ADS EOS Instructions For Use And Installation
Extraoral dental suction system
Hide thumbs
Also See for EOS:
- Instructions for use and installation (32 pages) ,
- Instructions for use and installation (32 pages)
Subscribe to Our Youtube Channel
Related Manuals for ADS EOS
Summary of Contents for ADS EOS
- Page 1 EOS Extraoral Dental Suction System Instructions For Use and Installation P/N：8027313 Version：A Date of Issue：2020-03-18...
- Page 2 ADS EOS Extraoral dental suction system, as a suction filtration equipment, the product does not have air disinfection function, it is NOT an air sterilizer. The EOS Extraoral suction system is designed to suck aerosols and droplets come out of the patient’s cavity so as to reduce the risk of being infected, dental professionals still need to protect themselves by wearing proper PPE.
-
Page 3: Table Of Contents
Extraoral Dental Suction System, Instructions For Use Contents 1 Product Introduction……………………………………………………………………………………1 ……………………………………………………………………………1 Intended Use of the Product…… …………………………………………………………………………1 Product Standard Lifetime Safety Precautions……………………………………………………………………………………………1 3 Product Structure……………………………………………………………………………………4 4 Product Specifications………………………………………………………………………………………5 4.1 Product Dimensions …………………………………………………………………………………6 4.2 Product Package Size and Weight …………………………………………………………………………8 Product Installation………………………………………………………………………………………9 Product Use……………………………………………………………………………………10 6.1 Warning………………………………………………………………………………………10 6.2 Preparation……………………………………………………………………………………12 6.3 Turn on the power ……………………………………………………………………………………13... -
Page 4: 1 Product Introduction
Extraoral Dental Suction System, Instructions For Use and Installation 1 Product Introduction The instructions contained in this manual should be thoroughly read and understood before operating the equipment. After the installation is completed, keep this manual in a safe place for future reference. 1. - Page 5 Extraoral Dental Suction System, Instructions For Use and Installation CAUTION ADS will not be responsible when equipment damage or failure is caused by below issues. ● The product is not installed, modified, or maintained by ADS designated operator. ● The product damage or failure is caused by products purchased from other companies than ADS and ADS authorized dealers.
- Page 6 ④ Never expose the product to chemicals or place the product near chemical storage area. ⑤ Clean the equipment on a per operation basis. 7)In case of the troubles, please contact ADS or ADS authorized dealers and technicians. Do not disassemble or attempt to repair.
-
Page 7: 3 Product Structure
Extraoral Dental Suction System, Instructions For Use and Installation 3 Product Structure 8026695 Case Panel 8026722 Handle 8026722 Fine Filter A121945 Suction Hood 8026635 Motor 8026746 Suction arm of the third joint 8026623 UV Light A121944 The third joint 8026563 HEPA filter 8026608 Muffler stick... -
Page 8: 4 Product Specifications
Extraoral Dental Suction System, Instructions For Use and Installation 4 Product Specifications Model EOS Extraoral Suction System Electric Voltage AC110V 60Hz 20A Lower current Power 1160W Fuse wire 20A 250V Suction Flow 105CFM 10KPa (10 Different Levels) Power Average Efficiency (EM) for 0.4MM particles(%),90<EM<95 Fine Filter Minimum efficiency* for 0.4MM particles(%),55... -
Page 9: Product Dimensions
Extraoral Dental Suction System, Instructions For Use and Installation 4.1 Product Dimensions... - Page 10 Extraoral Dental Suction System, Instructions For Use and Installation...
-
Page 11: Product Package Size And Weight
Extraoral Dental Suction System, Instructions For Use and Installation 4.2 Product Package Size and Weight Suction arm Case Packing Size 27.2”x10.2”x9” 14.6”x14.2”x39.4” Net Weight 3.2lbs 94.2lbs Gross Weight 5lbs 98.6lbs... -
Page 12: Product Installation
Extraoral Dental Suction System, Instructions For Use and Installation 5 Product Installation 1. Fix the bottom of center post on the case with screws. Put hosepipe through hose clamp and connect the hosepipe with the center post. Then tighten the hose clamp. -
Page 13: Product Use
Extraoral Dental Suction System, Instructions For Use and Installation 3. Insert the suction mouth tube into the mounting hole of the third joint. Make sure the thumb screw align with the center pillar groove. Then tighten the screw. 6 Product Use 6.1 Warnings During Use •... - Page 14 Extraoral Dental Suction System, Instructions For Use and Installation Handle Place the product on Move by handles level ground...
-
Page 15: Preparation
Extraoral Dental Suction System, Instructions For Use and Installation 6.2 Preparation 110V 60Hz (20A) Connect the 3P plug into a grounded wall socket for 110V/over 25A power supply... -
Page 16: Turn On The Power
Extraoral Dental Suction System, Instructions For Use and Installation 6.3 Turn On the Power ● Remove everything that might be mistakenly sucked in by the equipment. ● Make sure the suction arms are installed properly. ● Keep a distance of 3.94 Inches between suction hood and patient’s mouth. ●... -
Page 17: Operation Principle
Extraoral Dental Suction System, Instructions For Use and Installation 6.5 Operation Principle First, the equipment collects aerosols, droplets, dust and pathogens produced during dental procedures through a suction hood. Second, particulate matter are filtrated by the dust filter. Third, the exhaust go through HEPA filter Exhaust for a second time filtration, and the UV light exposure on the HEPA filter after 30 minutes... -
Page 18: Parts Cleaning And Replacement
Extraoral Dental Suction System, Instructions For Use and Installation 7 Parts Cleaning and Replacement • When installing or removing the suction hood, hold the hood by the connecting end, instead of by the far end. • To clean the equipment surface, dampen a soft cloth and wring before wiping. •... -
Page 19: Instructions For Replacing The Suction Arm
Extraoral Dental Suction System, Instructions For Use and Installation 7.2 Suction Arms [Daily Clean] • Use disinfectant or wiping to clean the product surface. • To clean the inside of suction arms, turn on the equipment while spraying degerming spray towards the suction hood. •... -
Page 20: Instructions For Replacing The Muffler Filter
Extraoral Dental Suction System, Instructions For Use and Installation 7.3 Muffler Filter Stick Replacement • Cut off the main power and plug out. • Keep your hands try. • Wear gloves. [Caution] Replaced muffler stick should be disposed in category of medical waste. ①... -
Page 21: Instructions For Replacing The Hepa Filter
Extraoral Dental Suction System, Instructions For Use and Installation 7.5 HEPA Filter Replacement Percentage of remaining lifetime The defaulted lifetime of filters are 12 months. When the equipment is powered on, the percentage of filter’s remaining lifetime will be shown on the panel. However, filter’s lifetime may vary in different operation environment. -
Page 22: Instructions For Replacing The Uv Light
Extraoral Dental Suction System, Instructions For Use and Installation UV Light Replacement • Cut off the main power and plug out. • Keep your hands try. • Wear gloves. • ①Detach the case panels. • ②Unlock the dust-proof drawer locker and press the cover plate. -
Page 23: Instructions For Replacing The Fuse Wire
Extraoral Dental Suction System, Instructions For Use and Installation 7.7 Fuse Replacement • Cut off the main power and plug out. • Keep your hands try. ① Pull the plug out from socket. ② Open the holder cover using a cross screwdriver as instructed on fuse holder. -
Page 24: Transportation And Storage Conditions
ADS Customer Services. 11 Warranty and Customer Services The EOS Extraoral suction system is with 2 year warranty from the date of purchase. Please contact us if you have any feedback and opinions on this document.If you want to get service information,please contact the local dealer authorized by ADS. - Page 25 Extraoral Dental Suction System, Instructions For Use and Installation 8026695 Case Panel 8026722 Handle 8026722 Fine filter A121945 Suction Hood 8026635 Motor 8026746 Suction arm of the third joint 8026623 UV Light A121944 The third joint 8026563 HEPA filter 8026608 Muffler stick 8027319 Transformer...
-
Page 26: Electromagnetic Compatibility
For the Extraoral Dental Suction System, use cables that are authorized by ADS only. • Attempt to use cable or other components from unauthorized source could lead to electro magnetic abnormalities. - Page 27 Extraoral Dental Suction System, Instructions For Use and Installation Statement of Manufacturer— Electromagnetic Immunity Extraoral Dental Suction System is designed for electro magnetic environment described below. Be sure to apply. Electromagnetic Electromagnetic IEC6061 Test Level Test Level Comformance Immunity Test Environment The floor should be of wood, concrete, or tile.
- Page 28 Extraoral Dental Suction System, Instructions For Use and Installation Statement of Manufacturer— Electromagnetic Immunity Extraoral Dental Suction System is designed for electro magnetic environment described below. Be sure to apply. Electromagnetic Test Level IEC6061 Test Level Electromagnetic Environment Immunity Test Comformance The isolation distance between portable and mobile RF...
- Page 29 Extraoral Dental Suction System, Instructions For Use and Installation Recommended isolation distance between portable and mobile RF communication devices and Extraoral Dental Suction System Extraoral Dental Suction System are intended for use in electromagnetic environments where RF radiation disturbances are controlled. Depending on the maximum rated output power of the communication device, the purchaser or user can prevent electromagnetic interference by maintaining the minimum isolation distance between portable and mobile RF communication devices (transmitters) and Extraoral Dental Suction System as recommended below.
-
Page 30: Related Symbol Descriptions
Extraoral Dental Suction System, Instructions For Use and Installation 12. Symbols Descriptions Symbols Descriptions Keep Dry Handle with Care More Information Serial Number Grounding Connection This Way Up Caution Type B Machine Power Switch Activate Gear Up Gear Down... - Page 31 ADS Dental System Inc. Technical Support:800 488 9708 Tel: (626) 620 0456 E-mail: ads@adsequip.com http://www.adsequip.com/ Add: 1590 S MILLIKEN AVE,UNIT A ONTARIO,CALIFORNIA,91761,USA...
