INFORMATION FOR USE WHEN ORDERING SPARES:
Model:
Serial Number:
Technical Information
Nominal heat output kW
Boiler heat output kW
3
Combustion air requirement m
/h
2
Air vent size cm
Weight of appliance Kg
Minimum chimney draught Pascals
Mean flue gas temperature °C
Flue gas mass flow g/s
This appliance is not suitable for installation in a shared flue system
ADDITIONAL SERVICEABLE PARTS
1. Brick Linings
ESSE Engineering Ltd, Long Ing, Barnoldswick, Lancashire BB18 6BN
Tel: 01282 813235 Fax: 01282 816876 Email: enquiries@esse.com Website: http://www.esse.com
EW
EWB
9.7
10.5
—
2.6
40
55
30
50
370
375
12
12
250
255
18.5
13.7
08/08
ESSE Cooking Stove
INSTALLATION INSTRUCTIONS
MODEL: EW & EWB
THIS APPLIANCE MUST BE COMMISSIONED BY A HETAS REGISTERED ENGINEER OR A COMPETENT
PERSON. THE WARRANTY CARD MUST BE RETURNED TO ENSURE GUARANTEE VALIDITY
HETAS
Approved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Esse EW
Summary of Contents for Esse EW
- Page 1 ADDITIONAL SERVICEABLE PARTS 1. Brick Linings ESSE Engineering Ltd, Long Ing, Barnoldswick, Lancashire BB18 6BN Tel: 01282 813235 Fax: 01282 816876 Email: enquiries@esse.com Website: http://www.esse.com THIS APPLIANCE MUST BE COMMISSIONED BY A HETAS REGISTERED ENGINEER OR A COMPETENT HETAS PERSON. THE WARRANTY CARD MUST BE RETURNED TO ENSURE GUARANTEE VALIDITY...
- Page 2 GENERAL SAFETY INFORMATION The Cooking Stove - Fig.1 Dimensions and boiler tapping In the UK, the installer has a responsibility under the Health and Safety at Work Act 1974 to provide for Secondary Oven damper air control control the safety of persons carrying out the installation. Attention is drawn to the fact that fire cement is 416mm 16”...
- Page 3 Note: This test is only a guide as an apparently poor flue may improve once the cooking stove is installed, lit and the flue is warmed. Once the cooking stove is installed, a flue draught reading ESSE as can be seen here looking at the underside should be taken.
- Page 4 PRESSURE ZONES, POSITION & DOWN DRAUGHT FLUE STABILISER A flue stabiliser can be fitted to reduce the draught through the cooking stove if the flue draught is 1) Pressure and suction zones created by wind too high. The flue stabiliser should be fitted in the same room as the cooking stove, be the same size as the flue pipe and be fitted no closer than 700mm to the flue outlet of the appliance.
- Page 5 Typical DHW Gravity System HOT WATER SYSTEM OPEN VENT OPEN VENT A) There are two connections, both 1” BSP Male on the left hand side. Follow general notes below. B) The EWB or DE-LUXE boiler is plain mild steel and capable of running a radiator in addition to domestic hot water.
- Page 6 SPARE PARTS Upper Door Handles Lower Door Handles Fire Guard Cast Fire Door Ash Door Magnet Catch Temperature Clock Ceramic Glass Window Flue Access Door 10 Oven Door Liner 11 Fuel Guard 12. Stainless Baffle - no longer in use 13 Flue Access Plate 14 Ashpan 15 Grate...
