Table 10 IEEE 802.11n Only Parameters
Parameter
Wireless RF Mode
Enable Isolation
Mode
Country/Region
Band Width
Channel
SGI Enable
Beacon Interval
Transmitting Power
QoS Type
RTS Threshold
DTIM Interval
3. Click Submit.
4.2.2 SSID Settings
Perform this procedure to configure multiple SSIDs.
The ZXHN H298N can be specified with four SSIDs and each SSID supports up to 32 subscribers.
Steps
1. Choose [Network→ WLAN→ SSID Settings].
2. Select an SSID from the Choose SSID drop-down list, as shown in
Description
Select Enabled to enable the wireless RF function.
When you select this check box, the subscribers with different
SSIDs cannot visit each other.
Select the working mode according to the wireless network card
configuration.
Select the country or region.
You can select 20Mhz or 40Mhz.
The default is Auto.
Select this check box to enable the short GI function.
Time interval for the wireless device to broadcast the SSID
Keep the default value.
Select the transmitting power as required.
Type of QoS
Specify the Request to Send threshold for a packet. When a
packet exceeds this value, the device sends the RTS value to the
destination point for negotiation. The default is 2347.
The value range is from 1 ms to 5 ms. The default is 1 ms.
41
Figure
26.
