HIRED-HAND Super-Saver Bunsen Jet Owner's Manual

Radiant brooder with pilotless ignition
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FOR YOUR SAFETY
If you smell gas:
1. O p e n w indows.
2. D o n 't touch electrical sw itches.
3. Extinguish any open flames.
4. Im m ediately call your gas supplier.
CONSIGNES DE SECURITE
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres
2. Ne touchez pas aux interrupteurs electriques
3. Eteignez toute flamme nue
4. Contactez immediatement votre compangie
de gaz
O w ner's M anual
Radiant Brooder with Pilotless Ignition
NOTE: Retain instructions for future reference
R
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vacinity of this or any
other appliance.
CONSIGNES DE SECURITE
ll es interdit d'utiliser des liquides
inflammables ou degageant des vapeurs
inflammables, a proximite de tout
appareil fonctionnant au gaz.
