Item #1006 316 039
Model #XD2615-1A
USE AND CARE GUIDE
FULL MOTION TV WALL MOUNT FOR FLAT PANEL TVS
(FITS VESA 75/100/200/300/400)
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
For additional support, call the manufacturer at 1-800-747-6558.

Advertisement

loading
Need help?

Need help?

Do you have a question about the XD2615-1A and is the answer not in the manual?

Questions and answers

Summary of Contents for Commercial Electric XD2615-1A

  • Page 1 FULL MOTION TV WALL MOUNT FOR FLAT PANEL TVS (FITS VESA 75/100/200/300/400) Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM...
  • Page 2: Table Of Contents

    Table of Contents Safety Information ........2 Pre-Installation .
  • Page 3: Pre-Installation

    Pre-Installation ENSURING THIS IS THE CORRECT WALL MOUNT FOR YOU IMPORTANT: Review this section carefully before you proceed with this installation to ensure that this is the correct TV Wall Mount for you. This TV Wall Mount is the correct wall mount for you if: Your TV VESA size is equal to or no greater than 400 mm x 400 mm (16 in.
  • Page 4 Pre-Installation (continued) ENSURING THE WALL STABILITY Carefully inspect the wall area you have selected. Examine the wall surface before you begin drilling. WARNING: Do not drill near electrical wiring and water pipes. CAUTION: Wood studs must be no smaller than 2 x 4 in. in size. Ensure the surface covering does not exceed 5/8 in. CAUTION: Concrete walls must have a minimum thickness of 5.5 in.
  • Page 5 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware is not shown to actual size. NOTE: The hardware included is suitable for mounting to walls made of brick, solid concrete, or wood studs covered with drywall. If your www.HomeDepot.com. For additional support, you can also call the manufacturer at 1-800-747-6558. Description Quantity Description...
  • Page 6 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Wall plate unit Extension arm Bubble level Mounting template HDMI Velcro ties...
  • Page 7: Installation

    Installation Identifying the bolt diameter to use Identifying the bolt length to use To ensure proper mounting of the brackets to your TV, this Insert a straw or toothpick (not included) into one of the mounting mounting system includes several sizes of bolts (EE – JJ), washers holes on the back of your TV.
  • Page 8 Installation (continued) Attaching the mounting plate to the TV (VESA 75/100 and 200) EE/FF/GG OO/PP NOTE: long, or there is interference between the TV bracket and cable inlets, we strongly recommend the use of spacers. If necessary, align the spacers (KK, LL, MM, or NN) over the mounting holes on the back of your TV.
  • Page 9 Installation (continued) Drilling the mounting holes in a Drilling the mounting holes in a concrete/brick wall wood stud CAUTION: Avoid drilling near electrical wiring and water If you are installing the mounting system into wood studs, proceed pipes. The mounting system must be attached to a weight to step 8.
  • Page 10 Installation (continued) Attaching the TV to the wall plate unit CAUTION: Use two or more people to complete this step. tab(1) Align the wall plate (A1) with the end of the wall plate unit (A2) . Slide the tab (1) on the wall plate (A1) onto the top edge of the wall plate unit (A2).
  • Page 11: Troubleshooting

    Troubleshooting Problem Solution Solution 1 The cables are blocked by the mount or brackets. Add spacers between the bracket and the TV back. Plug in the cable first and then hang the TV. Spacer Solution 2 If the above solution does not help, please contact 1-800-747-6558 with information about your TV's model, size, and weight.
  • Page 12 Troubleshooting (continued) Problem Solution Solution 1 The TV is not level or is out of balance. Check if the wall plate is level using the provided bubble level. If the wall plate is not level, adjust it to level. Level Solution 2 Check if the TV plate is level.
  • Page 13 Troubleshooting (continued) Problem Solution Problem Solution If the bolt is damaged, please contact customer service for a replacement 1. Pre-drill the pilot holes to the required length. Problem Solution Solution 1 Steel Bolt Spacer Solution 2 Steel Spacer Bolt Solution 3 HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 14 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM For additional support, call the manufacturer at 1-800-747-6558. Retain this manual for future use.
