Summary of Contents for Kvik MU947
- Page 1 MU947 Check out easy mounting of your kitchen Front with integrated handle L01680, mano L01660, mano L03080, mano L03060, mano L03080, mano L03060, mano 80 cm 60 cm 16-09-2019 0b...
- Page 2 MU947 Check out easy mounting of your kitchen DU85,***,000 / 176 (Support ) 2 pcs (Side) (Base-top) (Back panel) (Suspension list) 1 pcs 1 pcs 1 pcs 2 pcs BP21XXX Drawer slide Left Drawer slide right Drawer slide left Drawer slide right...
- Page 3 MU947 FIG. Side Left Screw flh 3,5x15 mm 4 pcs (Side) Screw flh 3,5x15 mm Drawer slide Left 1 pcs NB !!! FIG. Side Right Screw flh 3,5x15 mm 4 pcs (Side) Screw flh 3,5x15 mm Drawer slide right 1 pcs...
- Page 4 MU947 FIG. Side Left (Side) Euro screw Screw flh 6,3x11 mm 3,5x15 mm 4 pcs 1 pcs Drawer slide left 1 pcs FIG. Side Right Screw flh Euro screw 3,5x15 mm 6,3x11 mm 4 pcs 1 pcs (Side) Drawer slide right...
- Page 5 MU947 FIG. (Suspension list) (Support ) NB!!! (Support ) (Base-top) (Side) FIG. (Back panel) 16-09-2019 0b...
- Page 6 MU947 FIG. Screw flh (Side) 3,5x45 mm 5 pcs FIG. Screw flh 3,5x45 mm 5 pcs 16-09-2019 0b...
- Page 7 MU947 FIG. Euroscrew 4,2x9,5 4 pcs Rail holder front right 48,5x30 mm 1 pcs Always use # 2 Euroscrew 4,2x9,5 in right side Rail holder front left BP21XXX 48,5x30 mm Alu profil 1 pcs Always use # 1 in left side NB: Always use # 1 in left side FIG.
- Page 8 MU947 FIG. L016*0, mano Screw flh 3,5x15 mm 4 pcs Angle 46x43 mm 2 pcs FIG. L016*0, mano Screw flh 3,5x15 mm 2 pcs Euro screw 6,3x11 mm 2 pcs 16-09-2019 0b...
- Page 9 MU947 FIG. 16-09-2019 0b...
