English
MOTOR
PROBlEM
Noisy operation. 1. Incorrect belt tension.
2. Loose motor pulley.
3. Loose pulley cover.
Motor will not start. 1. Not plugged into power outlet.
2. Switch and key not in ON position.
3. Motor cord cut or abraded.
4. Plug on cord is faulty.
5. Fuse on circuit breaks open.
6. Faulty motor.
Motor will not start and fuse 1. Too many electrical machines.
or circuit breaker opens. 2. Incorrect fuse.
3. Wheels do not rotate.
4. Undersized extension cord.
5. Short circuit.
Motor fails to develop full 1. Low line voltage.
power. 2. Faulty motor or capacitor.
Motor overheats. 1. Overload on motor.
2. Poor ventilation of motor.
3. Capacitor failure.
Motor stalls or slows. 1. Motor overload.
2. Low line voltage.
3. Loose wire connections.
4. Faulty motor.
Frequent fuse or circuit 1. Motor overload.
breaker failure. 2. Overload of electrical circuit.
3. Incorrect fuse or circuit breaker.
18
CAUsE
1. Adjust tension. See ASSEMBLY AND ADJUSTMENTS section - "DRIVE BELT
2. Readjust and tighten motor pulley set screw.
3. Readjust and tighten pulley cover mounting screws.
1. Plug it into the power outlet.
2. Insert key and turn the switch ON.
3. Re-set; may be too many machines on line.
4. Contact Service Center or Authorized Service Station.
5. Contact Service Center or Authorized Service Station.
6. Contact Service Center or Authorized Service Station.
1. Turn off other machines and try again.
2. Try time delay fuse, or go to circuit with higher rated fuse or circuit
3. Unplug and turn wheels by hand, move obstruction.
4. Use correct size extension cord, see page 7.
5. Contact Service Center or Authorized Service Station.
1. Check power line for proper voltage.
2. Contact Service Center or Authorized Service Station.
1. Reduce load to motor, feed work slower into blade.
2. Unplug and clean out around motor. Provide better air circulation.
3. Contact Service Center or Authorized Service Station.
1. Reduce load to motor, feed work slower into blade.
2. Check power line for proper voltage.
3. Contact Service Center or Authorized Service Station.
4. Contact Service Center or Authorized Service Station.
1. Reduce load to motor, feed work slower into blade.
2. Too many electrical appliances on same circuit.
3. Have electrician upgrade service to outlet.
CORRECTiOn
TENSION."
breaker.
