Husqvarna CEORA Razor 43M Operator's Manual page 18

3. Put the 2 top baseplates on top of the lower
baseplate.
4. Attach the top baseplates to the lower baseplate
with 6 couplings. Use a 8 mm hex key to attach the
couplings.
18 - Installation
5. Drill 14 holes in the ground with a 6 mm drill.
6. Attach the charging station to the ground with the
14 supplied screws. Use a 10 mm socket wrench
to attach the screws.
CAUTION:
screws too much.
7. Open the cap on the charging station.
8. Put the mains cable through the slot in the
charging station tower and connect it to the
charging station. Attach the mains cable into to the
cable holder.
WARNING:
cable in the area where the product
cuts. Do not put it where persons can
trip on it.
9. Connect the mains cable to a 100-240V power
outlet.
10. Put the product in the charging station. Push the
ON/OFF button on the product for 3 seconds to
charge the product. Refer to
on page 27 .
Do not tighten the
Do not put the mains
To charge the battery
1691 - 002 - 14.01.2022
