ASSEMBLY INSTRUCTIONS
Before you begin, please follow assembly instructions carefully, then follow them step by step.
Read instruction carefully . See Furniture Parts list and Hardware List for guidance . Be sure you have all parts before you start assembling .
Place and assemble furniture on a clean flat soft surface , such as carpet or rug to pervent being scratched .
PART LIST
1
TOP PANEL
2
BOTTOM PANEL
SIDE PANEL (L)
3
SIDE PANEL (R)
4
CENTER PANEL (L)
5
CENTER PANEL (R)
6
SHELF PANEL
7
8
BACK PANEL
9 DOOR PANEL
SELF-PREPARED TOOLS: Tools below are NOT included in package.
SCREWDRIVER
Reminder:
Please ensure that all surfaces and edges with colours/laminations are facing forward/outward.
PAGE:
HARDWARE
QTY
1 PC
A
MINI FIX
A1
1 PC
B
M8 X 30MM WOOD DOWEL
M6 X 5OMM
1 PC
C
CSK CAP WOOD SCREW
1 PC
D
ALLEN KEY M4
1 PC
E
M3.5 X 16MM C.B SCREW
1 PC
F
5/8 NAIL
2 PCS
G
METAL SHELF SUPPORT
1 PC
H
7/8 HINGES
1 PC
I
PVC SQUARE LEG 5038
HAMMER
3
9
MODEL : GHTVS-1397
1
/4
8 SETS
A3
A2
16 PCS
8 PCS
1 PC
28 PCS
28 PCS
8 PCS
2 PCS
5 PCS
1
8
5
7
2
6
7
4
Advertisement
Table of Contents
Related Manuals for overstock GHTVS-1397
Summary of Contents for overstock GHTVS-1397
- Page 1 MODEL : GHTVS-1397 ASSEMBLY INSTRUCTIONS PAGE: Before you begin, please follow assembly instructions carefully, then follow them step by step. Read instruction carefully . See Furniture Parts list and Hardware List for guidance . Be sure you have all parts before you start assembling .
- Page 2 MODEL : GHTVS-1397 ASSEMBLY INSTRUCTIONS PAGE: STEP 1 STEP 2 SCREWDRIVER REQUIRED Insert hardware A2 onto panel (1). - Insert hardware A1 onto panel (3) and (4). (Repeat 8 times.) (Repeat 4 times.) - Insert hardware B onto panel (3) and (4).
- Page 3 MODEL : GHTVS-1397 ASSEMBLY INSTRUCTIONS PAGE: STEP 5 STEP 6 SCREWDRIVER HARDWARE REQUIRED Connect panel (2) to panel (3), (4), (5) and (6) - Fix hardware I into panel (2) with hardware E. by using hardware C and D. ( Repeat 4 times for each hardware.) (Repeat 8 times.)
- Page 4 MODEL : GHTVS-1397 ASSEMBLY INSTRUCTIONS PAGE: STEP 9 STEP 11 SCREWDRIVER REQUIRED - Assemble the panel (7) into between panel (4) and (6). - Fix hardware H into panel (3) by using hardware E. (Repeat 1 times.) (Repeat 2 times for each hardware.) - Assemble the panel (7) into between panel (5) and (6).
