1. Button Functions

Home Button: Return to the previous menu or main interface.
Knob: Adjust device settings.
Start / Stop Button: Start / Stop delivering air.

2. Setting up the Device

Mask
Power Cord
Power Outlet E
A. Connect one end of the tube to the assembled mask.
B. Connect one end of the tube to the air outlet of the device, as shown in the figure
above. Or Connect the heated tubing joint to the air outlet of the device, and then insert
the power plug of the heated tubing into the heated tubing port on the back of the
device.
C. Connect the power adapter to the DC inlet of the main device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.

3. Adjusting Device Settings

A. When the device is powered on, the display screen will display the
shown in the left figure below. If the heated tube is connected correctly, the icon
become a number
right figure below.
G3 CPAP (LG3500) Quick Operation Manual V1.0
®
Patient Quick Set-Up Guide
A
Tube
D
Power Adapter
in the Main Interface on the screen of the device, as shown in the
1 / 3
G3 CPAP (LG3500)
®
①
B
②
④
Main Device
C
①: Heated Tubing Port
②: Air Outlet
③: DC Inlet
④: Filter Cap (Air Inlet)
Main Interface, as
③
will
