Fixed Mobile (Executive) Stand Installation and Manual
Model:FIXM-V2
For using this product properly and safely, please follow the contents
of the Installation and Operation Manual to install.
Supports 65" Clear Touch panels.
This stand can carry a maximum weight of 132 Ibs.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FIXM-V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clear Touch FIXM-V2

  • Page 1 Fixed Mobile (Executive) Stand Installation and Manual Model:FIXM-V2 For using this product properly and safely, please follow the contents of the Installation and Operation Manual to install. Supports 65" Clear Touch panels. This stand can carry a maximum weight of 132 Ibs.
  • Page 2 BOM: A-The base B-Underframe D-Fixed parts C-Tray Hardware fittings Cross recessed pocket hexagon head screw M8x20 8pcs Cross recessed pocket hexagon head screw M8x40 5pcs Cross recessed pocket hexagon head screw M8x80 4pcs M8 Hex nut M8x60 4pcs M10 Hex nut M10x6 8pcs M8 Steel washer...
  • Page 3 Step 1: The underframe B is fixed with the base A (As shown in figure 1) (figure 1)
  • Page 4 Step 2: Lock the underframe and the base (As shown in figure 2). ( figure 2)
  • Page 5 Step 3: Adjust the height of the column according to actual requirement, then fix parts of machine on the left and right column (As shown in figure 3). Recommended mounting holes Available size 55 inch intelligent panel 65 inch intelligent panel The specific position can refer installation height to adjust, according to actual requirement.
  • Page 6 Step 4: Install wall mount on the column (As shown in figure 4). ( figure 4)
  • Page 7 Step 5: Assemble the IFP and brackets with right screw (As shown in figure 5). ( figure 5) Step 6: Hang the IFP onto the wall mount with the fastened brackets, and lock the safety screw (As shown in figure 6). Make sure the brakes are locked.
  • Page 8 Step 7: When using a tray, you can remove the locking screw from surface of the aluminum plastic plate, then install the tray on the underframe, two installation methods a and b for your reference (As shown in figure 7). Installation method a Installation method b (figure 7)
  • Page 9 Step 8: After installation, as shown in figure 8. ( figure 8)
