Important Safety Information

See the Important Safety and Product Information guide in the product box for product warnings and other

important information.

To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,

cutting, or sanding.

When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.

• Pencil

• Drill

• 22 mm (

in.) drill bit or hole saw

• 3 mm (

in.) drill bit

• 4.76 mm (

in.) wrench

• Phillips screwdriver

• Marine sealant (optional)

February 2022

GHS

INSTALLATION INSTRUCTIONS

™

WARNING

CAUTION

NOTICE

GUID-12CE8CB8-5444-4BC0-B8B2-CE732B5A84CA v2

Table of Contents

Do you have a question about the GHS 11 and is the answer not in the manual?

Page 1 ™ INSTALLATION INSTRUCTIONS Important Safety Information WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. CAUTION To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding.
Page 2 VHF radio. If needed, up to two additional 10 m (32 ft.) extension cables can be connected in series with the first extension cable. The maximum allowable total extension cable length between any handset and the VHF radio is 30 m (96 ft.). Extension cables are available from your Garmin dealer or website.
Page 3 Installing the Extension Cable in the Mounting Surface Before drilling a hole to mount the extension cable, you must make sure that the extension cable is long enough to connect to the microphone relocation port or a STATION port on the VHF radio from the selected mounting location (Mounting Considerations, page 1 Using the mounting plate...
Page 4 These trademarks may not be used without the express permission of Garmin. The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. © 2021 Garmin Ltd. or its subsidiaries...
