Summary of Contents for Mobilogix BAT-X
-
Page 2: Table Of Contents
Tilt ......................................9 Battery ....................................11 Enclosure ....................................11 Services ....................................11 Security ....................................11 Product Specifications..................................12 Mechanical ..................................... 12 Packaging and Handling ................................... 13 Product Marking and Serialization ............................13 Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... - Page 3 10 Glossary and Acronyms ..................................19 11 Document History .................................... 21 Figures Figure 2-1 BAT-X, Front view..............................7 Figure 2-2 BAT-X, Top view ..............................7 Figure 4-1 Mechanical Drawing ............................12 Figure 5-1 BAT-X Label Format ............................. 13 Version 1.1...
- Page 4 Table 3-9 Tilt Orientation Table ............................10 Table 3-10 Battery Specifications ............................11 Table 4-1 Mechanical Dimensions Summary ........................12 Table 5-1 BAT-X Label Description ............................13 Table 6-1 Environmental Specifications ..........................14 Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved...
-
Page 5: Introduction
BAT-X User Guide MOBILOGIX.COM INTRODUCTION PURPOSE The purpose of this document is to provide information regarding the function, features and usage of the BAT-X product. CONTACT INFORMATION Email us at support@mobilogix.com Call us on (949) 748-8895 RELATED PUBLICATIONS AND DOWNLOADS •... -
Page 6: Product Description
The BAT-X is smart logic-enabled to maximize battery life and comes with a fully configurable sensor feature set. Pair the BAT-X with Fusion-IoT for a mobile and modular end-to-end solution to smart asset management. On its own, the BAT-X is a fully capable indoor/outdoor tracking solution providing location and environmental data about asset condition. -
Page 7: Indicators And Accessories
MOBILOGIX.COM INDICATORS AND ACCESSORIES 2.3.1 INDICATORS Data LED Power LED GNSS LED Figure 2-1 BAT-X, Front view Light Sensor Figure 2-2 BAT-X, Top view 2.3.2 ACCESSORIES Charge with any USB Adapter. Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 8: Product Features
10 ms (warm), 55 ms (cold) Sensitivity ~16.4 LSB/°/s (@ 2000°/s range) Table 3-2 Accelerometer Sensor Specifications 3.2.2 TEMPERATURE Parameter Value -40°C – 85 Celsius (°C) Range Table 3-3 Temperature Sensor Specifications Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 9: Pressure
DROP AND IMPACT Parameter Value 1 – 25.5 G Range Table 3-7 Drop and Impact Sensor Specifications 3.2.7 TILT Parameter Value Range 0 - 180 (non-negative) Degrees Table 3-8 Tilt Sensor Specifications Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 10: Table 3-9 Tilt Orientation Table
BAT on side, LED facing user, light sensor on top (sky) BAT on side, LED facing user, light sensor on bottom x= 0, y= 90, z= 90 (ground) x=180, y= 90, z= 90 Table 3-9 Tilt Orientation Table Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 11: Battery
Indoor Location via BLE5 beacons SECURITY • Qualcomm® Trusted Execution Environment • Crypto Engine • Secure Boot • Silabs Hardware Cryptographic Accelerators • AES 128/256 • SHA-1, SHA-2 (SHA-224 and SHA-256) and ECC Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 12: Product Specifications
Front View Side View Bottom View Figure 4-1 Mechanical Drawing Parameter Value Length (mm) 123.00 ± 0.10 Width (mm) 58.00 ± 0.10 Height (mm) 23.38 Weight (g) Table 4-1 Mechanical Dimensions Summary Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 13: Packaging And Handling
PACKAGING AND HANDLING PRODUCT MARKING AND SERIALIZATION 5.1.1 DESCRIPTION The BAT-X product has labels identifying the product’s FCC ID, ISED, as well as barcodes identifying the ICC ID, IMEI and Serial Number. 5.1.2 PART NUMBER Figure 5-1 BAT-X Label Format... -
Page 14: Environmental Specifications
Operating Humidity 0%RH - 100%RH Storage Temperature -20°C - 60°C Storage Humidity 0%RH - 60±25%RH Extended Storage Temperature -20°C - 25°C Extended Storage Humidity 0%RH - 60±25%RH Table 6-1 Environmental Specifications Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 15: Compliances
FCC RF EXPOSURE GUIDANCE STATEMENT In order to comply with FCC/ISED RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times. Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... - Page 16 Afin de se conformer aux exigences d'exposition RF FCC / ISED, cet appareil doit être installé pour fournir au moins 20 cm de séparation du corps humain en tout temps. Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved...
-
Page 17: Safety Recommendations/Disposal
Dispose of used batteries according to the instructions BATTERY DISPOSAL “This product must not be treated as household waste. For more detailed information about recycling electronic components contact your local waste management authority.” Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved... -
Page 18: Warranties
Limited Warranty. Mobilogix, Inc. warrants the Unit to be free from manufacturing defects in material and workmanship for a period of one (1) year from the date of shipment of the Unit to the end user from Mobilogix, Inc. or the authorized reseller, as applicable. -
Page 19: 10 Glossary And Acronyms
Fusion IoT Fusion IoT is a cloud-based application with web and mobile support. Fusion IoT provides visualizations of the data recorded from devices in real time. BAT-X and BTM250 are supported by Fusion IoT out of the box. Operating Modes Operating modes define the behavior of BAT. - Page 20 GPS location fixes are preferred by BAT. FLaaS: Fusion Location as a Service FLaaS provides LaaS to Fusion IoT connected devices by offloading computing to the cloud to save power on the device. Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved...
-
Page 21: 11 Document History
BAT-X User Guide MOBILOGIX.COM 11 DOCUMENT HISTORY Version Date Note of change 11/17/2020 Original release 6/24/2021 ATD500Y release Version 1.1 © 2021 Mobilogix, Inc. All Rights Reserved...
