Sony SRS-GD50iP Service Manual page 30

SRS-GD50iP
MAIN
Ref. No. Part No. Description
R120 1-216-864-11 SHORT CHIP
R121 1-216-801-11 METAL CHIP
R122 1-216-801-11 METAL CHIP
R127 1-218-895-11 METAL CHIP
R128 1-216-841-11 METAL CHIP
R129 1-216-841-11 METAL CHIP
R130 1-216-809-11 METAL CHIP
R131 1-216-809-11 METAL CHIP
R132 1-216-825-11 METAL CHIP
R133 1-218-895-11 METAL CHIP
R134 1-218-892-11 METAL CHIP
R135 1-216-821-11 METAL CHIP
R136 1-216-825-11 METAL CHIP
R137 1-216-829-11 METAL CHIP
R138 1-216-829-11 METAL CHIP
R139 1-218-895-11 METAL CHIP
R140 1-216-821-11 METAL CHIP
R141 1-216-857-11 METAL CHIP
R142 1-218-895-11 METAL CHIP
R143 1-218-892-11 METAL CHIP
R144 1-216-837-11 METAL CHIP
R145 1-216-837-11 METAL CHIP
R146 1-216-837-11 METAL CHIP
R147 1-216-837-11 METAL CHIP
R148 1-216-864-11 SHORT CHIP
R149 1-216-833-11 METAL CHIP
R150 1-216-841-11 METAL CHIP
R151 1-216-837-11 METAL CHIP
R152 1-216-837-11 METAL CHIP
R153 1-216-845-11 METAL CHIP
R154 1-216-837-11 METAL CHIP
R155 1-216-837-11 METAL CHIP
R156 1-216-845-11 METAL CHIP
R157 (Not supplied) METAL CHIP
R158 1-216-829-11 METAL CHIP
R159 1-216-864-11 SHORT CHIP
R160 1-216-864-11 SHORT CHIP
R161 1-216-809-11 METAL CHIP
R162 1-216-809-11 METAL CHIP
R163 1-216-829-11 METAL CHIP
R164 1-216-829-11 METAL CHIP
R165 1-216-833-11 METAL CHIP
R166 1-216-833-11 METAL CHIP
R167 1-216-833-11 METAL CHIP
R168 1-216-833-11 METAL CHIP
R169 1-216-833-11 METAL CHIP
R171 1-216-821-11 METAL CHIP
R172 1-216-821-11 METAL CHIP
R173 1-216-821-11 METAL CHIP
R174 1-216-821-11 METAL CHIP
R175 1-218-845-11 METAL CHIP
R176 1-216-829-11 METAL CHIP
R177 1-216-829-11 METAL CHIP
R178 1-218-855-11 METAL CHIP
R179 1-218-855-11 METAL CHIP
R180 1-216-823-11 METAL CHIP
R181 1-216-801-11 METAL CHIP
R182 1-216-801-11 METAL CHIP
R184 1-216-821-11 METAL CHIP
R185 1-216-823-11 METAL CHIP
30
Remark
0
22 5% 1/10W
22 5% 1/10W
100K 0.5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
100 5% 1/10W
100 5% 1/10W
2.2K 5% 1/10W
100K 0.5% 1/10W
75K 0.5% 1/10W
1K 5% 1/10W
2.2K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
100K 0.5% 1/10W
1K 5% 1/10W
1M 5% 1/10W
100K 0.5% 1/10W
75K 0.5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
0
10K 5% 1/10W
47K 5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
100K 5% 1/10W
22K 5% 1/10W
22K 5% 1/10W
100K 5% 1/10W
3.3K 5% 1/10W
4.7K 5% 1/10W
0
0
100 5% 1/10W
100 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
820 0.5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
2.2K 0.5% 1/10W
2.2K 0.5% 1/10W
1.5K 5% 1/10W
22 5% 1/10W
22 5% 1/10W
1K 5% 1/10W
1.5K 5% 1/10W
Ref. No. Part No. Description
R187 1-216-849-11 METAL CHIP
R188 1-216-809-11 METAL CHIP
R190 1-216-857-11 METAL CHIP
R191 1-216-809-11 METAL CHIP
R192 1-216-809-11 METAL CHIP
R193 1-216-833-11 METAL CHIP
R195 1-216-821-11 METAL CHIP
R196 1-216-801-11 METAL CHIP
R197 1-216-845-11 METAL CHIP
R199 1-216-801-11 METAL CHIP
R200 (Not supplied) METAL CHIP
R201 (Not supplied) METAL CHIP
R202 1-216-864-11 SHORT CHIP
R203 1-216-793-11 METAL CHIP
R204 1-216-809-11 METAL CHIP
R205 1-216-801-11 METAL CHIP
R206 1-216-809-11 METAL CHIP
R207 1-216-809-11 METAL CHIP
R208 1-216-809-11 METAL CHIP
R209 1-216-809-11 METAL CHIP
R210 1-216-809-11 METAL CHIP
R211 1-216-833-11 METAL CHIP
R212 1-218-291-11 METAL CHIP
R213 1-216-833-11 METAL CHIP
R214 1-216-825-11 METAL CHIP
R215 1-216-833-11 METAL CHIP
R236 1-216-817-11 METAL CHIP
R237 1-216-817-11 METAL CHIP
R249 1-216-845-11 METAL CHIP
R250 1-216-809-11 METAL CHIP
R251 1-216-845-11 METAL CHIP
R252 1-216-845-11 METAL CHIP
R253 1-216-845-11 METAL CHIP
R254 1-216-845-11 METAL CHIP
R255 1-216-845-11 METAL CHIP
R256 1-216-845-11 METAL CHIP
R257 1-216-845-11 METAL CHIP
R258 1-216-845-11 METAL CHIP
R259 1-216-845-11 METAL CHIP
R300 1-216-845-11 METAL CHIP
R301 1-216-845-11 METAL CHIP
R302 1-216-845-11 METAL CHIP
R303 1-216-815-11 METAL CHIP
R506 1-216-833-11 METAL CHIP
R507 1-216-833-11 METAL CHIP
R508 1-216-821-11 METAL CHIP
R509 1-216-821-11 METAL CHIP
R510 1-216-829-11 METAL CHIP
R511 1-216-829-11 METAL CHIP
R512 1-216-864-11 SHORT CHIP
R513 1-216-864-11 SHORT CHIP
R516 1-216-833-11 METAL CHIP
R517 1-216-833-11 METAL CHIP
R518 1-216-821-11 METAL CHIP
R519 1-216-833-11 METAL CHIP
R520 1-216-833-11 METAL CHIP
R521 1-216-833-11 METAL CHIP
R522 1-216-864-11 SHORT CHIP
R523 1-216-833-11 METAL CHIP
R525 1-216-833-11 METAL CHIP
Remark
220K 5% 1/10W
100 5% 1/10W
1M 5% 1/10W
100 5% 1/10W
100 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
22 5% 1/10W
100K 5% 1/10W
22 5% 1/10W
2.2K 5% 1/10W
2.2K 5% 1/10W
0
4.7 5% 1/10W
100 5% 1/10W
22 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
10K 5% 1/10W
16K 5% 1/10W
10K 5% 1/10W
2.2K 5% 1/10W
10K 5% 1/10W
470 5% 1/10W
470 5% 1/10W
100K 5% 1/10W
100 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
330 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
0
0
10K 5% 1/10W
10K 5% 1/10W
1K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
0
10K 5% 1/10W
10K 5% 1/10W
