  • Page 1 SR-20RM USER GUIDE PLUG INTO THE FUTURE OF TECHNOLOGY...
  • Page 2 Revision History Revision Notes Revision 2.3 was published in V2.3 February of 2022. WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 3: Table Of Contents

    Receiving Your SR-20RM Section 1.1 What's in the Box? Section 2 SR-20RM Preparation Section 2.1 Preparing For Your SR-20RM Section 2.2 Installing Your SR-20RM into a Rack Section 2.3 Installing Your BioDigitalPC ® Section 2.4 SR-20-RM Power Supplies Section 2.5 Networking Your SR-20RM Section 2.6 Powering On Your SR-20RM...
  • Page 4 This manual details installation of the chasis, the components inside of the chassis, and notable features of the SR-20 RM server solution. Installations will be supported by ADDC. Unless otherwise specified, all instructions provided in this manual will assume that a user is a trained technician.
  • Page 5: Section 1.1 What's In The Box

    Section 1.0 - Recieving Your SR-20RM Section 1.1 - What's in the Box? Equipment (Included) • SR-20RM Chassis • SR-20RM Top Cover [Comes Assembled] • BioDigitalPC Server Cards [Check ® Invoice for Quantity] • 2 AC/DC Power Supplies • 4 10Gbps SFP+ Cables •...
  • Page 6: Section 2.1 Preparing For Your Sr-20Rm

    Your SR-20RM is designed to operate at room temperature with its self-contained cooling. Power Considerations When properly configured and installed the SR-20RM can draw up to 800 Watts depending on the number, load, and version of the BioDigitalPC s used.
  • Page 7: Section 2.2 Installing Your Sr-20Rm Into A

    Section 2.2 - Installing Your SR-20RM into a Rack This section provides information on installing the SR-20RM chassis into a rack unit with the quick- release rails provided.  Stability hazard. The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before you slide the unit out for servicing.
  • Page 8: Section 2.3 Installing Your Biodigitalpc

    ® removing them.  Only trained technicians are authorized to work beneath the SR-20RM System Cover and access any of the components inside the system. Section 2.3.1 - Removing the SR-20RM Top Cover:...
  • Page 9 Unlock the locking tab. Step 3: Lift to remove the card from its slot Section 2.3.4 - Replacing the SR-20RM Top Cover Once complete, a technician should replace the SR-20RM Top Cover. WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET...
  • Page 10 Section 2.4 - Installing Your SR-20RM Power Supplies Section 2.4.1 - Remove an SR-20RM Power Supply 1. Push SR-20RM Power Supply locking tab to the left. 2. While holding the locking tab, pull the SR-20RM Power Supply handle and remove.
  • Page 11: Section 2.5 Networking Your Sr-20Rm

    Section 2.5 - Networking Your SR-20RM Section 2.5.1 - Minimal/Testing Equipment 1 10/100 Ethernet Cable 1 External Computer (eg. a laptop) Section 2.5.2 - 1Gbps Networking Schema 2 10/100 Ethernet Cables 1 10/100/1000 Ethernet Cables 2 1 port 10/100/1000 Ethernet Switch RECOMMENDED Section 2.5.3 - 10Gbps Networking...
  • Page 12: Section 2.6 Powering On Your Sr-20Rm

    Section 2.6 - Power On Your SR-20RM Section 2.6.1 - Single Feed Redundant Power Supply Configuration Power Source Section 2.6.2 - Dual Feed Redundant Power Supply Configuration Power Source Power Source  Each Power Source must be capable of the maximum draw of 650W.
  • Page 13 Section 3 - SR-20RM Overview Network Connections Module Number Module Card Slot Number Front Interface WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 14: Section 3.1 Sr-10 Modules

    1Gbps NICs ® attached to an integrated switch. Each switch has two SFP+ 10Gbps connectors and one 1Gbps RJ-45 connector broken out to the rear panel of the SR-20RM (See Section 3.2 for additional information). Each SR-10's integrated switch...
  • Page 15: Section 3.2 Rear Panel

    Section 3.2.1 - AC Power Section 3.2.2 - Management, Switch, and 10Gbps SFP+ Ports KVM Modules Port Remote Management and 1Gbps Ports Switch Hardware Ports 10 Gbps SFP+ Ports WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 16: Section 3.3 Front Panel

    10G-A: An SR-10's 1G-AUX: An SR-10's primary 10Gbps auxiliary one Gigabit. SFP+ Port. 10G-A 10G-B 1G-AUX 10G-A 10G-B 1G-AUX An individual slot's 1Gbps NIC LEDs. One LED for each 1Gbps NIC WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 17: Section 4.1 Login

    The web interface for ROMWare asks for credentials to log in and begin management and/or monitoring of your SR-20RM. Users are supplied with administrative credentials that have been factory set. Only one admin can be logged in at once, through the IP 10.0.1.254.
  • Page 18 SR-10 Power Module. “Clear Faults” will clear faults for this SR- 10's power supply. Clicking on a box will show more information regarding the current status of the DC Power Supplies. WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 19: Section 4.4 Biodigitalpc

    Section 4.4 - BioDigitalPC Power Control & Monitoring ® Displaying the card management features of the SR-20RM is done by clicking the Slot Number. Powers on the BioDigitalPC Server card. ® Immediately removes power from the BioDigitalPC Server card. ®...
  • Page 20 Section 4.4 - BioDigitalPC Power Control & Monitoring ® BioDigitalPC Slot Number The unique SR-20RM slot number ® SR-10 Module Position The position number of the SR-10 Module within the SR-20RM BioDigitalPC Slot Position The Position of the Slot within the SR-10 ®...
  • Page 21 Power Control & Monitoring ® Disable Slot Disables the slot for this SR-10 module. Is Auto-Power On With this enabled, after boot up of the SR-20RM the Enabled BioDigitalPC in this slot will be powered on (if present) ® after delay number of seconds.
  • Page 22: Section 4.5 Sr-20Rm System Settings

    Section 4.5 - SR-20RM System Settings Click on the cog to access the Systems Settings The System Settings allows the user to change four things: ROMware password, the machines IP address, the machines Gateway and the ability to enable or disable the Keypad WWW.ADDC.NET...
  • Page 23: Section 4.6 Sr-20Rm Fdd Stack

    SR-20RMs from one interface. Upon clicking on "Add FDD +" this box will appear. Fill out "FDD IP Adress' and 'FDD Name' and the corresponding SR-20RM will be added to the 'FDD Stack'. 10.0.1.134 WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET...
  • Page 24 Section 4.6 - SR-20RM FDD Stack The "Connect" button will add the SR-20RM ot the "FDD Stack" WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 25 Section 4.6 - SR-20RM FDD Stack After "Connecting" to the added SR-20RM, your screen will now show the new SR- 20RM as the "Controlling FDD" Controlling FDD: 10.0.1.134 WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
  • Page 26 System Startup Screen – Allow 3-4 minutes for system to boot up • ADDC Support Screen – This screen is displayed right after the system boots up and will be closed after ten seconds or it can also be closed by clicking on the red button.
  • Page 27 Section 4.7 - Front Panel Touchscreen Overview • PC Card Slots Power Status Screen – This screen is displayed after the ADDC support screen is closed. WHITE indicates there is no PC Card installed, GRAY indicates there is a PC Card installed but is turned OFF, GREEN indicates that there is a PC Card installed and turned ON.
  • Page 28 Section 4.7 - Front Panel Touchscreen Overview • ADDC Support Screen – This screen is displayed right after the system boots up and will be closed after ten seconds or it can also be closed by clicking on the red button.
  • Page 29 The default session timeout can be changed from ROMWare Lite. Click the logout button to lock the screen WWW.ADDC.NET 516.673.4444 INFO@ADDC.NET ALL PRODUCTS ARE PROUDLY MADE IN THE USA...
