Monitor Table
Instruction Manual
1
Model:HNHM4
Thank you for choosing this Huanuo product! At Huanuo we
strive to provide you with the best quality products and
services in the industry. Please share your experience of our
product with others on www.huanuoav.com/reviews if you are
satisfied. Should you have any issues, please don't hesitate to
contact us.
Technical Support:
1-800-556-0533 Mon-Fri 10am - 5pm (PST) (USA) (CAN)
Other Info:
support@huanuoav.com (US/CA/DE/UK/FR/IT/ES/AU)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HUANUO HNHM4
Summary of Contents for HUANUO HNHM4
- Page 1 Monitor Table Instruction Manual Model:HNHM4 Thank you for choosing this Huanuo product! At Huanuo we strive to provide you with the best quality products and services in the industry. Please share your experience of our product with others on www.huanuoav.com/reviews if you are satisfied.
- Page 2 UNPACKING INSTRUCTIONS AND IMPORTANT SAFETY INFORMATION UNPACKING INSTRUCTIONS AND IMPORTANT SAFETY INFORMATION •Carefully open the carton, remove contents and lay out on cardboard or other protective surface to avoid damage. •Check package contents against the Supplied Parts and Hardware to assure that all components were received undamaged.
- Page 3 Connect Upper Pole to Lower Pole STEP Step 1-1 Loosen the screw [S] on pole [02] using Allen key [E] 1/8 in.(3mm) Step 1-2 Connect pole [01] to pole [02] Step 1-2 Tighten the screw [S] using Allen key [E] to fix the two poles For C Clamp Mounting STEP Step 2A-1...
- Page 4 Step 1A-2 Step 1A-3 Step 1A-4 Install part Secure the Adjust the mount according to the thickness of desktop [04] to part [03] mount to the desktop 15/64 in.(6mm) 45mm(1 in.) ＜ 45mm 80mm(3 in.) in.) STEP 2B For Grommet Mounting Step 2B-1 Install part [09] to pole [02] 1/8 in.(3mm)
- Page 5 Step 3 Install Cable Clips & Monitor Connector to the Pole Assembly Secure the monitor connector [05] Slide the two cable clips [07] to the pole assembly,then attach the Step 3-2 and the monitor connector Step 3-1 cable clips [08] to the monitor [05] to the pole assembly connector [05] Step 3-1...
- Page 6 Bolt length:Verify adequate thread engagement with bolts or bolts/spacers combination. We recommend thread engagement by at least 5 turns. -Too short will not hold the monitor. -Too long will damage the monitor. Attach the Monitor Plates to the Monitors Step 5 FLAT BACK MONITOR (UNIVERSAL MONITOR PLATE) M-A/M-C...
- Page 7 Fix Tilt Angle of thr Monitors Step 7 15/64 in.(6mm) Step 8 Manage Cables...
- Page 8 Store Allen Keys into the Cable Clip Step 9 F 15/64 in.(6mm) E 1/8 in.(3mm) Features 180° 360° Tilt Tilt 360° Individual VESA plate height adjustment helps monitors to be perfectly aligned.
