7. Do a pairing operation of the product and the
charging station. Select to enable GeoFence or not
and set the reversing distance.
Note:
It is only necessary to do a pairing operation of
®
the Automower Connect app and the product one time.
3.7.10 Installation of the map objects
Read and understand the instructions about where to
install the map objects. Refer to
install the objects on the map on page 15 .
On the map you can install the objects that follow in the
®
Automower Connect app:
Work areas (A)
•
Stay-out zones (B)
•
• Transport path (C)
Charging station (D)
•
Maintenance point (E)
•
Reference station (F)
•
• Work area, Secondary area (G)
A
B
C
E
For a complete map installation, you must install a work
area and a charging station on the map.
20 - Installation
A work area is specified by virtual boundaries. Maximum
20 work areas and secondary areas can be installed on
a map.
There are two types of work areas:
•
•
To examine where to
A transport path is a specified path between the docking
point in front of the charging station and a work area.
The product can operate automatically in this path, but
does not cut grass. A transport path can temporarily be
enabled and disabled in the app.
Stay-out zones can be made if there are areas where
the product must not operate. A stay-out zone is
specified by virtual boundaries. Stay-out zones can
temporarily be enabled and disabled in the app.
A maintenance point is a specified position where the
product can be parked at. This can for example be used
for a service point where maintenance of the product
is done. The maintenance point is connected to the
docking point with a path.
To install objects on the map, operate the product with
the appDrive installation to add waypoints on the map.
Refer to
3.7.10.1 To install objects on the map
The waypoints (A) are positions that makes the virtual
boundaries and paths (B). The lines are straight
between the waypoints. Add a number of waypoints to
make smooth curves. You can adjust the positions of the
waypoints in the app after the installation of the map.
F
G
D
A
A work area that has a charging station in it or
connected to it with a transport path where the
product operates automatically.
A secondary area is a work area with no charging
station and no transport path. The product must be
moved manually to and from the work area.
To install objects on the map on page 20 .
A
CAUTION:
Do not lift and move the
product between the waypoints when you
install the map objects. Use appDrive for a
correct installation.
