Keri Systems KDC-8 Quick Start Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Eight-Door Concentrator
Keri Systems KDC-8 Eight-Door Concentrator places four controllers into one cabinet, reducing
the amount of space needed to mount four controllers. The concentrator is designed to fit in a
standard IT server/telecom rack, but can easily be wall mounted. There are knock-outs around the
outside of concentrator's enclosure for cable routing.
1.0
Unit Specifications
•
Height – 15 inches (plus 0.25 inches for the cover)
•
Width – 17 inches (plus 0.25 inches for the cover)
•
Depth – 6.5 inches (plus 0.25 inches for the cover)
•
Weight – 19 pounds (including controllers and satellite boards, NOT including cabling)
•
Power Requirements – 12 VDC @ 3 A for the concentrator cabinet, including four, two-door
controllers.
NOTE: Separately powered door lock power requirements depend upon the door locks being used.
Please ensure sufficient power is provided to support all door locks connected to the cabinet.
Figure 1: 8-Door Concentrator Enclosure
2.0
Mounting the Cabinet
There are three methods of cabinet mounting.
1. wall mounting through the rear of the cabinet
2. wall mounting using the rack brackets
3. rack mounting to a standard IT Server/Telecom rack
2305 Bering Drive
San Jose, CA 95131 USA
(800) 260-5265 (408) 435-8400 FAX (408) 577-1792
Web: http://www.kerisys.com E-mail: sales@kerisys.com
01959-001 Rev. 1.1
Page 1 of 24
