MagicControl 4.0 (CM40)
Rev. 01 12/21
The diagnosis page displays the status of the individual machine
components.
It is possible to diagnose the following system components:
General
–
States of guns, axes, light grids, object numbers, object length,
number of objects
Powder guns
–
Current application values, software version of the gun control
units
Axes
–
Swivel axes
Standard axes are displayed under "General"
Inputs/outputs
–
Current state of inputs/outputs, simulation of inputs/outputs
CAN bus
–
Display of the active CAN bus users
Interface
–
Display of the inputs/outputs of the interface to a customer
controller
Application pump
–
Display of the current pressure values of the application pumps
–
Activation of the pinch valve diagnostic of the application pumps
–
Switching the remote operation of the gun control units on/off
Exhaust air
–
Display of the current pressure values of the after filter
– "Running-in filter cartridges" function
