Summary of Contents for Pivotell 3/07
- Page 1 Automatic Pill Dispenser (Model 3/07) Instructions...
- Page 2 PIVOTELL AUTOMATIC PILL DISPENSER MODEL 3/07 The pack also includes:- 6. Medication 7. Three reversible 8. Batteries 9. Key booklet and day/time discs 4 x AA Alkaline case...
- Page 3 PIVOTELL AUTOMATIC PILL DISPENSER MODEL 3/07 The Pivotell Automatic Pill Dispenser reminds the user by means of an alarm and flashing light when to take their medication. It will make the correct dose available at the correct time of day or night, whilst keeping other pills locked out of sight. Medication is dispensed from an internal tray containing 29 sections.
- Page 4 FILLING THE DISPENSER Time Discs Three day / time discs are supplied which comprise: Two printed discs for 1 up to 4 medication prompts per day (use either side) and one blank disc for more than 4 medication prompts per day. The discs should be completed by hand indicating the medication times.
- Page 5 DISPENSER SETTINGS There are two setting menus :- Menu A:- Button 1 Menu B:- Button 3 DOSES BEFORE AFTER ALARM SOUND LIGHT CLOCK HOURS DATE RECORD TEST Note: After completion of settings in either Menu A or B press button 1 for three seconds to restore to normal operation.
- Page 6 BEFORE (Continued) The time in advance that this can be done is controlled by the ‘BEFORE’ function, to set this: Press and hold Button 3 until BEFORE is displayed. Press Buttons 2 or 3 to set the time required (0-30 minutes maximum) NB: If medication is taken before the normal time, the dispenser will not activate again until the following medication is due.
- Page 7 EXTERNAL INTERFACE The dispenser includes an external interface to enable connection of various existing and future support electronic devices, for example - wireless transmitters, modems, alarm sounders, alarm lights etc. For further information please contact Pivotell Ltd.
- Page 8 ALWAYS LIFT IT OUT AND REPLACE BY LOWERING DIRECTLY INTO THE CASE IN THE CORRECT POSITION. Pivotell Ltd will accept no responsibility for faults or any other consequences arising from misuse e.g. dropping, water damage, insertion of foreign objects, forced turning of the pill tray or forced opening of the dispenser Pivotell Ltd, P.O.Box 108, Saffron Walden CB11 4WX...
