Technical data

What this chapter contains

This chapter contains the technical details of the Assistant control panel.

Connectors

The control panel has the following connectors:
Connector
RJ-45 female connector
Type B mini USB connector

Display

The control panel has a monochrome, 240×160 pixel resolution LCD display with adjustable
backlight and display contrast.
See Basic settings and assistants (page

Battery

At an ambient temperature of 25 °C (77 °F), the change interval of the real-time clock battery
is approximately 10 years.
Battery type
Purpose
Used for connecting the panel to drive.
• If cable is used, then maximum length should be 100 meters (328 ft.)
• On a panel bus, the combined maximum length of the panel bus cables
should be 100 meters (328 ft.).
• The panel bus can have a maximum of 32 nodes.
Used for connecting panel to PC. It is intended for temporary service use
(USB 2.0, MTP protocol). The maximum cable length should be three meters
(9.8 ft.).
31).
CR2032
