Related Manuals for OHD QuantiFit 2
Summary of Contents for OHD QuantiFit 2
- Page 1 C o n t a c t w w w . O H D G L O B A L . c o m + 1 2 0 5 . 9 8 0 . 0 1 8 0 U s : t e c h s u p p o r t @ o h d g l o b a l .
-
Page 2: Table Of Contents
................................. 9 Navigation ..................................11 Performing a Test ................................16 Reports ....................................18 Daily Verification ................................19 Onboard Settings ................................20 OHD Logic ..................................24 Software Updates ................................26 Home Screen .................................. 27 People ....................................31 Company ..................................32 Tests .................................... -
Page 3: Introduction
Welcome The QuantiFit2® can be used standalone or with OHD Logic software. When testing without a computer, all reports and test data may be retrieved from the instrument. Data can be imported into Logic software. The instrument is not compatible with FitTrack Gold, which comes with the legacy Quantifit. - Page 4 Before and after fit test steps, when the test subject is wearing a respirator, his or her inhalation is coming through inlets in the OHD adapter kit, and most of the exhalation should travel through the exhalation valve and out of the respirator. There are many potential respirator and adapter configurations.
-
Page 5: How The Quantifit2 Works
How the QuantiFit2 Works The QuantiFit2 functions by creating and maintaining a negative pressure in the respirator. Once the adapter valve is closed, sealing the respirator, the QuantiFit2 removes air from the respirator until the challenge pressure is reached. When the challenge pressure is reached, if there isn’t a leak, the QuantiFit2 doesn’t remove any more air from the respirator. -
Page 6: Instrument Setup
Instrument Setup What comes with the QuantiFit2? o The QuantiFit2 Respirator Fit Tester o Triple tube set o Power supply and power cord o USB cable o Hard case with extendable handle and wheels o Logic software o Calibration Certificate Unpacking the QuantiFit2 Carrying Case: Release the two latches on the front of the case by depressing the moveable lever under each latch. - Page 7 Instrument Setup Instrument Front Connections A. Carrying Handle B. Color Touch Screen C. Clear Tube Connection D. Gray Tube Connection E. Blue Tube Connection F. Verification Connection for Gray/Clear Tube G. Verification Connection for Gray/Clear Tube H. Verification Connection for Blue Tube I.
- Page 8 CAUTION: It is vital to open Logic software to pair the device. See Logic Software section. OHD Logic software allows users to run multiple machines simultaneously, with flexibility on the start time for any test. Standard Bluetooth allows testing to happen from across the room.
- Page 9 Instrument Setup Connecting Tubes It is best to connect the metal quick connects while holding onto the tube and not the connection. The metal quick connect will click into place. The tubing set consists of three tubes (blue, gray, and clear). Out of the six ends of the tube assembly, there is only one male connection, which will always go into the large circle on the front of the unit.
-
Page 10: Startup Wizard
Startup Wizard Language Select your preferred language here. Regulation The operator will be required to select the regulation that will be followed for testing in any specific region. This can be changed in the Settings>Admin Menu screen if there is a need to switch regulations. - Page 11 Startup Wizard Daily Verification Wizard This section will guide the operator through a daily verification. This must be performed every day of testing. Upon starting the instrument each day, the Daily Verification screen will appear. See the Daily Verification of this manual for more information. People/Test After the daily verification check has been performed, the wizard will move on to the People...
-
Page 12: Navigation
Navigation The QuantiFit2 is operated by the color touch on the front of the instrument. When pressing any button, there will be a “click-tone”. The volume of this tone can be changed in the System Settings menu. There are five major modules to select from: People/Test: Where people are added, edited, or imported, and where tests are initiated. - Page 13 Navigation DOWNLOAD – For loading people into the QuantiFit2 from the OHD Logic software EDIT – Allows the operator to change information for the selected item GO BACK – The back button will allow the operator to return to the previous screen GO DOWN –...
- Page 14 Navigation PRINT – The print button allows the user to print a report related to the current screen REPORTS – Brings the operator to a section enabling them to print reports by date or company RETRY – When a test step is interrupted, this allows the test subject to retry that step SAVE –...
- Page 15 Navigation People Search Test subjects may be searched by last name or by their personal ID. Click the button to be used for the search. The search will be defaulted to Last Name. Press the X at the end of the search bar to reset all search criteria.
- Page 16 CAUTION: After deletion, a test subject cannot be restored. Download The download feature allows test subjects to be uploaded in bulk. This can be done through a CSV file from the OHD Logic software. See Appendix B: Import Personnel Template import requirements.
-
Page 17: Performing A Test
Performing a Test Test Screen The test screen prompts the operator or test subject to select or fill in the details of the test. This includes Respirator, Size, and Operator. The Respirator selection will only show the respirators that have been selected during the setup wizard or in the Setup Respirators module on the... - Page 18 Performing a Test Initiating the test step: With Auto Start o If the Auto Start feature is turned on: Instruct the test subject to take a comfortable breath preparing to hold it once the circle in the lower right corner fills with green. •...
-
Page 19: Reports
Reports Reports may be printed at the time of the test, or any time after the testing has been completed. The following reports are available on the QuantiFit2: Fit Test Reports o Individual A single-page report that contains all required data for a respirator fit test record. -
Page 20: Daily Verification
Whenever the triple tube assembly is changed. Troubleshooting: If the instrument does not pass the daily verification, troubleshooting information will be displayed. If the verification will not pass after troubleshooting steps, the unit may require service. Contact OHD technical support (techsupport@ohdglobal.com. -
Page 21: Onboard Settings
Signature Capture allows the operator to turn off the signature capture at the end of each test if the signatures are not necessary or required. System Information The information button will display helpful information when contacting OHD for support including: o System Version – The current version of on-board software o Cycle Count –... - Page 22 Onboard Settings o Current Time – Can be changed by touching the current value Setup Respirators The QuantiFit2 is populated with an extensive list of respirators. When selecting respirators, only those turned "on” will be available as a selection on the Test Information screen during a fit test.
- Page 23 Onboard Settings Add Parameter The Add Parameter function will allow an operator to customize options for a particular respirator if the desire is to test outside of the standard testing parameters. You will need to enter: o Parameter name o Challenge Pressure: The negative pressure rate at which a respirator is tested 0.58 in H O is used in the APR parameters •...
- Page 24 Language Change selected language Update Software Occasionally there will be updates to the on-board software. OHD will notify customers when an update is available if the unit has been registered. The notification will come via email. The update can be downloaded from a website and saved to a USB Drive. With the USB Drive in any port on the back of the instrument, the Update Software button will ask the operator to select the update file.
-
Page 25: Ohd Logic
OHD Logic OHD Logic Software is intended to be driven by icons, and each icon function can be viewed by mousing-over the icon. In the case of the icons on the left sidebar, the Menu icon at top left can be clicked, and the menu will pop-out to display the names next to each icon. - Page 26 OHD Logic OHD Logic Software is to be installed on a PC running Windows software version 10 or greater. PC requirements: o Processor Speed: 1.0 GHz or greater o RAM: 1 GB or greater o Disc Space: 16 GB The installation must be completed by someone logged onto the PC who has administrative privileges.
-
Page 27: Software Updates
Software Updates OHD Logic software will be updated periodically to enhance features, add features, or fix bugs. In Settings section, there is an option to automatically receive updates. If this is not turned on, whenever the Update menu is selected, the software will check to see if an update is available and there will be an option to update or not. -
Page 28: Home Screen
Home Screen After initial setup, most people can do any task required directly from the Home Screen. This includes running tests, adding people, adding respirators, viewing test statistics, and identifying those people who are due for testing. Each of the modules seen on the Home Page can be collapsed by clicking on the no- view icon. - Page 29 Home Screen Test Creator To perform a fit test, it must be launched from the Test Creator. The Test Creator is a simple guide to record pertinent test information and to initiate the test. All fields must be complete for the Start button to appear. o Operator Add first name and last name to the operator selection.
- Page 30 Home Screen Select a size from the drop-down menu. o QuantiFit2 Use the drop-down menu to select the instrument you want to use for testing. If a QuantiFit2 has not been registered to the software, this will need to be done through the Settings/Devices menu. If only one unit is registered, this field will be populated with that instrument.
- Page 31 Home Screen Past Due Viewer This tool allows the operator to quickly view those who are due for a test. The list will show any person in the database who is within a month of needing testing. By default, the "Hide Never Tested" box is left unchecked. In addition to those due for testing, the list will also contain those people in the database who have never been tested.
-
Page 32: People
People The people list shows the people in the currently selected company who have not been made inactive. The All Companies box can be checked for a list of people throughout all companies. Users can be made inactive if they have left their position, or no longer require fit testing. Their records will not be deleted, but they will be hidden from view. -
Page 33: Company
Company Many QuantiFit2 users will have only one company, while others might have dozens, depending on the needs for testing. The purpose for a Company is to create a division within the database. The company name will appear on the top of the fit test reports. Company divisions are not necessary and are only for convenience. -
Page 34: Tests
The test screen is where any active test can be viewed. This may be one test, or it may be for an operator who is controlling multiple instruments. The QuantiFit2 allows users to run countless machines simultaneously through the OHD Logic software (as many machines as an operator is capable of overseeing), with flexibility on the start time for any test. - Page 35 Tests The testing sequence When initiating a test from Logic, the software will display the inhalation valve message reminder, and then display the tube connection instructions. These two screens can be turned off by checking the box next to "Hide these messages next time." The test subject will view a message that says, "Device is in remote mode.
- Page 36 When Security is activated, to gain access to the software, a person will need login credentials. These credentials either will be assigned to Operator or Administrator status. o Operator status allows a person to log into OHD Logic and run tests, reports, add people and all the regular functions of a fit testing program.
- Page 37 Date Format allows the Administrator to select the type of date format preferred. (MM/DD/YYYY, DD/MM/YYYY, YYYY/MM/DD) o Allow Reporting When this feature is allowed, the software will send errors to OHD. This will help OHD to continue to refine the software, and it may help with troubleshooting issues.
-
Page 38: Devices
Devices Connecting the QuanitFit2 to Logic Under the settings section, click on Devices. You can connect via USB or Bluetooth. Once your serial number appears below this button, click on Register button, then it will appear on the right as shown below. To test connection, highlight your serial number and click the Test connection button to confirm. -
Page 39: Respirators
Every effort is made to keep this respirator list up to date, but if a respirator that is being used does not appear on the list, it may be added. OHD would like to be notified if a respirator is not listed (techsupport@ohdglobal.com) so that we may update our... - Page 40 About In the About section, information is included for: OHD Contact Information Address: 2687 John Hawkins Pkwy, Hoover, AL 35244, USA Phone: +1-205-980-0180 Website: www.ohdglobal.com Email: sales@ohdglobal.com, techsupport@ohdglobal.com...
-
Page 41: Reports
You can add your logo to your reports by clicking on Change Logo button and selecting your image file. If you click Reset Logo, it will revert to the default OHD logo. There are several types of reports that can be produced from OHD Logic. -
Page 42: Troubleshooting
1. The inhalation valve can be propped open from the outside of the respirator before the adapter is connected. 2. Use an OHD valve prop to keep the valve intact and open during the fit test (pictured here). 3. If a valve prop is not available, other materials may be used. Take care not to damage the valve when inserting an object to prop it open. - Page 43 1. Check for proper tension of respirator to face. 2. Try a different size or different respirator. 3. Check fit test adapter for leaks. Check Troubleshooting section 3. Adapter Fault below. OHD provides this as an optional service during yearly calibration...
- Page 44 Troubleshooting Traceline way above challenge pressure line The QuantiFit2 traceline goes opposite of the direction of the pressure. If the line is above the challenge pressure line, that means that there is too much negative pressure. In this case, a test subject is most likely continuing to draw a breath in during the test.
- Page 45 3. Be sure that the mask is centered on the head, and that the straps are pulled equally on both sides. 4. Try a different size or different respirator. 5. Check adapter for leaks Check Troubleshooting section 3. Adapter Fault below. OHD provides this as an optional service during yearly calibration. Fit Factor of 0...
- Page 46 If the QuantiFit2 passes the daily verification procedure, this assures that the instrument is operating properly and measuring within tolerance. c. If the QuantiFit2 is not able to complete the Daily Verification Check. Please contact OHD Tech Support to troubleshoot before sending in for service.
- Page 47 Possible Solution: o Turn QuantiFit2 off, wait 15 seconds, power on, and retry Daily Verification. o Remove and replace all tubes. o Contact OHD Tech Support to evaluate problem or to arrange return to OHD Service Department. Bluetooth Connection Issues If you are having issues connecting via Bluetooth, make sure you are pairing from the Logic Software and not through Windows settings.
- Page 48 Check to make sure it is not too close to any other USB devices. Sometimes unshielded USB devices can interfere with Bluetooth connections. Should service be needed for your instrument, contact the OHD Service Department. For those instruments outside the U.S.A., contact OHD to find the nearest service center.
-
Page 49: Calibration And Maintenance
+/- 0.25%. To ensure the instrument operates at the parameters for which it is designed, OHD requires the QuantiFit2 to receive annual maintenance and calibration at an authorized service facility. -
Page 50: Appendix A: Specifications
USB Interface 4 Type A Ports (Keyboard, USB Memory, Printer) ....................4 1 Type B Port (PC Communication) .......................... 1 PC Requirements for OHD Logic Software Operating System ........................Windows 10 or newer Processor Speed ..........................1.0 GHz or greater RAM ................................ -
Page 51: Appendix B: Import Personnel Template
Appendix B: Import Personnel Template To import a list of names directly into the QuantiFit2, an Excel spreadsheet must be filled out with specific headers (see below). Fields can be empty and will be empty on the unit when imported. After populating the spreadsheet, save to a USB drive. Insert the USB drive into the back of the QuantiFit2 machine. -
Page 52: Appendix C: Terminology
Appendix C: Terminology Air-purifying respirator (APR) a respirator with Fit test the use of a protocol to qualitatively or a filter, cartridge, or canister that removes quantitatively evaluate the fit of a respirator on specific air contaminants by passing ambient air an individual. -
Page 53: Appendix D: Cnp Diagram
Appendix D: CNP Diagram... -
Page 54: Appendix E: Regulations
Appendix E: Regulations Links to select regulations are shown below. Please ensure you are following all applicable standards, regulations, and guidelines. OSHA (Occupational Safety and Health Administration) 1910.134 - Respiratory Protection. | Occupational Safety and Health Administration (osha.gov) CSA (Canadian Standards Association) CAN/CSA-Z94.4-18 | Product | CSA Group UK-HSE (Health and Safety Executive) Guidance on respiratory protective equipment (RPE) fit testing - INDG479 (hse.gov.uk) -
Page 55: Appendix F: Fit Test Adapters
In the case of an SCBA, the respirator might be required to be converted to an air-purifying respirator. OHD testing adapters must be maintained with care. Any dents or cracks that can occur will lose the ability to keep an air-tight seal, which would make it inadequate for testing. - Page 56 C o n t a c t w w w . O H D G L O B A L . c o m + 1 2 0 5 . 9 8 0 . 0 1 8 0 U s : t e c h s u p p o r t @ o h d g l o b a l .
- Page 57 ................................. 9 Navigation ..................................11 Performing a Test ................................16 Reports ....................................18 Daily Verification ................................19 Onboard Settings ................................20 OHD Logic ..................................24 Software Updates ................................26 Home Screen .................................. 27 People ....................................31 Company ..................................32 Tests ....................................
-
Page 58: Introduction
Welcome The QuantiFit2® can be used standalone or with OHD Logic software. When testing without a computer, all reports and test data may be retrieved from the instrument. Data can be imported into Logic software. The instrument is not compatible with FitTrack Gold, which comes with the legacy Quantifit. - Page 59 Before and after fit test steps, when the test subject is wearing a respirator, his or her inhalation is coming through inlets in the OHD adapter kit, and most of the exhalation should travel through the exhalation valve and out of the respirator. There are many potential respirator and adapter configurations.
-
Page 60: How The Quantifit2 Works
How the QuantiFit2 Works The QuantiFit2 functions by creating and maintaining a negative pressure in the respirator. Once the adapter valve is closed, sealing the respirator, the QuantiFit2 removes air from the respirator until the challenge pressure is reached. When the challenge pressure is reached, if there isn’t a leak, the QuantiFit2 doesn’t remove any more air from the respirator. -
Page 61: Instrument Setup
Instrument Setup What comes with the QuantiFit2? o The QuantiFit2 Respirator Fit Tester o Triple tube set o Power supply and power cord o USB cable o Hard case with extendable handle and wheels o Logic software o Calibration Certificate Unpacking the QuantiFit2 Carrying Case: Release the two latches on the front of the case by depressing the moveable lever under each latch. - Page 62 Instrument Setup Instrument Front Connections A. Carrying Handle B. Color Touch Screen C. Clear Tube Connection D. Gray Tube Connection E. Blue Tube Connection F. Verification Connection for Gray/Clear Tube G. Verification Connection for Gray/Clear Tube H. Verification Connection for Blue Tube I.
- Page 63 CAUTION: It is vital to open Logic software to pair the device. See Logic Software section. OHD Logic software allows users to run multiple machines simultaneously, with flexibility on the start time for any test. Standard Bluetooth allows testing to happen from across the room.
- Page 64 Instrument Setup Connecting Tubes It is best to connect the metal quick connects while holding onto the tube and not the connection. The metal quick connect will click into place. The tubing set consists of three tubes (blue, gray, and clear). Out of the six ends of the tube assembly, there is only one male connection, which will always go into the large circle on the front of the unit.
-
Page 65: Startup Wizard
Startup Wizard Language Select your preferred language here. Regulation The operator will be required to select the regulation that will be followed for testing in any specific region. This can be changed in the Settings>Admin Menu screen if there is a need to switch regulations. - Page 66 Startup Wizard Daily Verification Wizard This section will guide the operator through a daily verification. This must be performed every day of testing. Upon starting the instrument each day, the Daily Verification screen will appear. See the Daily Verification of this manual for more information. People/Test After the daily verification check has been performed, the wizard will move on to the People...
-
Page 67: Navigation
Navigation The QuantiFit2 is operated by the color touch on the front of the instrument. When pressing any button, there will be a “click-tone”. The volume of this tone can be changed in the System Settings menu. There are five major modules to select from: People/Test: Where people are added, edited, or imported, and where tests are initiated. - Page 68 Navigation DOWNLOAD – For loading people into the QuantiFit2 from the OHD Logic software EDIT – Allows the operator to change information for the selected item GO BACK – The back button will allow the operator to return to the previous screen GO DOWN –...
- Page 69 Navigation PRINT – The print button allows the user to print a report related to the current screen REPORTS – Brings the operator to a section enabling them to print reports by date or company RETRY – When a test step is interrupted, this allows the test subject to retry that step SAVE –...
- Page 70 Navigation People Search Test subjects may be searched by last name or by their personal ID. Click the button to be used for the search. The search will be defaulted to Last Name. Press the X at the end of the search bar to reset all search criteria.
- Page 71 CAUTION: After deletion, a test subject cannot be restored. Download The download feature allows test subjects to be uploaded in bulk. This can be done through a CSV file from the OHD Logic software. See Appendix B: Import Personnel Template import requirements.
-
Page 72: Performing A Test
Performing a Test Test Screen The test screen prompts the operator or test subject to select or fill in the details of the test. This includes Respirator, Size, and Operator. The Respirator selection will only show the respirators that have been selected during the setup wizard or in the Setup Respirators module on the... - Page 73 Performing a Test Initiating the test step: With Auto Start o If the Auto Start feature is turned on: Instruct the test subject to take a comfortable breath preparing to hold it once the circle in the lower right corner fills with green. •...
-
Page 74: Reports
Reports Reports may be printed at the time of the test, or any time after the testing has been completed. The following reports are available on the QuantiFit2: Fit Test Reports o Individual A single-page report that contains all required data for a respirator fit test record. -
Page 75: Daily Verification
Whenever the triple tube assembly is changed. Troubleshooting: If the instrument does not pass the daily verification, troubleshooting information will be displayed. If the verification will not pass after troubleshooting steps, the unit may require service. Contact OHD technical support (techsupport@ohdglobal.com. -
Page 76: Onboard Settings
Signature Capture allows the operator to turn off the signature capture at the end of each test if the signatures are not necessary or required. System Information The information button will display helpful information when contacting OHD for support including: o System Version – The current version of on-board software o Cycle Count –... - Page 77 Onboard Settings o Current Time – Can be changed by touching the current value Setup Respirators The QuantiFit2 is populated with an extensive list of respirators. When selecting respirators, only those turned "on” will be available as a selection on the Test Information screen during a fit test.
- Page 78 Onboard Settings Add Parameter The Add Parameter function will allow an operator to customize options for a particular respirator if the desire is to test outside of the standard testing parameters. You will need to enter: o Parameter name o Challenge Pressure: The negative pressure rate at which a respirator is tested 0.58 in H O is used in the APR parameters •...
- Page 79 Language Change selected language Update Software Occasionally there will be updates to the on-board software. OHD will notify customers when an update is available if the unit has been registered. The notification will come via email. The update can be downloaded from a website and saved to a USB Drive. With the USB Drive in any port on the back of the instrument, the Update Software button will ask the operator to select the update file.
-
Page 80: Ohd Logic
OHD Logic OHD Logic Software is intended to be driven by icons, and each icon function can be viewed by mousing-over the icon. In the case of the icons on the left sidebar, the Menu icon at top left can be clicked, and the menu will pop-out to display the names next to each icon. - Page 81 OHD Logic OHD Logic Software is to be installed on a PC running Windows software version 10 or greater. PC requirements: o Processor Speed: 1.0 GHz or greater o RAM: 1 GB or greater o Disc Space: 16 GB The installation must be completed by someone logged onto the PC who has administrative privileges.
-
Page 82: Software Updates
Software Updates OHD Logic software will be updated periodically to enhance features, add features, or fix bugs. In Settings section, there is an option to automatically receive updates. If this is not turned on, whenever the Update menu is selected, the software will check to see if an update is available and there will be an option to update or not. -
Page 83: Home Screen
Home Screen After initial setup, most people can do any task required directly from the Home Screen. This includes running tests, adding people, adding respirators, viewing test statistics, and identifying those people who are due for testing. Each of the modules seen on the Home Page can be collapsed by clicking on the no- view icon. - Page 84 Home Screen Test Creator To perform a fit test, it must be launched from the Test Creator. The Test Creator is a simple guide to record pertinent test information and to initiate the test. All fields must be complete for the Start button to appear. o Operator Add first name and last name to the operator selection.
- Page 85 Home Screen Select a size from the drop-down menu. o QuantiFit2 Use the drop-down menu to select the instrument you want to use for testing. If a QuantiFit2 has not been registered to the software, this will need to be done through the Settings/Devices menu. If only one unit is registered, this field will be populated with that instrument.
- Page 86 Home Screen Past Due Viewer This tool allows the operator to quickly view those who are due for a test. The list will show any person in the database who is within a month of needing testing. By default, the "Hide Never Tested" box is left unchecked. In addition to those due for testing, the list will also contain those people in the database who have never been tested.
-
Page 87: People
People The people list shows the people in the currently selected company who have not been made inactive. The All Companies box can be checked for a list of people throughout all companies. Users can be made inactive if they have left their position, or no longer require fit testing. Their records will not be deleted, but they will be hidden from view. -
Page 88: Company
Company Many QuantiFit2 users will have only one company, while others might have dozens, depending on the needs for testing. The purpose for a Company is to create a division within the database. The company name will appear on the top of the fit test reports. Company divisions are not necessary and are only for convenience. -
Page 89: Tests
The test screen is where any active test can be viewed. This may be one test, or it may be for an operator who is controlling multiple instruments. The QuantiFit2 allows users to run countless machines simultaneously through the OHD Logic software (as many machines as an operator is capable of overseeing), with flexibility on the start time for any test. - Page 90 Tests The testing sequence When initiating a test from Logic, the software will display the inhalation valve message reminder, and then display the tube connection instructions. These two screens can be turned off by checking the box next to "Hide these messages next time." The test subject will view a message that says, "Device is in remote mode.
- Page 91 When Security is activated, to gain access to the software, a person will need login credentials. These credentials either will be assigned to Operator or Administrator status. o Operator status allows a person to log into OHD Logic and run tests, reports, add people and all the regular functions of a fit testing program.
- Page 92 Date Format allows the Administrator to select the type of date format preferred. (MM/DD/YYYY, DD/MM/YYYY, YYYY/MM/DD) o Allow Reporting When this feature is allowed, the software will send errors to OHD. This will help OHD to continue to refine the software, and it may help with troubleshooting issues.
-
Page 93: Devices
Devices Connecting the QuanitFit2 to Logic Under the settings section, click on Devices. You can connect via USB or Bluetooth. Once your serial number appears below this button, click on Register button, then it will appear on the right as shown below. To test connection, highlight your serial number and click the Test connection button to confirm. -
Page 94: Respirators
Every effort is made to keep this respirator list up to date, but if a respirator that is being used does not appear on the list, it may be added. OHD would like to be notified if a respirator is not listed (techsupport@ohdglobal.com) so that we may update our... - Page 95 About In the About section, information is included for: OHD Contact Information Address: 2687 John Hawkins Pkwy, Hoover, AL 35244, USA Phone: +1-205-980-0180 Website: www.ohdglobal.com Email: sales@ohdglobal.com, techsupport@ohdglobal.com...
-
Page 96: Reports
You can add your logo to your reports by clicking on Change Logo button and selecting your image file. If you click Reset Logo, it will revert to the default OHD logo. There are several types of reports that can be produced from OHD Logic. -
Page 97: Troubleshooting
1. The inhalation valve can be propped open from the outside of the respirator before the adapter is connected. 2. Use an OHD valve prop to keep the valve intact and open during the fit test (pictured here). 3. If a valve prop is not available, other materials may be used. Take care not to damage the valve when inserting an object to prop it open. - Page 98 1. Check for proper tension of respirator to face. 2. Try a different size or different respirator. 3. Check fit test adapter for leaks. Check Troubleshooting section 3. Adapter Fault below. OHD provides this as an optional service during yearly calibration...
- Page 99 Troubleshooting Traceline way above challenge pressure line The QuantiFit2 traceline goes opposite of the direction of the pressure. If the line is above the challenge pressure line, that means that there is too much negative pressure. In this case, a test subject is most likely continuing to draw a breath in during the test.
- Page 100 3. Be sure that the mask is centered on the head, and that the straps are pulled equally on both sides. 4. Try a different size or different respirator. 5. Check adapter for leaks Check Troubleshooting section 3. Adapter Fault below. OHD provides this as an optional service during yearly calibration. Fit Factor of 0...
- Page 101 If the QuantiFit2 passes the daily verification procedure, this assures that the instrument is operating properly and measuring within tolerance. c. If the QuantiFit2 is not able to complete the Daily Verification Check. Please contact OHD Tech Support to troubleshoot before sending in for service.
- Page 102 Possible Solution: o Turn QuantiFit2 off, wait 15 seconds, power on, and retry Daily Verification. o Remove and replace all tubes. o Contact OHD Tech Support to evaluate problem or to arrange return to OHD Service Department. Bluetooth Connection Issues If you are having issues connecting via Bluetooth, make sure you are pairing from the Logic Software and not through Windows settings.
- Page 103 Check to make sure it is not too close to any other USB devices. Sometimes unshielded USB devices can interfere with Bluetooth connections. Should service be needed for your instrument, contact the OHD Service Department. For those instruments outside the U.S.A., contact OHD to find the nearest service center.
-
Page 104: Calibration And Maintenance
+/- 0.25%. To ensure the instrument operates at the parameters for which it is designed, OHD requires the QuantiFit2 to receive annual maintenance and calibration at an authorized service facility. -
Page 105: Appendix A: Specifications
USB Interface 4 Type A Ports (Keyboard, USB Memory, Printer) ....................4 1 Type B Port (PC Communication) .......................... 1 PC Requirements for OHD Logic Software Operating System ........................Windows 10 or newer Processor Speed ..........................1.0 GHz or greater RAM ................................ -
Page 106: Appendix B: Import Personnel Template
Appendix B: Import Personnel Template To import a list of names directly into the QuantiFit2, an Excel spreadsheet must be filled out with specific headers (see below). Fields can be empty and will be empty on the unit when imported. After populating the spreadsheet, save to a USB drive. Insert the USB drive into the back of the QuantiFit2 machine. -
Page 107: Appendix C: Terminology
Appendix C: Terminology Air-purifying respirator (APR) a respirator with Fit test the use of a protocol to qualitatively or a filter, cartridge, or canister that removes quantitatively evaluate the fit of a respirator on specific air contaminants by passing ambient air an individual. -
Page 108: Appendix D: Cnp Diagram
Appendix D: CNP Diagram... -
Page 109: Appendix E: Regulations
Appendix E: Regulations Links to select regulations are shown below. Please ensure you are following all applicable standards, regulations, and guidelines. OSHA (Occupational Safety and Health Administration) 1910.134 - Respiratory Protection. | Occupational Safety and Health Administration (osha.gov) CSA (Canadian Standards Association) CAN/CSA-Z94.4-18 | Product | CSA Group UK-HSE (Health and Safety Executive) Guidance on respiratory protective equipment (RPE) fit testing - INDG479 (hse.gov.uk) -
Page 110: Appendix F: Fit Test Adapters
In the case of an SCBA, the respirator might be required to be converted to an air-purifying respirator. OHD testing adapters must be maintained with care. Any dents or cracks that can occur will lose the ability to keep an air-tight seal, which would make it inadequate for testing.
