Summary of Contents for Plumbline 3000 Series
- Page 1 ® ® 3000 Series Water Filters 3000 Series Water Softeners Owner’s Manual Installation Instructions ®...
- Page 2 ® 3000 Series Water Filters Congratulations! We know you’ll love your clean water and your new Plumbline Water Filter from Monument® Water Systems. You’ll soon wonder how you ever lived without it. Improving your water with a Plumbline Water Filter is just one way to enjoy beter water in your home.
- Page 3 Table of Contents How to Use Your System..... Installaion Instrucions ..... Warranty.
- Page 4 Low pH (Acidic Water) • Chlorine, Odd Tastes or Odors • Your Plumbline Water Filter is designed to correct your water problem so you can enjoy clean, clear water, and minimize stains and corrosion. Your system operates in two primary modes: Online: Your water passes through media in your system’s filtration tank which...
-
Page 5: How To Use Your System
Check your system’s media level regularly to determine whether it requires reilling. By-passing Your System: Plumbline’s integrated by-pass valve allows you to by-pass your system should you ever wish to take it oline while you use water for other purposes. To by-pass your system, turn both handles unil they are perpendicular to the system inlet/outlet. - Page 6 How to Use Your System (coninued) Plumbline 3000 Series Water Filter Models Plumbline 3000 Series Water Filters are available in several configurations. Your installer has chosen the ideal model(s) for your application. Service Peak Tank Media Model Application Media Flow...
- Page 7 Notes...
-
Page 8: Installaion Instrucions
® 3000 Series Water Filters Installation Instructions Contents of Carton(s) Parts In/Out Adapter Part No. 13123 Owner’s Manual & Installaion Instrucions By-pass Valve Part No. 13119 Filter Assembly Mouning Clip (4 sets) (Atached to valve and by-pass valve) Part No. 15713 20 feet ½”... - Page 9 Precautions Read. Venilate. Use eye protecion. Protect nearby materials when soldering. Use only lead-free solder. Don’t reach. Install grounding strap before creaing plumbing gaps.
- Page 10 System Setup Untreated Water Filtered Water to Home or Sotener Raw Water Drain Line To Drain NOTE: Your installaion may vary. NOTE: Your installaion may vary. Follow all local plumbing codes. Follow all local plumbing codes.
- Page 11 System Setup (continued) Unpack equipment. Locate and idenify parts shown in “Parts” secion. Connect by-pass valve, in/out adapter. Atach components using mouning clips. Posiion system on a hard level surface with access to inlet plumbing, drain and electric outlet. NOTE: Make sure by-pass valve is in by-pass mode.
- Page 12 System Setup (continued) System Setup (continued) Conirm drain line low control (DLFC) installaion by removing retainer clip and disassembling as shown. Apply telon tape to barbed drain adapter. Thread barbed drain adapter into DLFC adapter. Reassemble DLFC assembly and secure with retainer clip. DLFC DLFC Adapter Barbed Drain Adapter...
- Page 13 System Setup (continued) (Step #4 coninued) Drain Line Floor Drain Connect power supply cord to nearest outlet. Begin valve set-up. • When the system is irst plugged in, the display indicator will point to Media. • Hold the Up buton unil “F” (Filter) is displayed. •...
- Page 14 System Setup (continued) Set ime of day. • Set ime of day by holding the Up or Down arrow. • Hold the Extra Cycle buton unil the Program icon disappears to save the current ime. Set backwash detail. 1. Press the Mode buton to advance to Time of Backwash. Push the up or down arrow to adjust to the desired ime of day for backwash.
- Page 15 System Setup (continued) Start-up. 1. Place the by-pass into the online posiion. 2. Start an immediate regeneraion by holding the Extra Cycle buton for 5 seconds, which will cause the valve to begin backwashing. Ensure the drain line low remains steady for selected backwash ime period, or unil the water runs clear.
-
Page 16: Warranty
Inluent water conditions must not exceed the following operating speciications: For Plumbline Water Softeners and Filters • Pressure: 20 - 125 psi (1.4 – 8.6 bar) • Min./Max. Operating Temperature: 34°F/110°F (1°C/43°C) - Page 17 Limited Warranty for Residenial Applicaions (coninued) Consumables Periodic replacement of ilter cartridges and certain ilter media (such as carbon or calcite) is part of the normal maintenance required by your system. These replacements and media loss due to natural attrition are not covered. Additional operating parameters may apply and are listed in your system owner’s manual and/or installation instructions.
-
Page 18: Register Your Product
Register Your Product Register your product within 30 days of installaion for warranty coverage. For quickest registraion, visit monumentwater.com. Or, if you prefer, complete the following form and mail it to Monument Water Systems, Warranty Registraion, 10845 Kinsman Rd., P.O. Box 193, Newbury, OH 44065. Serial Number First Name Last Name... - Page 20 We’re building a Monument for you! Backed by more than 40 years in the water treatment industry, Monument Water Systems manufactures some of the most innovaive technologies to help you take control of your water quality. Learn why plumbing professionals and consumers choose Monument Water Systems for clean, soft water and high quality drinking water.
