm) – Made for Pacific Sun • Royal Blue 450nm – Cree • Royal Blue 465nm – Cree • Blue – Cree •...

  • Page 9: Metis Hyperion S/S2

    – very strong shimmer at the bottom of the aquarium comparable to metal halide. Pacific Sun lamp has been designed as a pendant lamp for open aquariums. It must not be used in enclosed aquariums below the canopy.
  • Page 10 • “Ultra Quiet” 80mm fans controlled by a temperature sensor. • Mounting: Hanging kits LED panels specification • UV (400 and 420nm) – Made for Pacific Sun • Royal Blue 450nm – Cree • Royal Blue 465nm – Cree • Blue – Cree •...

  • Page 11: T5 Lighting

    Lighting - LED, T5, Hybrid LED+T5 3. T5 lighting 3.1. Althea T5 A totally new T5 fixture with ultra-efficient cooling and Wi-Fi on-board. The Althea will guarantee your chosen tubes will work at 100% efficiency and even tell you when they need replacing.

  • Page 12: Hybrid Led+T5 Lamps

    Lighting - LED, T5, Hybrid LED+T5 4. Hybrid LED+T5 lamps 4.1. Althea T5 Hybrid LED + T5 lamp Page 12...
  • Page 13 Lighting - LED, T5, Hybrid LED+T5 A modified version of original Althea T5 – with two pairs high efficiency LED strips for additional corals fluorescence instead of pair of T5 bulbs. Althea Hybrid T5 fixture have ultra-efficient cooling and Wi-Fi controller on-board. The Althea will guarantee your chosen tubes will work at 100% efficiency and even tell you when they need replacing! Ultra efficient cooling via the inbuilt 120mm low speed fans keep the ballasts and tubes...

  • Page 14: Pandora Hyperion R2

    The SMT provides the perfect mix of colors all LED channels and an extraordinary visual experience – very strong shimmer at the bottom of the aquarium comparable to metal halide. Pacific Sun lamp has been designed as a pendant lamp for open aquariums. It must not be used in enclosed aquariums below the canopy.
  • Page 15 • Mounting: Hanging kits or Pacific Sun “Spider” mount • lamps have protection glass LED panels specification • UV (400 and 420nm) – Made for Pacific Sun • Royal Blue 450nm – Cree • Royal Blue 465nm – Cree • Blue – Cree •...

  • Page 16: Pandora Hyperion S

    – very strong shimmer at the bottom of the aquarium comparable to metal halide. Pacific Sun lamp has been designed as a pendant lamp for open aquariums. It must not be used in enclosed aquariums below the canopy. Page 16...
  • Page 17 Lighting - LED, T5, Hybrid LED+T5 Weight Lamp Size LED Panels + T5 [mm] [kg] 1 + 2 x T5 600 x 320 x 50 2 + 4 x T5 900 x 450 x 50 3 + 4 x T5 1250 x 450 x 50 4 + 4 x T5 1650 x 450 x 50...
  • Page 18 • “Ultra Quiet” 80mm fans controlled by a temperature sensor. • Mounting: Hanging kits or Pacific Sun “Spider” mount LED panels specification • UV (400 and 420nm) – Made for Pacific Sun • Royal Blue 450nm – Cree • Royal Blue 465nm – Cree •...

  • Page 19: Lamp Wi-Fi Pacific Sun Cloud Setup

    Lighting - LED, T5, Hybrid LED+T5 5. Lamp Wi-Fi Pacific Sun Cloud setup 5.1. Connecting Lamp to your home Wi-Fi network 1. Connect power to the PS device. Find your PS DEVICE on you Wi-Fi network list devices. Click Connect directly to the PS DEVICE Wi-Fi Network.
  • Page 20 Lighting - LED, T5, Hybrid LED+T5 5. Open the Device WiFi network setup. Open your Internet Browser and type the device WiFi network into the IP address 192.168.4.1 address field. http://192.168.4.1 Switch to STA+AP mode Under WiFi Association you should see Scanning for available home Wi-Fi networks.

  • Page 21: Adding Lamp To Pacific Sun Cloud

    Lighting - LED, T5, Hybrid LED+T5 5.2. Adding Lamp to Pacific Sun Cloud Connect to your home Wi-Fi internet network, open Internet Browser, and go to the following address: https://cloud.pacific-sun.eu Click Create an account Note: If you already have PS account...
  • Page 22 Under your tank Name: Click Add Device Type In your preferred Name and select one of the Lamp from the list: Kore 7 Kore 5 Calcfeeder PRO WiFi Pacific Sun Power Module Althea Alpha Hyperion Click Add Device Page 22...
  • Page 23 Lighting - LED, T5, Hybrid LED+T5 Under your Client ID: Click Auto Connect Connect Lamp to Pacific Sun Cloud: Step Click Next Configure device and Ready: Step Use your Lamp IP address Click Configure! Note: Optionally you can see the IP address on the...
  • Page 24 Lighting - LED, T5, Hybrid LED+T5 Added Lamp main settings panel: Light percentage - LED intensity T5 channels schedule - for each 2 x T5 channel T5 Lifetime - time from the first T5 installation Atmospheric settings Moonlight settings Manual control - LED channels intensity Page 24...

  • Page 25: Setting Up Light Profile

    Lighting - LED, T5, Hybrid LED+T5 5.3. Setting Up Light Profile Available two OPTIONS to setup Light Profiles: Add and design your own, new profile Import/modify profile from other users 5.3.1. OPTION 1 - Add new Light Profile Add and design your own, new profile: Go to My Light Profiles Click Type in your preferred lamp Name...
  • Page 26 Lighting - LED, T5, Hybrid LED+T5 Basic Light Chart: Option to Share Public extra Node to the chart: Click on the Chart COLOR Select you want to add a new node to Click Add node Page 26...
  • Page 27 Lighting - LED, T5, Hybrid LED+T5 Modify the new node: Select and Move/Adjust COLOR Optionally for an easier nodes adjustment, you can hide any chart line: COLOR Click any to hide the line After editing click Save Page 27...
  • Page 28 Lighting - LED, T5, Hybrid LED+T5 Saved new Light Profile: Created Light Profile Send the Light Profile to Lamp: Go to you Tank > > Light Lamp Click the Light Profile Send to Lamp Optionally you can edit again your Light Profile and Send to Lamp Page 28...

  • Page 29: Option 2 - Import/Modify Profile From Other Users

    Lighting - LED, T5, Hybrid LED+T5 5.3.2. OPTION 2 - Import/modify profile from other users Import/modify profile from other users Go to My Light Profiles Click Select preferred Cloud Light Profile Select one of the lamp profile Type in your preferred lamp program Name Click Page 29...
  • Page 30 Lighting - LED, T5, Hybrid LED+T5 Optionally modify imported Cloud Light Profile: Select and Move/Adjust any node Option to Share Public Saved Light Profiles: Imported Previously created Page 30...
  • Page 31 Lighting - LED, T5, Hybrid LED+T5 Send the Light Profile to Lamp: Go to you Tank > > Light Lamp Click the imported Light Profile Send to Lamp Optionally you can edit again your imported Light Profile and Send to Lamp Page 31...

  • Page 32: Linking Lamp With Kore 7Th Khlab

    Lighting - LED, T5, Hybrid LED+T5 5.4. Linking Lamp with Kore 7th kHLab Pacific Sun Cloud is giving all users the opportunity to add all Wi-Fi PS Cloud-ready devices, configure them and link them to enable additional functionality and more automatic control to the aquarium.

  • Page 33: Lamp Firmware Upgrade

    Lighting - LED, T5, Hybrid LED+T5 6. Lamp Firmware Upgrade Warning! Switching OFF the power supply during the Firmware updating process may damage your lamp CPU. Uploading wrong Firmware may damage your lamp and void your warranty. The damage may require returning the lamp to our service department to restore it’s original functionality.
  • Page 34 Lighting - LED, T5, Hybrid LED+T5 Option 2: Verify the USB Serial Port COM number from “Devices and Printers”. 4. Right Click on the device and select “Properties”. 5. The USB Serial Port COM number will be visible under device Properties.
  • Page 35 Lighting - LED, T5, Hybrid LED+T5 6. Download the “Firmware Updater” application from the Pacific Sun website: http://www.pacific-sun.eu/pliki/PSunFlash32.zip Unpack the ZIP file and run the “Firmware Uploader”. Note: For the Mac OS version download from: http://www.pacific-sun.eu/pliki/PSunFlash21.app.zip 7. In the “Settings” tab, choose the port...
  • Page 36 Lighting - LED, T5, Hybrid LED+T5 9. Select the previously downloaded Firmware file and click Open 10. Click Update 11. The Firmware upgrade will be in progress with message “Please wait……..” Page 36...
  • Page 37 Lighting - LED, T5, Hybrid LED+T5 12. Now - RESET the lamp: Switch DOWN Switch UP 13. The Firmware writing process will start and the number in bytes will be increasing. 14. The Firmware upgrade status will be indicated with the green progress bar.
  • Page 38 1. At the end of the Firmware writing process program will show “Firmware updated”. 2. Disconnect the USB cable from your computer and Pacific Sun device. 3. Disconnect device from the power source for a few seconds and connect the power back.

  • Page 39: Troubleshooting

    Lighting - LED, T5, Hybrid LED+T5 7. Troubleshooting Problems Solutions Problem with 1. Reboot your home Wi-Fi router (power OFF/ON) and after that communication between reboot your PS device (power OFF/ON). the device and PS Cloud Wait a few minutes and check PS Cloud application service interface functionality again.
  • Page 40 If you need technical support - please contact with Copyright: Pacific Sun Sp. Z o.o. ul. Ogrodników 22 84-240 Reda Poland tel. + 48 58 778 17 17 email: office@pacific-sun.eu...
