Summary of Contents for ElproSys DiagProg4
- Page 1 I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER Diagnostic tester Instruction Manual Software ENGLISH Prepared by: Sylwester Czupryna Sebastian Żur Approved by: ElproSys Sp. z o.o. ul. Tarnogórska 140 44-102 Gliwice ©Elprosys April 2019 − Rev. 3.1...
-
Page 2: Table Of Contents
SETUP SUBMENU INFORMATION SUBMENU TESTS 10 MENU – SUBJECT OF PROGRAMMING TOOLS 11 EXEMPLARY PROGRAMMING 12 BASIC SETTINGS 13 DIAGPROG4 MANUAL UPDATE 14 MAINTENANCE 15 DISPLAY FIRMWARE UPDATE 16 RESTART DIAGPROG4 17 DIAGPROG4 MANAGER 18 DESCRIPTIVE MENU ©Elprosys April 2019 − Rev. 3.1... -
Page 3: Legal Reservations And Agreement Of Use
DIAGNOSTIC TESTER LEGAL RESERVATIONS AND AGREEMENT OF USE Once Diagprog4 device is switched on user should select language from the supported languages list. Language selection will result in the change of language in the entire menu. User should review LEGAL RESERVATIONS and AGREEMENT OF USE. By selecting the Agree – accept button user accepts AGREEMENT OF USE and Diagprog4 device will switch on. -
Page 4: Menu Navigation ( Multi-Touch Screen)
Simple gestures — tapping or pressing with fingers — is enough to select menu options. In order to navigate the menu using keypad press Accept button to activate it and fully use keypad. - Accept, - Cancel, - Top, - Bottom ©Elprosys April 2019 − Rev. 3.1... -
Page 5: Main Screen
Other Selection of a quad, scooter, tractor model Tools Basic Tools Setup Basic Setup Information Information about Diagprog4 Special programs Runs special/diagnostic functions Read car’s VIN numer. Car selection based on VIN number. VIN programs Accept Icon Allows to accept... -
Page 6: Keypad
I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER KEYPAD Keypad below the multi-touch screen is another way to navigate DiagProg4 menu. KEYPAD – BUTTONS BUTTONS FUNCTION Accept Button Button to ACCEPT... -
Page 7: Setup
Power supply to connected module and OBDII connector OTHER SETTINGS Settings modification: e.g. contrast, volume POWER SAVING Switch ON/OFF screensaver SECURITY DiagProg4 additional security measures TESTS Tests available for the user WIFI SETTINGS WIFI settings modification ©Elprosys April 2019 − Rev. 3.1... -
Page 8: Submenu Information
I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER SUBMENU INFORMATION ABOUT DIAGPROG4 Information about DiagProg4 CONTROL NUMBER Used for registration in customer zone at www.diagprog4.com DATE/TIME Information about date and time DEVICE LIMITS Information about DiagProg4 limits AGREEMENT OF USE... - Page 9 Immediate restart in order to reload operating system RESTORE THE BACKUP MODULE Restore backup file saved on SD card SENDING LOG FILE Send *.LOG file to ElproSys server for technical support SUPPORT SCRIPT Runs support script prepared for user by technical support team UDS COMMUNICATION CONTROL...
-
Page 10: Menu - Subject Of Programming
I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER 10 MENU – SUBJECT OF PROGRAMMING Menu – Subject of programming can be Menu for CARS, MOTORBIKES and OTHER VEHICLES. EXEMPLARY PROGRAMMING MENU ©Elprosys April 2019 − Rev. 3.1... -
Page 11: Exemplary Programming
I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER 11 EXEMPLARY PROGRAMMING Exemplary programming of Alfa Romeo \ 146/146 \ ST5249 MENU FOR BRAND SELECTION MENU FOR MODEL SELECTION MENU FOR MODULE SELECTION MENU FOR THE TYPE OF PROGRAMMING SELECTION ©Elprosys April 2019 − Rev. 3.1... -
Page 12: Basic Settings
Information about WIFI enabled by default is stored on SD card. Without SD card device will not remember WiFi network. LANGUAGE settings Select SETUP , next select LANGUAGE from the menu and accept with OK button. ©Elprosys April 2019 − Rev. 3.1... - Page 13 I N S T R U C T I O N M A N U A L DIAGNOSTIC TESTER SENDING LOG FILE If any error occurs during module programming DiagProg4 sends LOG file to ElproSys server for Technical Support. SENDING LOG FILE MANUALLY Select TOOLS , next select SENDING LOG FILE from the menu.
-
Page 14: Diagprog4 Manual Update
DIAGNOSTIC TESTER 13 DIAGPROG4 MANUAL UPDATE Connect DiagProg4 to PC via mini USB cable (Linux, Unix, MAC OS, Android or Windows), it will appear as an additional external drive. Save update.dpu file, received directly from ElproSys or its representative in the main folder of microSDHC card and restart the device which will be automatically updated. -
Page 15: Display Firmware Update
If the device screen does not respond to touch, it is possible to restart it to restore its efficiency. Press and hold buttons - up and - cancel for at least 3 seconds to restart DiagProg4 device. ©Elprosys April 2019 − Rev. 3.1... -
Page 16: Diagprog4 Manager
Software used to manage device using PC. DiagProg4 connection with PC: It is required to use mini USB cable supplied by manufacturer in order to connect DiagProg4 with PC. DiagProg4 should be connected to an additional power source. Software update Use this option to download latest update and activations from Elprosys server. -
Page 17: Descriptive Menu
Software requirements: .Net Framework 4.5 or above 18 DESCRIPTIVE MENU Some DiagProg4 functions will show additional hints. When a position is selected from the menu device will display additional descriptive menu. In order to display hint select a position from the menu, press it and hold it. - Page 18 Adding description for option: SENDING LOG FILE manually 03.03.2016 Czupryna Sylwester Adding description for option: MAINTANANCE 03.03.2016 Czupryna Sylwester Adding description for option: RESTART DIAGPROG4 Adding description for option: DESCRIPTIVE MENU 03.03.2016 Czupryna Sylwester Change in TOOLS MENU – adding new positions: - DOWNLOAD UPDATE/ ACTIVATION 03.04.2017...
