Page 1
Do not install on sloping or soft ground. Please carefully read the following instructions; if in doubt, consult a qualified trades-person. Only use recommended Shelta bases or anchoring systems. To ensure a long life for your Cantilever umbrella: Close the umbrella and cover with the Protective Sleeve between uses.
Page 2
4 x hex keyed SS bolts Winder Handle The Palazzo is best mounted onto a 100mm reinforced concrete slab with 4 x 10mm x 105mm Stainless steel bolts. These need to be purchased separately (not supplied). Alternatively a base can be purchased which makes the umbrella a temporary installation. It should be noted this is not Shelta’s preferred method for installation and does not provide as much support as the bolt down method but it...
Page 3
Mount the Follow in- mounting structions on post to the the next page plate with to mount the the 4 screws mounting provided post to the concrete slab Two people are required to put the umbrella onto the mounting post Put the locking pin into the mast as shown on the left.
Page 4
Drill hole to 100mm depth with a 10mm concrete drill bit. (DP10105HSS) use the 10x105mm Stainless steel DynaBolt™ Available at all good Hardware stores. Note Stainless steel DynaBolt™ are 316 grade Stainless steel and are recommended when installing in the vicinity of chlorine or salt water pools. Clean thoroughly with brush.
Page 5
Shelta Australia’s total liability in respect of a claim by a consumer under the CCA for a minor problem (as defined in the CCA) with a product is limited, at our option to, providing the consumer with a refund, replacement product or repairing the product.
