Great care was taken when compiling the texts and illustrations; Nevertheless, errors cannot be ruled out. The company FISCHER Mess- und Regeltechnik GmbH will not accept any legal responsibility or liability for this.
FISCHER Mess- und Regeltechnik GmbH Table of contents Table of contents 1 Safety instructions ......................4 1.1 General........................... 1.2 Personnel Qualification......................1.3 Risks due to Non-Observance of Safety Instructions ............. 1.4 Safety Instructions for the Operating Company and the Operator .........
1 | Safety instructions FISCHER Mess- und Regeltechnik GmbH 1 Safety instructions 1.1 General This operating manual contains basic instructions for the installation, operation and maintenance of the device that must be followed without fail. It must be read by the installer, the operator and the responsible specialist personnel be- fore installing and commissioning the device.
FISCHER Mess- und Regeltechnik GmbH Safety instructions | 1 1.6 Inadmissible Modes of Operation The operational safety of this instrument can only be guaranteed if it is used as intended. The instrument model must be suitable for the medium used in the system.
• Operating manual 2.2 Intended use The capacitive filling level probe NC56 serves to measure tank filling levels in tanks containing fresh water, waste water, faeces, diesel fuel, chemicals and extinguishing foam. Filling level heights of between 400 and 2000 mm can be measured.
2 | Product and functional description FISCHER Mess- und Regeltechnik GmbH 2.4 Function diagram Max. Min. Status LED brown blue black Output µC Probe : Start capacity (probe free) : End capacity (probe covered) Fig. 4: Function diagram 2.5 Design and mode of operation An AC voltage signal is exerted onto two metal rods held at a defined distance to each other.
As standard, the device is intended for assembly in a size 1¼ mounting flange. If a protection tube is used, a pipe connection suitable for a size 2 mounting flange is used. The NC56 is suited only for vertical installation and, if possible, should be mounted at the highest point of the tank.
Page 10
3 | Assembly FISCHER Mess- und Regeltechnik GmbH 3.2.1 Shortening the probe rods CAUTION Damage to coating Insulated electrodes can become unusable as a result of rough impacts and shocks (e.g. hitting the floor). If you need to shorten the electrodes, proceed as follows: •...
FISCHER Mess- und Regeltechnik GmbH Assembly | 3 3.3 Electrical connections • By authorized and qualified specialized personnel only. • When connecting the unit, the national and international electro-technical regulations must be observed. • Disconnect the system from the mains, before electrically connecting the device.
4 | Start-up FISCHER Mess- und Regeltechnik GmbH 4 Start-up 4.1 General All electrical lines must have been installed properly before the start-up takes place. All connections must be arranged so that there are no mechanical forces acting on the device.
Page 13
FISCHER Mess- und Regeltechnik GmbH Start-up | 4 Useful information about the calibration If the filling levels change, the calibration can be repeated at any time. If just one of the two filling levels changes, it is sufficient to recalibrate only the corres- ponding value.
5 | Servicing FISCHER Mess- und Regeltechnik GmbH 5 Servicing 5.1 Maintenance The instrument is maintenance-free. We recommend the following regular in- spection to guarantee reliable operation and a long service life: • Check the function in combination with downstream components.
FISCHER Mess- und Regeltechnik GmbH Technical data | 6 6 Technical data 6.1 General General information Type designation NC56 Measurement principle Continuous measurement of the capacity change between two/three probe rods, de- pending on the filling probe of a fluid.
6 | Technical data FISCHER Mess- und Regeltechnik GmbH 6.6 Operating conditions Ambient temperature range -20 °C ... +70 °C Storage temperature range -40 °C ... +80 °C Medium temperature range Max. 80°C IP protection class IP67 EN 61326-1:2013 EN 61326-2-3:2013...
Page 17
FISCHER Mess- und Regeltechnik GmbH Technical data | 6 6.7.2 Dimension drawings Ø60 Ø60 M12 plug connector G 1¼ G 1¼ Spanner attachment SW55 Ø4.8 Ø4 Ø4 Probe with 3 rods Probe with shrink-fit tubing (uncoated Ø60 SW77 octagonal G 1¼...
7 | Order codes FISCHER Mess- und Regeltechnik GmbH 7 Order codes Code no. 10 11 12 Type Design: (Code no.) Rod 1 Rod 2 Rod 3 Water Shrink-fit tubing Bare (1.4404) waste water Diesel Bare (1.4404) Bare (1.4404) Bare (1.4404)
FISCHER Mess- und Regeltechnik GmbH Order codes | 7 Operating voltage: (Code no.) 9 to 32 V (for current output) 12 to 32 V (for voltage output) Version: [9-12] (Code no.) 2011 Version 7.1 Accessories Order no. Designation No. of...
