Sony XM-GS100 Service Manual page 23

Ref. No. Part No. Description
Q910 6-552-281-01 FET
Q912 8-729-055-50 TRANSISTOR
Q913 8-729-055-50 TRANSISTOR
Q914 8-729-202-38 TRANSISTOR
Q915 8-729-202-38 TRANSISTOR
Q916 8-729-209-15 TRANSISTOR
Q917 8-729-209-60 TRANSISTOR
Q923 8-729-620-07 TRANSISTOR
Q924 6-550-693-01 TRANSISTOR
< RESISTOR >
R121 1-216-821-11 METAL CHIP
R127 1-216-829-11 METAL CHIP
R139 1-216-843-11 METAL CHIP
R154 1-216-829-11 METAL CHIP
R159 1-216-845-11 METAL CHIP
R160 1-216-829-11 METAL CHIP
R161 1-216-829-11 METAL CHIP
R162 1-216-841-11 METAL CHIP
R163 1-216-829-11 METAL CHIP
R164 1-216-821-11 METAL CHIP
R165 1-216-833-11 METAL CHIP
R166 1-216-821-11 METAL CHIP
R167 1-216-821-11 METAL CHIP
R168 1-216-825-11 METAL CHIP
R169 1-216-829-11 METAL CHIP
R170 1-216-819-11 METAL CHIP
R171 1-216-819-11 METAL CHIP
R172 1-216-214-00 METAL CHIP
R173 1-216-234-00 METAL CHIP
R174 1-216-829-11 METAL CHIP
R175 1-216-815-11 METAL CHIP
R176 1-216-821-11 METAL CHIP
R177 1-216-246-00 METAL CHIP
R178 1-216-807-11 METAL CHIP
R180 1-216-246-00 METAL CHIP
R181 1-216-845-11 METAL CHIP
R182 1-215-880-31 METAL OXIDE
R183 1-216-813-11 METAL CHIP
R184 1-216-813-11 METAL CHIP
R185 1-216-809-11 METAL CHIP
R186 1-216-811-11 METAL CHIP
R187 1-216-801-11 METAL CHIP
R188 1-215-880-31 METAL OXIDE
R190 1-216-793-11 METAL CHIP
R191 1-216-845-11 METAL CHIP
R192 1-216-809-11 METAL CHIP
R193 1-216-811-11 METAL CHIP
R194 1-216-801-11 METAL CHIP
R195 1-216-829-11 METAL CHIP
R201 1-216-829-11 METAL CHIP
R202 1-216-829-11 METAL CHIP
R203 1-216-801-11 METAL CHIP
R204 1-216-809-11 METAL CHIP
R701 1-216-839-11 METAL CHIP
R702 1-216-847-11 METAL CHIP
R801 1-216-853-11 METAL CHIP
R803 1-216-857-11 METAL CHIP
R804 1-216-833-11 METAL CHIP
R805 1-216-833-11 METAL CHIP
R806 1-216-833-11 METAL CHIP
Remark
FKV575
2SC4357-T11-1E
2SC4357-T11-1E
2SC3326N-A
2SC3326N-A
2SD2012
2SB1375
2SC3052EF-T1-LEF
KTC4373
1K 5% 1/10W
4.7K 5% 1/10W
68K 5% 1/10W
4.7K 5% 1/10W
100K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
47K 5% 1/10W
4.7K 5% 1/10W
1K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
2.2K 5% 1/10W
4.7K 5% 1/10W
680 5% 1/10W
680 5% 1/10W
4.7K 5% 1/8W
33K 5% 1/8W
4.7K 5% 1/10W
330 5% 1/10W
1K 5% 1/10W
100K 5% 1/8W
68 5% 1/10W
100K 5% 1/8W
100K 5% 1/10W
10 5% 2W F
220 5% 1/10W
220 5% 1/10W
100 5% 1/10W
150 5% 1/10W
22 5% 1/10W
10 5% 2W F
4.7 5% 1/10W
100K 5% 1/10W
100 5% 1/10W
150 5% 1/10W
22 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
22 5% 1/10W
100 5% 1/10W
33K 5% 1/10W
150K 5% 1/10W
470K 5% 1/10W
1M 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
Ref. No. Part No. Description
R807 1-216-833-11 METAL CHIP
R809 1-216-833-11 METAL CHIP
R810 1-216-833-11 METAL CHIP
R811 1-216-833-11 METAL CHIP
R812 1-216-833-11 METAL CHIP
R813 1-216-833-11 METAL CHIP
R814 1-216-833-11 METAL CHIP
R818 1-216-845-11 METAL CHIP
R820 1-216-821-11 METAL CHIP
R822 1-246-157-11 METAL
R823 1-216-823-11 METAL CHIP
R824 1-216-833-11 METAL CHIP
R825 1-216-823-11 METAL CHIP
R826 1-216-845-11 METAL CHIP
R828 1-216-833-11 METAL CHIP
R829 1-216-833-11 METAL CHIP
R830 1-216-833-11 METAL CHIP
R831 1-216-833-11 METAL CHIP
R832 1-218-867-11 METAL CHIP
R833 1-218-867-11 METAL CHIP
R834 1-216-841-11 METAL CHIP
R837 1-246-157-11 METAL
R838 1-216-829-11 METAL CHIP
R839 1-216-821-11 METAL CHIP
R840 1-216-829-11 METAL CHIP
R841 1-216-833-11 METAL CHIP
R851 1-216-827-11 METAL CHIP
R852 1-216-827-11 METAL CHIP
R853 1-216-827-11 METAL CHIP
R854 1-216-845-11 METAL CHIP
R855 1-216-827-11 METAL CHIP
R856 1-216-833-11 METAL CHIP
R857 1-216-821-11 METAL CHIP
R858 1-216-821-11 METAL CHIP
R860 1-218-867-11 METAL CHIP
R861 1-216-827-11 METAL CHIP
R862 1-216-827-11 METAL CHIP
R863 1-216-823-11 METAL CHIP
R870 1-216-821-11 METAL CHIP
R874 1-216-821-11 METAL CHIP
R875 1-216-821-11 METAL CHIP
R876 1-216-833-11 METAL CHIP
R877 1-216-821-11 METAL CHIP
R901 1-216-222-00 METAL CHIP
R902 1-216-833-11 METAL CHIP
R903 1-216-833-11 METAL CHIP
R904 1-216-814-11 METAL CHIP
R905 1-216-206-00 METAL CHIP
R906 1-216-821-11 METAL CHIP
R907 1-216-845-11 METAL CHIP
R908 1-216-825-11 METAL CHIP
R909 1-216-827-11 METAL CHIP
R910 1-216-835-11 METAL CHIP
R911 1-216-837-11 METAL CHIP
R912 1-216-845-11 METAL CHIP
R915 1-216-821-11 METAL CHIP
R916 1-216-821-11 METAL CHIP
R917 1-216-158-00 METAL CHIP
R918 1-216-158-00 METAL CHIP
R919 1-216-825-11 METAL CHIP
XM-GS100
MAIN
Remark
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
100K 5% 1/10W
1K 5% 1/10W
0.015 5% 5W F
1.5K 5% 1/10W
10K 5% 1/10W
1.5K 5% 1/10W
100K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
6.8K 0.5% 1/10W
6.8K 0.5% 1/10W
47K 5% 1/10W
0.015 5% 5W F
4.7K 5% 1/10W
1K 5% 1/10W
4.7K 5% 1/10W
10K 5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
100K 5% 1/10W
3.3K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
6.8K 0.5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
1.5K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
10K 5% 1/8W
10K 5% 1/10W
10K 5% 1/10W
270 5% 1/10W
2.2K 5% 1/8W
1K 5% 1/10W
100K 5% 1/10W
2.2K 5% 1/10W
3.3K 5% 1/10W
15K 5% 1/10W
22K 5% 1/10W
100K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
22 5% 1/8W
22 5% 1/8W
2.2K 5% 1/10W
23 23
