DC Turbo Power Supplies
"Turbo Function" is installed so that it can output widely in compact size
Max. output voltage ▶ 80 to 650 V
Max. output current ▶ 5 to 100 A
Max. output power ▶ 400 W, 800 W, 1600 W
800 W model
www.matsusada.com
Programmable DC Turbo Power Supplies
RKT Series
RKT
se ri es
400 W model
NEW
NEW
1600 W model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RKT Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matsusada RKT Series

Summary of Contents for Matsusada RKT Series

  • Page 1 Programmable DC Turbo Power Supplies RKT Series DC Turbo Power Supplies “Turbo Function” is installed so that it can output widely in compact size Max. output voltage ▶ 80 to 650 V Max. output current ▶ 5 to 100 A se ri es Max.
  • Page 2 1600 W Model (19 inches rack size) RKT series power supply is programmable DC power supply with distinctive turbo function which realises 4-5 times wider coverage of output voltage and current in comparison to conventional DC power supply of equivalent output power.
  • Page 3 Following Applications, for Example Features Evaluation of electrics elements for automobile It realizes Wide Range Output by installed Turbo Function. Covered from 12 V to Higher Volt. by this One Unit. Evaluation of Communication Equipment Best fit to Research and Development by the Low Noise Switching System.

  • Page 4: Principal Functions

    （On the master unit） （On the master unit） In case -LUs1,-LEt or -LGob option is selected, only one unit of RKT series can be used. Master Function to delay the OUTPUT ON / OFF time. It is possible to use in case single...
  • Page 5 Useful New Functions These are applicable to wide range of usages as various methods of use is possible by adding -LDe option. Function for Pulse & Ramp Sequence and Master Follow (-LDe Option) Output control as Next A to D are possible. A.

  • Page 6: Standard Functions

    Standard Functions Remote Switch ON / OFF Digital Interface Output is made ON / OFF with an external relay or open collector. In addition to digital control with LAN (Ethernet), USB, RS-232C, RS-485 and GPIB, one control is enabled in master-slave operation. Various Adapter (sold separately) -S (common)

  • Page 7: Specifications

    Specifications Input Voltage 85 to 264 VAC, 50 / 60 Hz Single Phase Power Factor at 100 VAC input and max. output : 0.99 typ. Input Current 6 Amax(400 W Model), 13 Amax(800 W Model), 20 Amax(1600 W Model) at 100 VAC input Local : Constant Voltage Rotary Encoder on the Front Panel * Output Control if output power is set beyond max.

  • Page 8: External Specifications

    External Specifications Display Output Voltage and OVP setting Setting Knob for Output Current(shared OCP Setting) Display Output Current and OCP setting Preset Switch for Output Setting Switch OVP / OCP Display Remote Programming lighted during remote control of Voltage / Current. Setting Switch Key Lock Display OUTPUT lighted during output.
  • Page 9 Dimensions inch (mm) 400 W Models Weight : 3 kg approx. 0.87 13.78 0.71 (22) (350) (18) 2.76(70) 4.88 2xM6 (124) INPUT AC100-240V 6.2A 50 60Hz 0.31 Weight : 6 kg approx. 800 W Models, except RKT650-5 (800W) 0.87 13.78 0.67 (22) (350)
  • Page 10 Options *1 *2 *3 -LGob : Optical interface Board -LDe : Pulse and Ramp Sequence -LGob Optical Interface board + Optical cable 2 m Please refer to page 5 for detail. -LGob （ Fc5） Optical Interface board + Optical cable 5 m -LGob （...

  • Page 11: Technical Notes

    Example for Applied Actions With RKT series of the same model, output voltage and current can be increased by connecting power supplies in series or parallel. We recommend local control or master-slave control. Do not connect together COMMON of 2 units or more as the COMMON of connector for external input and output control (TB1) is connected with output.

  • Page 12: Other Countries

    The use under such environment is not covered by this warranty and may require additional design and manufacturing processes. No modification or supplement of this warranty shall be binding unless in writing and signed by a duly authorized officer of Matsusada. Matsusada reserves the right to make any changes in the contents of catalogs or specifica- tions at any time without advance notice.
