BikeYoke BARKEEPTER STEM Manual

Video/Anleitung
auf Deutsch
BIKEYOKE WARRANTY
All BikeYoke Components are covered for two years from original date of purchase against manufacturer defects
in material and workmanship. The warranty applies only to the original owner and is not transferrable. Proof of
purchase is required. Product must be returned to the original retailer to process any warranty claim. This warranty
does not cover any damage caused through mis-use, crashing or failing to comply by the recommendations given in
this manual. This warranty does not affect your statutory rights.

PREPARATION AND NOTES

1. Ensure that the steerer tube is cut cleanly and level and is free of any burrs (inside
and outside). The stem should sit, once installed on the top of all headset parts and
spacers, so that the steerer tube is approximately 2 to 3mm below the top of the
stem. This is equivalent to 37-38mm of clear space on the steerer tube above all
headset parts and spacers.
See figure A.
2. Ensure the steerer tube and handlebar clamp areas are both clean and dry
(NO GREASE!) .
3. Do not apply any grease on stem bolts or threads! The torque values are for dry bolts.
4. Use your stem only with the original bolts/fasteners and make sure to use the included washers under the
bolt heads. You can also use one of BikeYoke's original Ti bolt upgrade kits, which are custom made for your
BikeYoke Barkeeper stem.
5. Your BikeYoke Barkeeper stem comes in a one piece design. Note, that not every handlebar may be compatible
with this one piece design. Typically, handlebars with rise of up to 30mm will work but it greatly depends on the
shape of the handlebar. Handlebars with more or less rise may or may not work.
6. Depending on the shape of your handlebar, installation may require the
included assembly wedge and assembly screws to spread the clamp for sliding
the stem onto the handlebar easily. Usually, the assembly screws already come
pre-installed in place of the regular M5 bolts. If not, please remove the M5 handlebar
clamping bolts and install the assembly screws instead (from rear side). Make sure
the gap is fully clear. Then fully insert the assembly wedge into the gap. Mind the
orientation of the wedge.
See figure B.
page 1 / 2
MANUAL - BARKEEPER STEM
READ THESE INSTRUCTIONS BEFORE
INSTALLING YOUR STEM!
Riding bicycles can be dangerous. These instructions should be
read thoroughly before installation. Failure to follow these
instructions before installing can result in severe injury or death.

INCLUDED PARTS

1x stem body | 4x stem bolt + washer | 2x assembly screw | 1x assembly wedge

TOOLS REQUIRED

T25 Torx | 2.5mm Hex | Torque Wrench | Caliper

PRODUCT SPECIFICATIONS

Handlebar clamp diameter: Ø 35mm | Stem length: 35mm, 45mm, 55mm | Rise: 0°
Compatible fork steerer tube: 1 1/8" (28.6mm) only | Stack height: 40mm
www.bikeyoke.com
Video/instructions
in English
37-38mm
Fig. A
assembly
screws
assembly
wedge
Fig. B
