Summary of Contents for AP&T AP-AB1215
- Page 1 AP&T Shanghai Anping Static Technology Co.,Ltd High Efficient Electroshock-proof Intelligent Ion Bar AP-AB1215 AP&T...
- Page 2 Widely used in electronics, optoelectronics, semiconductor and other industries E f f e c t i v e l y s o l v e t h e p r o b l e m c a u s e d b y s t a t i c e l e c t r i c i t y Prevent adhesion of objects Static removal Prevent uneven scattering...
- Page 3 High efficient Safe Static removal...
-
Page 4: Intelligent Control
Intelligent Control Ion balance/ ion output frequency adjustable The output ratio of positive and negative ions is adjustable, which can be used to adjust the ion balance voltage. Positive high voltage amplitude Positive high voltage amplitude (Positive high voltage) (Positive high voltage) The negative ion output increases with the increase of negative high voltage amplitude time... - Page 5 Intelligent Control Ion balance/ ion output frequency adjustable Button function instructions Symbol Operation instructions Function Unlock before adjusting operating parameters. Unlock Device starts running when power is on. Press "STOP" to standby and no high voltage Run / Pause output. Press "RUN" again and the device will start working. Press CTTH first, then +/- to increase or decrease the cleaning cycle.
- Page 6 Pulse AC The effect of static eliminating is better compare to power frequency AC ion bar Pulse AC Comparison with traditional AC Positive pulse Negative pulse Pulse AC Positive voltage working time (Positive high pressure) The pulsed AC method alternately applies "+" and "-" high voltage to one electrode needle to generate two polar ions.
- Page 7 Efficiently static removal Stay away static trouble & for clean production environment 150mm 150mm 1.7s 2.8s 30mm 3.2s 3.1s 50mm 3.1s 2.3s 0.1s 70mm 5.1s 6.0s 1.0s 100mm 150mm*150mm Flat tester Test Conditions： Ion bar length：410mm Working frequency：30Hz Test standard: ANSI/ESD.STM3.1, SJ/T 11446—2013 Test instrument: Trek157 static tester Test voltage: ±1000V →...
-
Page 8: Easy Installation
Features Safe / Easy to use / Durable No.1 Easy installation Provide stainless steel mounting angle and can adapt to various installation environments. No.2 Electroshock-proof Protection against electroshock. No.3 Working status visualization Red light alarm when high voltage abnormal. No.4 CE certification It can effectively prevent the external electromagnetic interference from... -
Page 9: Specification
Specification Details / Parameter / Size Product Details Power input port Working status indicator Negative high voltage (orange light on when working) Needle holder and electrode needle Strip grounding electrode Positive high voltage (green light on when working) RJ45 port on the front and back panel of ion bar: The orange light on the front port and the green light on the back port blink alternately with the working frequency;... -
Page 10: Product Parameter
Product Parameter Model AP-AB1215 Input voltage DC 24V Power Electrode pin voltage Vpp:8-12KV Ion emission Pulse AC Emitter electrode Discharge structure Resistance coupling Output frequency 0.1,0.5,1,5,10,30,55,65,105Hz；(EX-Work setting: 30Hz) Discharge range L*W*H：Bar Length*300*100mm Installation distance 30→100mm Ion balance ≤|±30V| （ AVE ）... -
Page 11: Use Of The Product
Use of the product Installation step / Installation position / Packaging accessories Installation step power cable cable one adapter for one bar one adapter for two bars Bracket installation power cable cable 1.Take out the ion bar, adapter power supply, power supply network cable , Insert one end of the power cord into the RJ45 socket of the power stainless steel mounting brackets and other accessories from the packing box. -
Page 12: Installation Position
Installation position 1. Choose the best static elimination position and install the bar body and the matching power adapter firmlyafter the static detection of the on-site working environment. The installation angle should be perpendicular to the surface of the charged body, and the installation distance can be referred to the following table. -
Page 13: Packaging Accessories
Packaging accessories Name Image Part No. Quantity Specification GRT-240200: DC24V 2A, dual network Power Adapter OSP000601 port output, Size: 123*61*40.5mm (L*W*H) National standard power cord 8YXG25110 Standard:1.8m, optional:3m/5m Double ended crystal head 8WXI00004 Standard:2.5m, 5m/10m:optional black shield cable Single-ended crystal head FUTP CAT.5E 26AWG 4Pair Jacket PVC black shield 8WXI00002... - Page 14 It can be used only after the electrical performance index is normal. After-sales service AP-AB1215 has undergone rigorous testing and aging treatment before ex-work. Its performance has completely reached the relevant indicators marked in the usage instruction.
- Page 15 AP&T Professional electrostatic intelligent monitoring/analysis and elimination solution provider 专 业 创 造 价 值 S p ecia lit y C r ea t es Va l u e Shanghai Anping Static Technology Co.,Ltd Tel : +86-21-64517676 Fax : +86-21-64517673 AP&T Postcode : 200233 Website : www.ap-static.com...
