Summary of Contents for Next 436397
- Page 2 GAMING DESK 436397 H86.5xW100xD60 cm...
- Page 3 GAMING DESK 436397 Assembly instructions Tools required not supplied...
- Page 4 GAMING DESK 436397 (12) (11) (13) (14) (10) (10) 100x28x1.8cm 92x59x2cm 49x10.7x2cm 8x8x0.2cm 24x10.7x2cm 49.8x27x1.8cm 23x16x3cm 100x60x1.8cm 10x4x4cm 72x56x2cm 9x9x1.5cm 7x7x1.5cm 6x6.5x4cm 92x3x2cm...
- Page 5 GAMING DESK 436397 Spare M6x40mm M6x12mm M5x12mm M4x6mm 14x6x1.5mm 75x25x15mm 17x17x15mm...
- Page 6 GAMING DESK 436397 B x6 6x12mm G x2...
- Page 7 GAMING DESK 436397 After attaching the table top with the shelf unit, tighten all screws to 100%. A x6 E x6 14x6x1.5mm 6x40mm...
- Page 8 GAMING DESK 436397 A x2 6x40mm G x2...
- Page 9 GAMING DESK 436397 B x16 6x12mm G x2...
- Page 10 GAMING DESK 436397 A x4 G x2 6x40mm...
- Page 11 GAMING DESK 436397 A x4 G x2 6x40mm The bottom shelf can be fixed on either side for left or right hand use. A x4 6x40mm G x2...
- Page 12 GAMING DESK 436397 Adjust the balance of the table and then tighten all screws to 100%.
- Page 13 GAMING DESK 436397 D x4 4x6mm B x4 6x12mm G x2...
- Page 14 GAMING DESK 436397 Note：Cable clips can be sticked on either side. H x4 I x4 17x17x15mm...
- Page 15 GAMING DESK 436397 We recommend the use of the wall attachment bracket provided for safety reasons. Wall fixings are not included,please source suitable fixings for your wall type.If in doubt, please consult a qualified trades person. WARNING:Always ensure the wall to be drilled is free from hidden electrical wires, water and gas pipes.
- Page 16 GAMING DESK 436397 Actual product size H86.5xW100xD60 cm Warning：the maximum loading weight for this desk is 75 kgs！...
- Page 17 GAMING DESK 436397...
