USER MANUAL

HOMEVIZ Robotic Vacuum Cleaner G1

V1.0

Table of Contents

Need help?

Do you have a question about the G1 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOMEVIZ G1

Page 1 USER MANUAL HOMEVIZ Robotic Vacuum Cleaner G1 V1.0...
Page 2: Table Of Contents
CONTENTS WHAT'S IN THE BOX PRODUCT INTRODUCTION INSTALLATION INSTRUCTIONS OPERATION INSTRUCTIONS DAILY CARE BASIC PARAMETERS TROUBLESHOOTING COMMON PROBLEMS SPECIAL PROMPTS SERVICE RESTRICTION CONTACT US...
Page 3: What's In The Box
Water Tank *1 Adapter *1 Side Brush *2 Rag *2 Quick Start Guide HOMEVIZ Robotic Vacuum Cleaner G1 V1.0 Rag Holder Board *1 Aroma Stick *2 Quick Start Guide *1 Before using the product, please check whether the package contains the...
Page 4: Product Introduction
PRODUCT INTRODUCTION · Main Device Front Bumper Top Cover Auto-recharge Button Short Press: start the auto-recharge. Power on, oﬀ/Whole House Cleaning Short Press: Start/Stop Cleaning Long Press: hold for 3 seconds for power on/oﬀ Power Indicator Lamp Color Steady white light: works normally White light blinking: enter the network conﬁguration mode Yellow light blinking: recharging/low battery Yellow light breathing: charging...
Page 5 Universal Wheel Main Device Battery Cover Charging Pole Piece Rolling Brush Side Brush Water Tank Driving Wheel Cliﬀ Sensor · Dust Bin Components Dust Bin Handle Dust Bin Dust Bin Release Button Dust Bin Cover Board HEPA Component...
Page 6 · Charging Base Charging Indicator DC Power Jacket Charging Connector · Water Tank Component Water Tank Release Button Water Tank Seal Cover Rag Holder Board...
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Set the Charging Base Place the charging base on a ﬂat surface against a wall. Note: Ensure a space of at least 1.0 m/3.3 ft on both sides of the charging base, and a space of at least 2.0 m/6.6 ft in front. Do not put the charging base near the objects with strong reﬂective surfaces such as mirrors.
Page 8 Charge the device as soon as possilbe when it runs out of power. This product can only use the respective adapter and charging dock equipped with the Homeviz. Battery can not be removed, please contact support@homeviz.net to maintain or replace.
Page 9 3. Install Water Tank 1) Add Water water into the water tank and buckle the plug. 2) Rag Assembly Put the pocket on one end of the rag into the rag holder board, and then stick the rag to the magic sticker of the rag holder board.
Page 10 3) Rag Holder Board Assembly Insert the rag holder board into the slot at both ends of the water tank according to the ﬁgure. 4) Install Water Tank Press the water tank release button and install the water tank into the main device.
Page 11: Operation Instructions
OPERATION INSTRUCTIONS 1. Power On/Oﬀ ① It will automatically turn on when the main device is on the charging base. ② It cannot be turned oﬀ when the main device is on the charging base. ③ Press and hold the POWER button to shut it down when the main device is stationary, and a voice prompt will be given.
Page 12 4. Distribution Network and Firmware Upgrade Scan the QR code on the device to download the app, and long press the button and POWER button to enter the reset Wiﬁ Internet work conﬁguration mode device will be turned on, and you will hear a voice prompt after the power-on is completed. ①...
Page 13 ③ Select a 2.4 GHz Wiﬁ network and enter the password, then tap "Next". ④ Choose "AP Mode" in the upper right corner, then conﬁrm that the indicator light is blinking slowly.
Page 14 ⑤ Connect your phone to the device's hotspot. The Wiﬁ name starts with "SmartLife" followed by "-xxxx". xxxxx...
Page 15 ⑥ After connecting, go back to the TuyaSmart app and wait for its response. The device ﬁrmware can be directly inquired and upgraded through the app. Make sure that the device is charged, and the battery level is not less than 30% when upgrading.
Page 16 5. Pause ① Press the POWER button to pause the device, press again, cleaning continues. ② Press the stop cleaning button on the app to pause the device, and press start cleaning button to continue. 6. Sleep Mode If there is no operation for more than 3 minutes in the standby state, the main device automatically enters sleep mode, and during sleep, it can be awakened by pressing the buttons on the device or the app.
Page 17 9. Mopping Mode Install the rag holder board on the main device, default is I-shaped cleaning and mopping route. The water output can be adjusted through the app, which are: ① Low mode; ② Middle mode; ③ High mode. 10. Add Water to the Water Tank or Wash Rag If you need to add water or clean the rag to the main device during the cleaning process, press the button ﬁrst, and then remove the water tank after pausing.
Page 18: Daily Care
DAILY CARE 1. Dust Bin 1) Remove the ﬂip cover and lift the handle to take out the dust bin. 2) Press the dust bin button as shown in the ﬁgure, open the front cover, and empty trash from the dust bin.
Page 19 3) Remove and change a ﬁlter grid, as illustrated. Note: Filter grid cannot be washed with water, please tap to remove the dust. 4) Open the dust bin, rinse it and the cover. Note: Hang up the dust bin, HEPA and ﬁlter components, keep them dry to ensure the service life.
Page 20 2. Water Tank Components 1) Remove the rag and the rag holder board, rinse and hang up the rag. 2) Press the water tank release button to take out the components.
Page 21 3) Drain the remaining water from the water tank, wipe the tank components and hang them up. 3. Side Brush Check the condition of the side brush from time to time to see if it is damaged or entangled with foreign objects. Use a cleaning tool or a cloth to clean the side brush. Replace it in time when the side brush is damaged and cannot be used.
Page 22 4. Rolling Brush Note: Because the cutting rolling brush components cannot be replaced by yourself, please contact the customer service at support@homeviz.net for help if there is any problem. 5. Other Components 1) Irregularly use a cleaning tool or a dry soft cloth to gently wipe the charging pole pieces and sensor window on the chassis of the device.
Page 23 2) Clean the charging connector of the charging base and charging connector with a dry cleaning tool or a soft cloth. Charging Connector 3) Reset Switch When using the device, if encountered system stuck, no response or other problems, and the power button and APP cannot be used to recover, you can open the ﬂip cover and press the reset button to force the device to shut down.
Page 24: Basic Parameters
BASIC PARAMETERS 1. Main Device Parameters Dimensions L340*W340*H80mm Weight 3.4kg Rated Voltage 14.8V Rated Power 2. Charging Base Parameters Dimensions L164*W133*H104mm Rated Input 20V-0.5A Rated Output 20V-0.5A Rated Frequency 50/60Hz 3. The Name and Contents of Harmful Substances Parts Harmful Substances Cr VI PBDE Plastic...
Page 25: Troubleshooting
Environmental protection use period of 10 years It means that the harmful substances contained in this product will not leak or change, and the normal use of this product according to the product manual will not cause serious pollution to the environment or cause serious damage to the person or property of the user.
Page 26: Common Problems
Fault 08 Abnormal side The side brush is tangled Check whether the side brush brush, please check and and blocked for more than is entangled by the thread and clean the side brush. 12s. clean the entanglement. Fault 09 Please check and Trigger collision Check whether the front remove the foreign objects...
Page 27: Special Prompts
9. Unable to charge. Make sure there is enough space around the charging base, and there is no dust and obstructions on the surface of the charging connector on the charging base. 10. Reservation cleaning Please conﬁrm that the device is connected to the Internet. does not work.
Page 28 3. Use only the original power adapter, otherwise it may cause damage to the product and ﬁre. 4. Do not stand or sit on the product, otherwise it may damage the product or cause a fall. 5. When dust adheres to the metal part of the power plug, be sure to wipe it with a dry cloth.
Page 29 Main device and accessories related using restriction risk 1. Be sure to use a dedicated power adapter, otherwise it will cause leakage heating or rupture. 2. Do not short-circuit the battery or disassemble the battery, otherwise it will cause leakage heating or rupture. 3.
Page 30: Contact Us
Please recycle the waste battery safely and environmentally friendly. CONTACT US For any inquiries about HOMEVIZ products, please feel free to contact us. We will respond within 24 hours. Tel: 301-670-7335 (US) Email: support@homeviz.net...
