Dynabook Laptop Components Classified as Requiring Selective Treatment

Dynabook would like to communicate the method of identifying and removing components

contained in Dynabook notebook products, including but not limited to the Dynabook

Satellite Pro E10-S

model, that requires selective treatment based on the European

WEEE Directive, Directive 2012/19/EU of the European Parliament and of the Council on

waste electrical and electronic equipment (WEEE).

All of the instructions provided within this letter can be reviewed in greater detail within the

Satellite Pro E10-S

Series Maintenance Manual.

Tools Required

In order to remove internal components of the

below may be required located in Chapter 4 Replacement Procedures of the Dynabook

Maintenance Manual

Table of Contents

• (Page 2-3) Removing the Lithium Ion Battery (Main Battery)

• (Page 4) Removing the SSD

• (Page 5) LCD, Printed Circuit / Wiring Boards (PCB/ PWB system board)

• (Page 5) Manual Replacement Procedures

• (Page 6) AC Adapter and external provide cables

Satellite Pro E10-S

some tools from the list

Table of Contents

Need help?

Do you have a question about the Satellite Pro E10-S and is the answer not in the manual?

Page 1 In order to remove internal components of the Satellite Pro E10-S some tools from the list below may be required located in Chapter 4 Replacement Procedures of the Dynabook Maintenance Manual Table of Contents • (Page 2-3) Removing the Lithium Ion Battery (Main Battery) •...
Page 2 1. Removing the Lithium Ion Battery (Main Battery) Please refer to the information below for instructions regarding the identification and removal of the lithium ion battery. Further maintenance instructions can be found in section 4.2 of the Satellite Pro E10-S Maintenance Manual.
Page 4 Please refer to the information below for instructions regarding the identification and removal of the SSD. Please refer to the information listed in section 4.4 of the Satellite Pro E10-S Series Maintenance Manual. One Philips screwdriver with type 1 bit will be required to remove the screws indicated in the locations...
Page 5 3. Removing the LCD and Printed Circuit / Wiring Boards Beside the LCD and the main PCB, there are further small PCBs and components which are in the scope of the WEEE Directive. The removal of those components are described in detail in the chapter 4 of associate maintenance manual.
Page 6 AC Adapter, External cables provided with the AC adapter and USB cables Depending on your purchased model there are different AC adopters or cables supplied. Those parts should be recycled as per local requirements.
