Indoor Vandal Proof 27x PTZ Dome
User Manual
NY: 55 Mall Drive • Commack, NY 11725 (800) 422-6707
CA: 20521 Earl Street • Torrance, CA 90503 (877) 407-9555
www.computarganz.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT127N and is the answer not in the manual?

Questions and answers

Summary of Contents for CBC PT127N

  • Page 1 All manuals and user guides at all-guides.com Indoor Vandal Proof 27x PTZ Dome User Manual NY: 55 Mall Drive • Commack, NY 11725 (800) 422-6707 CA: 20521 Earl Street • Torrance, CA 90503 (877) 407-9555 www.computarganz.com...
  • Page 2 All manuals and user guides at all-guides.com This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 All manuals and user guides at all-guides.com NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference.
  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com CONTENTS ○ Introduction Features Product & Accessories Parts Name & Functions ○ Installation Terminal Cover Dis assembling / Assembling DIP Switch Setup Direct Installation on the Ceiling Installation using In-Ceiling Mount Bracket Installation using Ceiling Mount Bracket Installation u sing Wall Mount Bracket Cabling...
  • Page 5: Introduction

    All manuals and user guides at all-guides.com INTR ODUCTION Features Camera Specifications CCD Sensor : 1/4" Super HAD color Zoom Magnification : × 27 Optical Zoom, × 12 Di gital Zoom (Max × 324 Zoom) Day & Night Functi Various Focus Mode : Auto-Focus / Manual Focus / Semi-Auto Focus.
  • Page 6 All manuals and user guides at all-guides.com INTRODUCTION PTZ(Pan/Tilt /Zoom) Control With RS-485 communication, max. 255 of cameras can be controlled at the same time. Pelco-D or Pelc o-P protocol can be selected as a control protocol in the current version of firmware. OSD(On Screen Display) Menu OSD menu is provided to display the status of camera and to configure the functions interactively.
  • Page 7: Product & Accessories

    All manuals and user guides at all-guides.com INTRODUCTION Product & Accessories Product & Accessories Main Body / Terminal Cover Dome Cover Screws Options Fflush Mount Model(FMK4) Pendant Mount Model(PMK4) Wall mount Model(WMK4) 7/47 Speed Dome Camera Instruction Manual...
  • Page 8: Parts Name & Functions

    All manuals and user guides at all-guides.com INTRODUCTION Parts Name & Functions Lockup Screw Terminal Cover Mounting Hole Drop Prevention Spring Fuse Cabling Drop Prevention Terminal Block Hook Main Body Connector Dome Cover Main Body / Terminal Cover Terminal Cover Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust.
  • Page 9: Installation

    All manuals and user guides at all-guides.com INSTALLATION Terminal Cover Disassembling ① Remove the Lockup Screw as shown bellow. ② Turn main body on its axis in CCW(Counter- clockwise) direction and separate it from Terminal Cover. Terminal Cover Assembling ① Check if the su ②...
  • Page 10: Dip Switch Setup

    All manuals and user guides at all-guides.com INSTALLATION DIP Switch Setup fore you install the camera, you should set th e DIP s witches to configure the camera ID, communication protocol. Do not use the ISP connector. (Authorized person only !) ISP connector (for System Upgrade) Communication...
  • Page 11 All manuals and user guides at all-guides.com INSTALLATION Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol/Baud rate (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Otherwise Reserved If you want to control using DVR or P/T controller, their protocol must...
  • Page 12 All manuals and user guides at all-guides.com INSTALLATION Terminal resistor Setup Terminal resistor is used if your system is one of following two cases. Case 1: C ontrol c able between camera and co ntroller is rela tively v ery lo ng (1:1 c onne ction)
  • Page 13: Direct Installation On The Ceiling

    All manuals and user guides at all-guides.com INSTALLATION Direct Installation on the Ceiling ① To pass cables to upside of ceiling ② For cable connection, remove the pre-defined , please, make about 50~60mm hole on the ceiling panel. hole mark on the Rubber Gasket and locate the summit of the Plate Spring at the arrow mark as shown in the dotted cir cle.
  • Page 14 All manuals and user guides at all-guides.com INSTALLATION ⑤ Check the 2 mold line for assembly before ⑥ Tighten the Lockup Screw as shown bellow. starting assembly. Line up the mold lines as shown in the dotted circle and turn main body on axis CW(Clock-Wise) direction...
  • Page 15 All manuals and user guides at all-guides.com INSTALLATION Installation using Flush Mount Bracket ① ② Assemble Terminal C er of camera to the In- Cut the panel of ceiling as shown bellow. Ceiling Mount Bracket as shown bellow. Hole Dimension(mm) ③...
  • Page 16 All manuals and user guides at all-guides.com INSTALLATION Installation using Pendant Mount Bracket ① To pass cables to upside of ceiling, please ② Assemble Terminal Cover to Ceiling Mount make about 50~60mm hole on the ceiling panel and racket with 3 screws. ( Do not use Rubber attach the Ceiling mount bracket on it.
  • Page 17: Installation Using Wall Mount Bracket

    All manuals and user guides at all-guides.com INSTALLATION Installation using Wall Mount Bracket ① Install Wall Mount Bracket on wall. ② Assemble Terminal Cover to Wall Mount Bracket with 3 screws. (Do not use Rubber Gasket !) Locate the summit of the Plate Spring at the arrow mark.
  • Page 18: Cabling

    All manuals and user guides at all-guides.com INSTALLATION Cabling Power IrDA Sensor PWR(+) Door PWR(-) IN COM+ Switch VIDEO(+) Moinitor VIDEO(-) Sensor RS-485(+) RS-485(-) RELAY1 RELAY2 Light RS-485 Alarm Buzzer Controller / DVR Output Devices Terminal Cover Power Connection Please, check the voltage and current capacity of rated power carefully. Rated power is indicated in the back of main unit.
  • Page 19 All manuals and user guides at all-guides.com INSTALLATION Alarm I/O Connection Sensor Input Internal +5V~12V IN COM+ Sensor 1 Output IN 1- Sensor 4 Output IN 4- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output gnal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.
  • Page 20 All manuals and user guides at all-guides.com 20/47 Speed Dome Camera Instruction Manual...
  • Page 21: Operation

    All manuals and user guides at all-guides.com OPERATION Check points before operation Before power is applied, please check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading DIP switch of the camera.
  • Page 22: Start Osd Menu

    All manuals and user guides at all-guides.com OPERATION Starting OSD Menu Function Using the OSD menu, Preset, Pattern, Swing, Group and Alarm I/O function can be configured for each application. Enter Menu <Go Preset> [95] Reserved Preset Description Some Preset numbers are reserved to special functions. Function <Go Preset>...
  • Page 23: Preset

    All manuals and user guides at all-guides.com OPERATION Preset Function ax. 127 positions can be stored as Preset position. The Preset number can be assigned om 1 to 128, but 95 is reserved for starting OSD menu. Camer a characterist ics (i.e.
  • Page 24: Pattern

    All manuals and user guides at all-guides.com OPERATION Pattern Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern.
  • Page 25: Group

    All manuals and user guides at all-guides.com OPERATION Group Function The group function allows running sequence of Presets, Pattern and/or Swings. Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or swing. Preset speed can be set up and the repeat number of Pattern & Swing can be set up in Group setup.
  • Page 26: Other Motion Functions

    All manuals and user guides at all-guides.com OPERATION Other Functions Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, Swing and Group are available for this function but Jog actions are not available to resume.
  • Page 27: Osd Display Of Main Screen

    All manuals and user guides at all-guides.com OPERATION OSD Display of Main Screen Action Title Preset Label LABEL12345 PRESET1 Alarm Information I:1--- O:-2 Camera ID CAM 1 15/4/x1/N P/T/Z Information P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction. Camera ID Current Camera ID(Address).
  • Page 28: How To Use Osd Menu

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu. For all menu level, to go into sub menu, press NEAR key. To go to up-one-level menu, press FAR key.
  • Page 29 All manuals and user guides at all-guides.com HOW TO USE OSD MENU Display Setup This menu defines Enable/Disable of OSD display on Main Screen. If an DISPLAY SETUP item is set to be AUT O, the item is displayed only when the value of it is ------------------------ CAMERA ID changed...
  • Page 30: Privacy Zone Mask Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU PRIVACY ZONE MASK Setup Select area in image to mask. PRIVACY ZONE ------------------------ MASK NO Mask No [1~8] UNDEFINED DISPLAY Select Mask num ber. If the selected mask has CLEAR MASK CANCEL read...
  • Page 31: Camera Module Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU CAMERA SETUP Setup the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO Focus Mode [AUTO/MANUAL/SEMIAUTO] DIGITAL ZOOM LINE LOCK Sets ca mera focus mode. IMAGE FLIP SHARPNESS SEMIAUTO Mode...
  • Page 32 All manuals and user guides at all-guides.com HOW TO USE OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL ------------------------ In Manual mode, Red and Blue level can be set WB MODE AUTO ADJUST up manually BLUE ADJUST [0~255] Red Adjust Blue Adjust...
  • Page 33 All manuals and user guides at all-guides.com HOW TO USE OSD MENU Shutter Speed [ESC/A.Flicker/Manual(×256~1/120000 sec)] If Iris is set to Manual and Shutter Speed is set to ESC, Shutter Speed should have highest priority. If tter Speed is set to A.Flicker, to remove Flick er, Shutter Speed should be set to 1/100 sec.
  • Page 34 All manuals and user guides at all-guides.com HOW TO USE OSD MENU HLC (High Light Compensation) Setup Limit [AUTO/MANUAL] ------------------------ When there are too bright lights, this function LIMIT COLOR blocks light sources on the images to have better images. For examp le, when there is a car coming to a camera at night, this function bocks car headlights to recognize its number...
  • Page 35: Motion Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU Motion Setup Setup the general functions of Pan/Tilt moti ons. MOTION SETUP ------------------------ Motion Lock [ON/OFF] MOTION LOCK PWR UP ACTION If Motion Lock is set to ON, it is impossible to AUTO FLIP set up and delete Preset, Swing, Pattern and JOG MAX SPEED...
  • Page 36 All manuals and user guides at all-guides.com HOW TO USE OSD MENU Parking Action Setup If Park Enable is set to ON, camera runs assigned function automatically PARKING ACTION SETUP ------------------------ if there is no PTZ comma nd during a ssigned "Wait Time".
  • Page 37: Preset Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU PRESET Setup Preset Number [1~128] PRESET SETUP ------------------------ If a selected preset is already defined, camera PRESET NO. moves to pr e-defined position and preset CLR PRESET CANCEL characteristics such as Label and Relay Outputs <EDIT SCENE>...
  • Page 38 All manuals and user guides at all-guides.com HOW TO USE OSD MENU Edit Preset Scene ○ Using Joystick, move camera to desired position. EDIT SCENE - PRESET 1 ------------------------ ○ By pressing NEAR k ey, save current PTZ data. ○ Press FAR key to ca ncel.
  • Page 39 All manuals and user guides at all-guides.com HOW TO USE OSD MENU Relay Out Setup Relay Out × [ON/OFF] RELAY OUT - PRESET 1 ------------------------ Sets Relay Outputs for assign ed preset. RELAY OUT 1 RELAY OUT 2 BACK EXIT 39/47 Speed Dome Camera Instruction Manual...
  • Page 40: Swing Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU Swing Setup Swing Number SWING SETUP ------------------------ lects Swing number to edit. If a selected Swing SWING NO. 1ST POS. NOT USED has not defined, "NOT USED" is displayed in 1st 2ND POS.
  • Page 41: Pattern Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU Pattern Setup Pattern Number ~4 ] PATTERN SETUP ------------------------ Selects Pattern number to edit. PATTERN NO. UNDEFINED If a selected pattern number is not defined, CLR PATTERN CANCEL <EDIT PATTERN>...
  • Page 42: Group Setup

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU Group Setup Group Number [1~8 GROUP SETUP ------------------------ Sele cts Group number to edit. GROUP NO. UNDEFINED If a selected Group number is not defined, CLEAR GROUP CANCEL <EDIT GROUP>...
  • Page 43 All manuals and user guides at all-guides.com HOW TO USE OSD MENU ④ Set up items such as Action, ###, Dwell and OPT. EDIT GROUP 1 ------------------------ NO ACTION ### DWELL OPT ------------------------ 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ BACK...
  • Page 44: System Initialize

    All manuals and user guides at all-guides.com HOW TO USE OSD MENU System Initialize Clear All Data Deletes all configuration data such as display, SYSTEM INITIALIZE camera, motion setup and so on. ------------------------ CLEAR ALL DATA CLR DISPLAY SET Clear Display Set Initializes Display Configuration CLR CAMERA SET CLR MOTION SET...
  • Page 45: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Specifications Appearance Model PT127N PT127P Video Signal System NTSC 1/4' ' Super HAD color CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 550 TV Line(Color), 680 TV Line(B/W)
  • Page 46 All manuals and user guides at all-guides.com SPECIFICATIONS Dimension Main Bod y & Terminal Cover Flush Mount Hole Dimension(mm) nt Mou Wall Mount Bra cket 56.3 56.3 56.3 56.3 Unit (mm) 46/47 Speed Dome Camera Instruction Manual...
  • Page 47 All manuals and user guides at all-guides.com 47/47 Speed Dome Camera Instruction Manual...
