Isabella Double & King Bed
OTTOMAN
Important - read this guide carefully and retain for future reference.
Ottoman Safety Warnings
You must ensure that the mattress is on the bed frame before operating the lift mechanism - Failure
to do so could result in injury.
Keep hands clear of the mechanism when opening or closing the ottoman.
Beware of entrapment - Never reach in through the mechanism to access the storage area.
Always ensure that the ottoman is FULLY opened before accessing the storage area.
Do not exceed the maximum mattress weight as specified in the table below:
Bed
Isabella
(manual)
Bed Size
Piston Strength (N/M)
Double
King
Isabella Double & King bed - Assembly Guide - page 1
Min Mattress
Weight (kg)
600
20
700
24
Max Mattress
Weight (kg)
42
50
Advertisement
Related Manuals for DREAMS Isabella Double
Summary of Contents for DREAMS Isabella Double
- Page 1 Do not exceed the maximum mattress weight as specified in the table below: Min Mattress Max Mattress Bed Size Piston Strength (N/M) Weight (kg) Weight (kg) Isabella Double (manual) King Isabella Double & King bed - Assembly Guide - page 1...
-
Page 2: Help And Support
Thank you Hello, thanks for choosing to purchase your bed from Dreams - you’re now on your way to your best Ever night’s sleep. Before you begin building your bed, please take a moment to read through the Instructions and make sure that you’ve got all the relevant parts listed on the following pages. - Page 3 The bed you have purchased comes with a metal slat frame lifting from the front OTTOMAN Parts List Description Description Headboard Center Panel Footboard Base Boards Headboard Panel Base Boards Footboard Panel Metal Slat Frame Side Rails (Left & Right) Mattress Stoppers Isabella Double & King bed - Assembly Guide - page 3...
-
Page 4: Tools Required
(k) Spanner (l) Allen Key(M4) (m) Allen Key(M5) (n) Nut (M8) x1pc x2pcs x1pc x2pcs Tools required Please check you have all these below: Tape measure Scissors Isabella Double & King bed - Assembly Guide - page 4... - Page 5 2) Please do not tighten any Locking Nuts yet. Assemble footboard panel (D) to the side¢er rails (E & F). Secure by tightening the locking nuts in the same way as described in step 1. Isabella Double & King bed - Assembly Guide - page 5...
- Page 6 Ottoman assembly Fit the footboard (B) to the unit. Fit the headboard (A) to the unit. Isabella Double & King bed - Assembly Guide - page 6...
- Page 7 Nuts with Spanner (k),do not Slat frame Support Bar over - tighten. A small gap needs to be left so stem can move freely, please see sketch below. small gap Isabella Double & King bed - Assembly Guide - page 7...
- Page 8 2) Secure by threading bolts (j) to slat frame on the gas-lift mechanisms support bars . Position base boards (G&H) into the bed frame Isabella Double & King bed - Assembly Guide - page 8...
- Page 9 Ottoman assembly LAY DOWN Make certain the bed is squared up as shown in the diagram then tighten all bed assembly bolts 100% Isabella Double & King bed - Assembly Guide - page 9...
- Page 10 Before removing the mattress secure the frame to ensure it does not open unexpectedly. Do not attempt to lie on the mattress when the ottoman is in the raised position. When lifting the ottoman remove all bedding except the fitted sheet. Isabella Double & King bed - Assembly Guide - page 10...
-
Page 11: Care And Maintenance
Metal tends to be more resilient to everyday wear and tear. We recommend to gently dust your metal furniture and keep it dry to maintain its look. Thank you for shopping with us - we hope you have a great night’s sleep Isabella Double & King bed - Assembly Guide - page 11...
