Install Burner Grates

To install burner grates, place the grates ﬂ at-side

down and align them into the cooktop recess.. The

grates have tabs that interlock, so it is important to

place the center grate ﬁ rst.

Figure 5: Install grates middle-ﬁ rst

BEFORE SETTING SURFACE CONTROLS

IMPORTANT

•

Make sure the burner grates are proper-

ly placed on the cooktop before using the

surface burners (Figure 4). The grates are

designed to rest inside the recess on the

cooktop.

Grates should rest ﬂ ush against each other

and against the sides of the recess.

Do not line the area underneath the grates or

any part of the cooktop with aluminum foil or

with any other lining.
