PACKAGE CONTENTS
Part
A
B
C
D
WARNINGS AND CAUTIONS
WARNING
•
To reduce the risk of electrical shock, connect only to a properly grounded, grounding type receptacle
(GFCI).
•
Do not exceed the voltage shown on the transformer.
•
Do not submerge the transformer and sensor.
•
To reduce the risk of fire or injury, keep lamp away from materials that may burn.
•
Always disconnect light from the power source before beginning any maintenance or work on the light.
•
Inspect cord for damage before installation and/or maintenance. Replace the entire light/transformer
assembly if damage is found.
CAUTION
•
Light gets hot! - Do not touch the lens, guard, or enclosure until light is turned off and cool.
•
Turn light off and allow to cool before replacing the bulb.
•
Use a proper power source as indicated on the transformer label.
•
Keep the cord away from high temperatures or other heat sources.
•
Do not lift the light or the transformer by its power cord.
•
This light assembly is not intended for use in swimming pools or hot tubs.
Fountain and Landscape Light Kit
Description
Light
Sensor
Transformer
Color lenses
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@geoglobalpartners.com. Or
visit our website www.total-pond.com.
Quantity
1
1
1
4
1
ITEM # UW16200
A
B
C
D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TotalPond UW16200
Summary of Contents for TotalPond UW16200
- Page 1 ITEM # UW16200 Fountain and Landscape Light Kit Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday, or email us at customercare@geoglobalpartners.com. Or visit our website www.total-pond.com. PACKAGE CONTENTS...
