White desk + sofabed combi
Assembly Instructions
1516610
- Please keep for future reference
Dimensions
Length - 191cm
Depth - 97cm
Height - 140cm
Weight - 30kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 15/05/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 1516610
Summary of Contents for Argos 1516610
- Page 1 White desk + sofabed combi Assembly Instructions 1516610 - Please keep for future reference Dimensions Length - 191cm Depth - 97cm Height - 140cm Weight - 30kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2 - 4.
-
Page 3: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Back panel x1 Shelf x2 Side panel x 1 (68.3x20.5x1.5cm) (31.7x38.0x1.5cm) (31.7x39.5x1.5cm) No. 15-01506831-20 No. 15-01503174-20 No. 15-01503173-20 Side panel x2 Drawer front x 1 Base middle x1 (64.7x21.5x1.5cm) (75.4x21.5x1.5cm) - Page 4 Components - Parts Rail pull out chair x1 List f.pull out chair x1 (76.0x8.9x2.6cm) (75.0x6.8x3.0cm) No. 12-02607602 No. 12-03007501 List back f. pull out chair Rail pull out chair x1 (75.0x3.2x2.0cm) (76.0x9.0x2.0cm) No. 12-02007501 No. 12-02007601 List for seat x2 Slat x14 (37.1x3.2x2.0cm) (90.0x6.5x1.5cm)
- Page 5 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 3909-63090 No. 3901-35015 No.
- Page 6 Assembly Instructions Step 1 Attach the dowels the side panels Attach the side panels to the legs with the screws Step 2 Attach the plastic drawer runners to the base middle and the end panel with the screws Beware “forward” and “up”...
- Page 7 Assembly Instructions Step 3 Attach the rail pull out chair to the end panel and the base middle with the screws Step 4 Attach the shelfs the side panels , with the screws Step 5 Attach the table top the side panels with the screws...
- Page 8 Assembly Instructions Step 6 Attach the base middle to the side panel attach with the screws Attach the base middle to the side panel attach with the screws Step 7 Attach the table top to the end panel with the screws...
- Page 9 Assembly Instructions Step 8 Attach the table top to the bed with angles and screws Step 9 Attach the lists for seat to the side panels with the screws Beware the “12,5 mm side”...
- Page 10 Assembly Instructions Step 10 Attach three slats the seat with the screws Step 11 Attach the handles the drawer front with the screws Attach two slats to the list for pull out chair and the list back for pull out chair, with the screws Please note that all angles must be 90 degrees !
- Page 11 Assembly Instructions Step 12 Attach two slats to the rails with the screws Step 13 Attach the rest of the slats with the screws 14 14 14 Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 E-mail: order@fl...
