MicroNet SP3367A User Manual

Wireless adsl2+ modem router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Micronet
R
Faster and Easier Networks

User Manual

Wireless ADSL2+ Modem Router
Model No. SP3367A
http://www.micronet.info

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP3367A and is the answer not in the manual?

Questions and answers

Related Manuals for MicroNet SP3367A

Summary of Contents for MicroNet SP3367A

  • Page 1: User Manual

    Micronet Faster and Easier Networks User Manual Wireless ADSL2+ Modem Router Model No. SP3367A http://www.micronet.info...

  • Page 2: Ce Declaration Of Conformity

    CE Declaration of conformity This equipment complies with the requirements relating to electromagnetic compatibility, EN55022 class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. FCC Part 68 This equipment complies with Part 68 of the FCC Rules.
  • Page 3 The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper operation of your equipment. If they do, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service. If you experience trouble with this modem, please contact your dealer for repair/warranty information.
  • Page 4 installation. FCC regulations require that shielded interface cables be used with your modem. If interference does occur, we suggest the following measures be taken to rectify the problem: 1) Move the receiving antenna. 2) Move the modem away from the radio or TV. 3) Plug the modem into a different electrical outlet.

  • Page 5: Table Of Contents

    CE Declaration of conformity ... 1 Chapter 1 Introduction... 6 1.1 Overview... 6 1.2 Features ... 7 1.3 System Requirements ... 9 Chapter 2 Installation ...10 2.1 Checklist ...10 2.2 The Front LEDs ... 11 2.3 The Rear Ports ...12 2.4 Hardware installation ...13 2.5 Splitter Configuration ...14 POTS Splitter Configuration (ADSL over POTS) ...14...
  • Page 6 4.4.1 Routing Table ...35 4.4.2 NAT Setting ...37 4.4.3 ADSL ...40 4.4.4 Firewall ...41 4.5 Access Management ...42 4.5.1 ACL...42 4.5.2 IP Filtering ...43 4.5.2 SNMP ...44 4.5.3 UPnP ...45 4.5.4 DDNS ...46 4.6 Maintenance ...47 4.6.1 Administration...47 4.6.2 Time Zone ...48 4.6.3 Firmware Update...49 4.6.4 System Restart...50 4.6.5 Diagnostic...51...

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction The ADSL2+ Router provides home connectivity to an ADSL service provider network over an ADSL/ Asynchronous Transfer Mode (ATM) physical layer. The router can run upstream maximum transmission rates of 2Mbps and downstream maximum transmission rates of 24Mbps. The actual rate depends on the copper category of your telephone wire, distance from the central office and the type of ADSL2+ service subscribed.

  • Page 8: Features

    1.2 Features ADSL2/2+ Compliance ♦ Compliant with ADSL standards ♦ Full-rate ANSI.413 Issue 2 , ITU G.dmt (G.992.1) , G.dmt bis (G.992.3) and G.adslplus(G.992.5) standards Splitter less ITU G.lite (G.992.2) specification Annex A (ADSL over POTS) and Annex B (ADSL over ISDN), compliant to ETSI TS 101 388 ♦...

  • Page 9: Bridge Mode

    Bridge Mode ♦ Ethernet to ADSL self learning Transparent Bridging (IEEE 802.1D) ♦ Supports MAC learning addresses Router Mode ♦ IP routing-RIPv2 ♦ Static routing ♦ DNS Proxy ♦ Dynamic DNS ♦ DMZ ♦ Port Forwarding ♦ DHCP (dynamic host configuration protocol) server and client ♦...

  • Page 10: System Requirements

    Ethernet Interface ♦ Compliant with IEEE 802.3 and 802.3u 10/100 Mbps HTTP Web-Based Management ♦ Firmware upgrade by UI ♦ Customizable Web pages ♦ WAN and LAN side connection statistics ♦ Configuration of static routes and routing table ♦ Password protected access ♦...

  • Page 11: Chapter 2 Installation

    Chapter 2 Installation This chapter offers information about installing your router. If you are not familiar with the hardware or software parameters presented here, please consult your service provider for the values needed. 2.1 Checklist Check the shipping box carefully to ensure that the contents include the items you ordered.

  • Page 12: The Front Leds

    2.2 The Front LEDs State WLAN Blinking ADSL Blinking LINK/ ACT (Port 1 - 4) Blinking Description When the router power on When wireless AP is disabled While wireless traffic is transmitting or receiving Connected to an ADSL DSLAM successfully No connection The LAN cable is connected to the router No network connection...

  • Page 13: The Rear Ports

    2.3 The Rear Ports Connector Antenna Connector Reset POWER LAN (1-4) ADSL Description Reverse SMA connector The reset button, the router restore default settings when press until reboot Power connector with 12VDC/ 1 Ampere Router is successfully connected to a device through the corresponding port (1, 2, 3 or 4).

  • Page 14: Hardware Installation

    2.4 Hardware installation This section describes how to connect and configure the ADSL router. 1) Connect the ADSL line Connect the router directly to the wall jack using the included ADSL RJ-11 telephone cable. 2) Connect a workstation to the Router's LAN port Use Ethernet RJ-45 cable to connect computer or expend Ethernet network.

  • Page 15: Splitter Configuration

    2.5 Splitter Configuration ADSL splitter builds-on a micro-filter it stops the ADSL signal interfering with the voice part of your phone line. The graph hereunder shows the frequency range that your phone (POTS) and ADSL occupy. Use ADSL splitter to separate the bands for POTS and ADSL and get better communication quality.
  • Page 16 Figure 2-5.1 Router connected through a POTS Splitter Note: The POTS splitter may also be installed on the outside of the house adjacent to the telephone network interface device (NID). Figure 2-5.2 Router connected through several micro-filters...

  • Page 17: Isdn Splitter Configuration (Adsl Over Isdn)

    ISDN Splitter Configuration (ADSL over ISDN) A ISDN splitter separates ADSL signals from ISDN signals on your ISDN telephone line. The ISDN splitter works by running a separate ADSL line from the ISDN line, so that the ADSL router has a cable dedicated for data transmission.

  • Page 18: Chapter 3 Connection

    Chapter 3 Connection 3.1 Determine connection settings Before configure the router, you need to know the connection information supplied by your ADSL service provider. 3.2 Connecting the Router to network Unlike a simple hub or switch, the setup of the ADSL Router consists of more than simply plugging everything together.
  • Page 19 2) Connect a network cable from one of your PCs' Ethernet ports to the LAN port on the back of the Router. 3) Connect the power adapter to the Power port on the rear of the Router then connect to a power outlet using the power cord included in the Router's packaging.
  • Page 20 8) Click OK again. Windows may begin copying files to your computer. (In Windows 98, system will ask you to restart your PC. Click Yes to restart your computer and initiate the new settings.)

  • Page 21: Chapter 4 Configuration

    Chapter 4 Configuration 4.1 Access the Modem Router It is advised that the administrator password be changed to safeguard the security of your network. To configure the router, open your browser, type http://192.168.2.1 into the address bar and click Go to get to the login page. Save this address in your Favorites for future reference.

  • Page 22: Quick Setup

    4.2 Quick Setup You can use Quick Setup to setup the router as follows, and the router will connect to the Internet via ADSL line. Click Quick Start to get into the quick setup procedures.
  • Page 23 Click RUN WIZARD to start up this procedure. Step 1 - Click Next to setup your new administrator's password.
  • Page 24 Step 2 - Click Next to setup your time zone. Step 3 - Click Next to setup your Internet connection type. You can have this information from your Internet Service Provider.
  • Page 25 Enter the connection information provided by your ISP. Click Next twice then close the Wizard.

  • Page 26: Interface Setup

    4.3 Interface Setup 4.3.1 Internet ATM VC Configuration Go to Interface Setup Internet. To add or delete ADSL VC configuration, these information provide by ISP.

  • Page 27: Wan Configuration

    WAN Configuration Go to Interface Setup Internet. The router can be connected to your service provider in any of the following ways. Check the radio box of the service provided by your ISP, then the related settings will pop up in this page under Encapsulation.
  • Page 28 Static IP Address: Uses a static IP address. Your service provider gives a static IP address to access Internet services.
  • Page 29 PPPoE: PPP over Ethernet is a common connection method used for xDSL PPPoA: PPP over ATM is a common connection method used for xDSL...
  • Page 30 Bridge: Bridge mode is a common connection method used for xDSL modem.

  • Page 31: Dynamic Routing

    Dynamic Routing Go to Interface Setup Internet to select the Dynamic Route needed. The dynamic routing feature of the router can be used to allow the router to automatically adjust to physical changes in the network's layout. The router uses the dynamic RIP protocol. It determines the route that the network packets take based on the fewest number of hops between the source and the destination.

  • Page 32: Lan Configuration

    4.3.2 LAN Configuration Go to Interface Setup LAN. The LAN Settings option enables you to configure the LAN port. DHCP Relay DHCP Relay forwards local clients' DHCP requests to WAN site DHCP server. Three settings have to be configured when enabling the function: (1) disable the NAT and run on route mode only;...
  • Page 33 Go to Interface LAN to enable DHCP server. Then you can set DNS server for the router. A Domain Name system (DNS) server is like an index of IP addresses and Web addresses. If you type a Web address into you browser, a DNS server will find that name in its index and find the matching IP address.

  • Page 34: Wireless Settings

    4.3.3 Wireless Settings Go to Interface Wireless to setup the wireless parameters. SSID SSID is the identifier for the network. You can change the SSID. Only devices with the same SSID can interconnect. Channel ID The channel number is used for wireless networking. The channel setting of the wireless devices within a network should be the same.

  • Page 35: Wireless Security

    Wireless Security The Authentication type supports “shared key WEP 64bits", "shared key WEP 128bits”, “WPA-PSK”.

  • Page 36: Advanced Setup

    4.4 Advanced Setup 4.4.1 Routing Table Go to Advance Setup Routing to see the Routing Table. The Routing table allows you to see how many routings are on the network. It shows the interface information.

  • Page 37: Static Routing

    Static Routing Go to Advance Setup Routing ADD ROUTE to set up static route features. The static routing function determines the path that router follows over the network before and after it passes through this router. You can use static routing to allow different IP domain users to access the Internet through this device.

  • Page 38: Nat Setting

    4.4.2 NAT Setting Go to Advanced Setup NAT to set up the NAT features. Network Address Translation (NAT) allows multiple users at your local site to access the Internet through a single public IP address or multiple public IP addresses. NAT can also prevent hacker attacks by mapping local addresses to public addresses for key services such as the Web or FTP.

  • Page 39: Dmz Setting

    DMZ Setting Go to Advanced Setup DMZ to set DMZ parameters. If you have a local client PC that cannot run an Internet application properly behind the NAT firewall, you can open the client up to unrestricted two-way Internet access by defining a virtual DMZ Host.

  • Page 40: Virtual Server

    Virtual Server Go to Advanced Setup Virtual Server to set virtual server as needed (known as Port Mapping). Virtual server opens the port(s) for specified service and maps the port(s) to the private IP address of the server. It allows remote users accessing services such as the Web or FTP at the local site via public IP address.

  • Page 41: Adsl

    4.4.3 ADSL Go to Advanced Setup ADSL to set up the ADSL mode and ADSL type. ISP should provide you the details required.

  • Page 42: Firewall

    4.4.4 Firewall Go to Advanced Setup Firewall to enable or disable Firewall feature.

  • Page 43: Access Management

    4.5 Access Management 4.5.1 ACL Access Control List (ACL) defines the rule which the user may remote access the route to execute the selected application. Go to Access Management ACL, it will list that the five applications. With the default IP 0.0.0.0, any client of LAN site would be allowed to access the router.

  • Page 44: Ip Filtering

    4.5.2 IP Filtering Go to Access Management IP Filtering to block some packets form WAN. The router provides extensive firewall protection by restricting connection parameters to reduce the risk of intrusion and defending against a wide array of common hacker attacks. It will accept up to 12 IP Filter rules to prevent unwanted access from accessing the services of the router.

  • Page 45: Snmp

    4.5.2 SNMP The Simple Network Management Protocol (SNMP) enables a host computer to access configuration, performance and other system data that resides in a database on the modem. The host computer is called a management station and the modem is called an SNMP agent. The data that can be accessed via SNMP is stored in a Management Information Database (MIB) on the modem.

  • Page 46: Upnp

    4.5.3 UPnP Universal Plug and Play (UPnP): When a user plugs a device which supports UPnP into the network, the device will configure itself, acquire a TCP/IP address, and use a discovery protocol based on the Internet's Hypertext Transfer Protocol (HTTP) to announce its presence on the network to other devices.

  • Page 47: Ddns

    4.5.4 DDNS Go to Access Management DDNS to set up your DDNS parameters. Dynamic DNS (DDNS) allows you to update your dynamic IP address with the dynamic DNS services. So anyone can access your FTP or Web service on your computer using DNS-like address.

  • Page 48: Maintenance

    4.6 Maintenance 4.6.1 Administration Go to Maintenance Administration to set a new user's name and password to restrict management access to the router. The default is admin (User's name) and admin (Password)

  • Page 49: Time Zone

    4.6.2 Time Zone Go to Maintenance Time Zone and select system time for your area. Connecting to a Simple Network Time Protocol (SNTP) server allows the router to synchronize the system clock to the global Internet. The synchronized clock in the router is used to record the security log and control client filtering.

  • Page 50: Firmware Update

    4.6.3 Firmware Update Go to Maintenance Firmware to upgrade the firmware. The new firmware for this router can improve functionality and performance. Enter the path and name of the upgrade file then click the UPGRADE button below. You will be prompted to confirm the upgrade.

  • Page 51: System Restart

    4.6.4 System Restart In the event that the router stops responding correctly or in some way stops functioning, you can perform a reset. Your settings will not be changed. To perform the reset, select Current Setting and click on the RESTART button below.

  • Page 52: Diagnostic

    4.6.5 Diagnostic The Diagnostic page allows you to run a series of diagnostic tests of your system software and hardware connections. From the Virtual Circuit drop-down list, select the name of the Virtual Circuit on which the diagnostics are to be shown. Note: 1) User ONLY can view PVC0’s Diagnostic Test connection.

  • Page 53: Status

    4.7 Status 4.7.1 Device Info The Device Info screen shows the current status of this modem router. Note that these fields are read-only and are not meant for diagnostic purposes, except the Virtual Circuit, which is chosen from drop-down list for showing the system status.
  • Page 54 [Device Information] Firmware Version: This field displays current firmware version. MAC Address: The MAC (Media Access Control) or Ethernet address unique to your modem. [LAN] IP Address: The LAN port IP address Subnet Mask: The LAN port IP subnet mask. DHCP Server: The status of DHCP Server (Enabled or Disabled) [WAN] Virtual Circuit: Click the drop-down list and select the name of the Virtual...

  • Page 55: System Log

    4.7.2 System Log Go to Status System Log and you will see the system log file. Click Save Log to save system log file.

  • Page 56: Adsl Statistics

    4.7.3 ADSL Statistics Go to Status Statistics and select ADSL interface. You can see the traffic statistics of ADSL interface.

  • Page 57: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting The LAN LED on the front panel does not light up. STEPS CORRECTIVE ACTION Check the Ethernet cable connections between your ADSL2+ Router and the computer or hub. Check for faulty Ethernet cables. Make sure your computer’s Ethernet card is working properly. If these steps fail to correct the problem, contact your local distributor for assistance.
  • Page 58 I cannot access the web management. STEPS CORRECTIVE ACTION Make sure you are using the correct IP address of ADSL2+ Router. Check the IP address of ADSL2+ Router. Your computer and ADSL2+ Router’s IP addresses must be on the same subnet for LAN access. If you have changed ADSL2+ Router’s LAN IP address, then enter the new one as the URL.
  • Page 59 Your PC’s IP address is 192.168.2.111. The PC’s Subnet Mask is 255.255.255.0. Your PC’s MAC Address is the one entitled Physical Address (00-00-E2-82-C3-AD). I cannot access the Web Management of the router after activating the ACL function. STEPS CORRECTIVE ACTION When ACL is activated, you have to set the ACL rule for allowing some users to use some services.
  • Page 60 I forget my login username and/or password. STEPS CORRECTIVE ACTION If you have changed the password and have now forgotten it, you will need to upload the default configuration file. This will erase all custom configurations and restore all of the factory defaults including the password.
  • Page 61 Initialization of the ADSL connection failed. STEPS CORRECTIVE ACTION Check the cable connections between the ADSL port and the wall jack. The ADSL LED on the rear panel of the router should be on. Check VPI, VCI, type of encapsulation and type of multiplexing settings are the same as what you collected from your ISP.

  • Page 62: Appendix A Glossary

    Appendix A Glossary Address mask A bit mask used to select bits from an Internet address for subnet addressing. The mask is 32 bits long and selects the network portion of the Internet address and one or more bits of the local portion. Sometimes is called subnet mask.
  • Page 63 given packet is given to all hosts attached to the network. Example: Ethernet. Central Office. Refers to equipment located at a Telco or service provider's office. Customer Premises Equipment located in a user's premises DHCP (Dynamic Host Configuration Protocol) DHCP is software that automatically assigns IP addresses to client stations logging onto a TCP/IP network.
  • Page 64 One of the most common local area network (LAN) wiring schemes, Ethernet has a transmission rate of 10 Mbps. File Transfer Protocol. The Internet protocol (and program) used to transfer files between hosts. Hop count A hop count is a measure of distance between two points on the Internet. It is equivalent to the number of gateways that separate the source and destination.
  • Page 65 IP address The 32-bit address assigned to hosts that want to participate in a TCP/IP Internet. Internet service provider - A company allows home and corporate users to connect to the Internet. Media Access Control Layer - A sub-layer of the Data Link Layer (Layer 2) of the ISO OSI Model responsible for media control.
  • Page 66 Remote server A network computer allows a user to log on to the network from a distant location. Request for Comments - Refers to documents published by the Internet Engineering Task Force (IETF) proposing standard protocols and procedures for the Internet. RFCs can be found at www.ietf.org.. Route The route is the path that network traffic takes from its source to its destination.
  • Page 67 multi-bridged environment. When three or more LAN's segments are connected via bridges, a loop can occur. Because a bridge forwards all packets that are not recognized as being local, therefore some packets may circulate for long periods of time, eventually degrading system performance.
  • Page 68 bridge itself; the bridge is thus transparent to the communicating workstations. It involves frame forwarding, learning workstation addresses and ensuring no topology loops exist (in conjunction with the Spanning-Tree algorithm). User Datagram Protocol - A connectionless transport protocol that runs on top of TCP/IP's IP.

  • Page 69: Appendix B Cabling

    Appendix B Cabling Network cables connect PCs in an Ethernet network Category 5, also called "Cat5" for short, which is a commonly used type of network cable today. Cat 5 cables are tipped with RJ-45 connectors, which fit into RJ-45 port. Straight-through vs.

  • Page 70: Appendix C Service / Port

    Appendix C Service / Port Service Name, Protocol and Port number Service Protocol HTTP IMAP VDOLive WINFRAME PC-Anywhere SNMP TALK UDP-Any PING ICMP Port Service Finger 20-21 Gopher HTTPS InterLocator 6660-6669 L2TP 7000-7010 WAIS 1494 X-WIN SYSLOG 517-518 TFTP UUCP TRACEROUTE Protocol Port...
