- Page 1 Installation Guide UNIZINC Doc G13 Rev 1 Date 03.09.2021...
-
Page 2: Important Considerations
IMPORTANT CONSIDERATIONS 1) CHECK THE CAPACITY OF THE SUPPORTING FLOOR. 2) CHECK THE LEVELLING OF THE FLOOR. 3) SHELVING SYSTEMS MUST BE ASSEMBLED VERTICALLY. 4) INDIVIDUAL SYSTEMS, WHOSE HEIGHT EXCEED SIX TIMES THE DEPTH OF THE SHELVING, MUST BE ANCHORED TO THE WALL (IN THE UPPER PART). 5) MINIMUM EXTENSION STRENGTH OF THE ANCHORING - 150N (15KG) 6) MARK OUT THE EXACT POSITION OF THE SHELVING ON THE FLOOR 7) ASSEMBLY TOOLS:... - Page 3 UNIZINC FRAME BRACING Frame Height: 2475 Number of Braces Required: Position of the Bracing upper Slot: 1. 5 2. 29 3. 61...
- Page 4 UNIZINC UPRIGHTS This image (below) shows the upright positioned the correct way up. Smaller cutouts immediately above the larger ones. Smaller cutouts. Larger cutouts. BOTTOM...
- Page 5 UNIZINC PLASTIC FOOT ASSEMBLY Insert the plastic foot (1) in the lower part of the upright (2)
- Page 6 ASSEMBLY OF BRACING Before Assembling the frames, make sure you have settled the uprights correctly (upper and lower part) To ensure bracing does Insert the bracing in the not move please ensure internal side of the up- you use the locking clip. right (1) and block it by (Please see image above).
- Page 7 UNIZINC ASSEMBLY OF BEAMS Beams are made up of a length of metal terminated by Red clips. Insert the cur’s lower hooks into the back holes of the upright (1), then turn the beam, insert the upper hooks too and finally push down (2).
- Page 8 ASSEMBLY OF SHELF PANELS Insert the shelf panel (1) in the groove of the beam (2)
- Page 9 UNIZINC BLOCKING BEAMS Fix the blocking beams (1) to the upright (2) with self-tapping screws. Use 1 blocking beam on each run and every 5 modules: Run of 3 modules? 1 blocking beam. Run of 8 modules? 2 blocking beams.
- Page 10 GONDOLA When connecting gondola units together use side clips. Please ensure, to avoid slipping, these are self- tapped into place. When connecting gondola units together use double feet to retain a level unit and avoid damage to the floor surface.
- Page 11 VERSATILITY RESISTANCE CUSTOM DESIGN CUSTOMER CARE Magrini (UK) ltd - CAEM UK Unit 3 - Jamage Industrial Estate Talke Pits - Stoke-On-Trent - ST7 1XW - UK T. 01782 794500 information@caem.co.uk caem.co.uk/unizinc...
