- Page 1 USER MANUAL JPM370A-R2, JPM375A-R2, JPM380A-R2, JPM385A RACKMOUNT FIBER PATCH PANEL 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TABLE OF CONTENTS TECHNICAL SUPPORT 1.877.877.2269 CHAPTER 1: SPECIFICATIONS ......................................3 CHAPTER 2: OVERVIEW ..........................................4 CHAPTER 3: INSTALLATION ........................................5 APPENDIX A: REGULATORY INFORMATION ................................7 A.1 RoHS .................................................7 A.2 NOM Statement ............................................8 APPENDIX B: DISCLAIMER/TRADEMARKS ..................................9 B.1 Disclaimer ..............................................9 B.2 Trademarks ..............................................9 1.877.877.2269... -
Page 3: Chapter 1: Specifications
TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1. TRANSMITTER SPECIFICATIONS Capacity Fits in 19” or 23” racks Construction 16 AWG cold-rolled steel Connectors JPM370A-R2 (24) Simplex ST adapters ® JPM375A-R2 (12) duplex SC adapters JPM380A-R2 (12) duplex LC adapters JPM385A (24) duplex LC adapters Size 1.8”H (1U) x 16.8”W x 10.8”D (4.4 x 42.7 x 27.4 cm) -
Page 4: Chapter 2: Overview
Š (1) red “danger” sticker that warns you of laser hazard Š (6) 1-inch (2.5 cm) stick-on rectangular cable holders Š (1) pair of black spool rings for cable management If anything is missing or damaged, please contact Black Box at 877-877-2269. 1.877.877.2269 BLACKBOX.COM... -
Page 5: Chapter 3: Installation
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 DANGER Do not look at the fiber ends when the laser is lit. Unmated connectors may emit invisible light, and this may cause eye damage. The patch panel is shipped with two screws installed on the sides for the front rackmounting position. - Page 6 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 Route the multipair distribution fiber cable through the opening in the back of the shelf. Once you pull the cable through the opening in the shelf, use the cable ties and black spool rings to hold the cable in place inside the shelf.
-
Page 7: Appendix A: Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: HEADLINE APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 ROHS This product is RoHS compliant. 1.877.877.2269 BLACKBOX.COM... -
Page 8: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: HEADLINE TECHNICAL APPENDIX A: REGULATORY INFORMATION SUPPORT 1.877.877.2269 A.2 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. -
Page 9: Appendix B: Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this docu- ment and Black Box Corporation may revise this document at any time without notice. - Page 10 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2007, 2021. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. JPM370A-R2-USER_REV2.PDF...
