KS98+ I/O extensions with CANopen
19.1

RM 211, RM212 and RM213 basic modules

GND
CAN
H
RM 201
CAN-CPU
The connecting terminals can be
withdrawn easily from the modules.
The RM 200 system is a basic module (housing) for snap-on rail mounting with 3, 5 or 10 slots.
The left socket is always reserved for the RM 201 CANopen bus coupler module. Dependent of requirement, I/O mod-
ules or dummies can be plugged into the remaining sockets. The modules click in position in the basic module and can
be released using simple tools for replacement (e.g. small screwdriver).
a
Don't insert or remove modules with the supply voltage switched on.
